ZÄHL H1 Reference Headphone Amplifier
ZÄHL - H1 Reference Headphones Amplifier, Perfect Impulse Reproduction, Ultra Wide Frequency Response
Email me when the availability or price changes
Finance this product
- From £211.47 / month (APR 16.9%) or 0% for 4 months
- With a 10% deposit from just £199.30 / month (APR 19.9%)
Reference Headphone Amplifier
ZÄHL - H1
pure analogue designThe ZÄHL H1 reference headphone amplifier offers unprecedented transparency and precision, attention to detail and massive power performance. For both high-end enthusiasts and professional users. It features class A power amplifier in its purest form with switchable negative feedback [„servo“] while maintaining Class A operation. Stereo base control allows you to adjust the sound stage to your preferences, as a precision tool for widening or narrowing the stereo image or switching to mono. Get the most out of your headphones with this incredible headphone amplifier, designed and manufactured in Germany!
at a glance
• Perfect impulse reproduction
• Ultra wide frequency response
• Extremly low impedance output precisely controls complex loads
• Integrated toroidal mains transformer with specially designed mumetal housing
• No-compromise components and interior/exterior construction
• Logic circuits without clock generators
• Consistent dual-mono layout
• Straight linear power supply
• No external power adapter needed
The Tech Spec
| Features | Specification | Inputs | Line Inputs balanced – Impedance 20KΩ – max. level +23dBu Line Inputs unbalanced – Impedance 20KΩ – max. level +23dBu |
|---|---|
| Headphones Output | Impedance Class A 0,8Ω, Class A & Servo 0,045Ω max. level +23,5dBu (+/-16,5V) |
| Output Power per Side | RMS 4W/30Ω; 7W/15Ω Peak 7,6W/30Ω; 11W/15Ω; 12W/10Ω (18W for 1,5ms) |
| Frequency Response | 10Hz ... 30kHz -/+0,05dB 1Hz ... 500kHz better than -3dB at Headphones Output @ +6dBu |
