Product Overview The Tempest HX S7100 motherboard is designed to be an ideal platform for both GPU workstations and general purpose server applications. As a workstation motherboard, the S7100 features onboard audio and allows the use of 4 GPU cards. This enables maximum performance in technical computing workloads such as Engineering Analysis, 3D Design, Photorealistic Rendering, Image Manipulation, Media & Entertainment Creation, and Energy Exploration. With much of modern high performance workstation applications featuring support for VGA offloading and all four PCIe x16 slots being a full electrical x16 link, Tyan's Tempest HX S7100 is one of the most powerful workstation motherboards on the market today. The Tempest HX S7100 is also a versatile platform for many server applications. With a total of 7 PCIe slots, it lends itself well to many high I/O applications such as Video Walls, Large Scale Video Capture, Surveillance, Industrial Automation, and general purpose server workloads. The board design also lends itself to offering support for true full length 12.3" PCIe cards. Features • Xeon Scalable Processor Family.
• 7 PCIe slots.
• 205W CPU Support.
• Optional HD Audio.
• 4 GPU Support.
• Dual Port SATA DOM and NVMe M.2.
• IPMI 2.0 with Redfish Support.
Specifications
Core Specifications
Edition Tyan S7100
Form Factor SSI EEB
CPU Socket 3647
Chipset Intel C621
RAM Memory Support
Memory Type DDR4 RDIMM/LRDIMM
Memory Channel Hex (6) per CPU/Socket
Memory Type (ECC)
Memory Type (R/U) RDIMM / LRDIMM
Memory Speed (Mhz) DDR4 - 2666
Max. Memory Capacity 1536GB (24x64GB)
Audio
Audio 7.1 Channel HD Audio
Graphics Support
Primary GPU Interface PCIe (x16)
NVIDIA SLI Support Not Supported
AMD CrossFire Support Not Supported
Integrated Graphics Integrated ASPEED AST2500
On-Board Graphics Connectors D-Sub (VGA)
Internal Connectivity
Expansion Slots
  • 4 x PCIe 3.0 x16
  • 3 x PCIe 3.0 x8
SATA Support SATA
RAID Support via RAID 0/1/10/5 (Intel RSTe)
Storage Mode Support Intel Rapid Storage Technology Enterprise
Internal I/O
  • 3 x Mini SAS
  • 3 x USB 2.0 Port
External Connectivity
Network Interface Type
Network Chip/Modules
Rear I/O Connectors
  • 3 x USB 2.0
  • 6 x USB 3.0
Additional Specifications
Water Cooled No
Cooling
QPI Speed N/A
Board Dimensions 309.8*331.2 mm
Note
Additional Information
Scan Code LN96837
Model Number S7100GM2NR
GTIN 635872043239
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
36 months
Type:
Return to base
DOA Period:
14 days
RTB Period:
36 months
