New
Scan code: LN93540 Manufacturer code: Archer C2300

TP-Link Archer Dual Band AC2300 Router

TP-Link Archer C2300 Router, 3x Antennas, MU-MIMO, Dual-Band 2.4+5GHz (600+1625Mbps), GbE, 802.11ac

Thumbnail 1 : TP-Link Archer Dual Band AC2300 Router Thumbnail 2 : TP-Link Archer Dual Band AC2300 Router Thumbnail 3 : TP-Link Archer Dual Band AC2300 Router Thumbnail 4 : TP-Link Archer Dual Band AC2300 Router
Scan code: LN93540 Manufacturer code: Archer C2300
£161.99
spend over £225 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
Delivery Options
  • By DPD On 14th Nov 2018 to your specified address. | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • UPS and DPD Pickup Pickup from local convenience store | £4.79

    Collect your parcel from your newsagents, petrol stations and convenience stores

ScanProtect
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

Product Overview Wave 2 AC Wi-Fi for More Bandwidth
With NitroQAM Technology, Archer C2300 boosts the Wi-Fi Speed up to 1625Mbps on 5GHz and 600Mbps on 2.4GHz. It can perfectly handle your favourite activities like gaming online, watching 4K movies, or sharing large files.

64-Bit CPU and XStream Processing for Smoother Performance
With XStream processor architecture, the Archer C2300 dedicates one processor to each of its Wi-Fi bands. These processors handle Wi-Fi traffic, freeing the router’s powerful 1.8 GHz dual-core 64-bit CPU to take care of everything else.

MU-MIMO and Smart Connect for Better Connections
MU-MIMO lets the Archer C2300 talk to several devices at once, and Smart Connect automatically places each device on the best available Wi-Fi band. With both working together, everyone can hop online at the same time without having to wait, and each device can always get the best connection.

RangeBoost for Far-Reaching Wi-Fi
RangeBoost amplifies the router's ability to detect and receive Wi-Fi signal from devices that are located farther away. Stream, game and enjoy what you love anywhere in your home, from your favourite spot on the couch to the comfort of your bed.

Media Sharing for More Fun
USB 3.0 and 2.0 ports make it easy to share photos, videos, and music on your home network.
When away from home, a VPN allows you to securely access NAS drives and other devices connected to the router through USB.

VPN Acceleration for Fast and Stable VPN
Archer C2300 is not only supporting safe and secure OpenVPN and PPTP VPN connection, but also using VPN Acceleration to boost the connection speed. All of the data you're transmitting is guaranteed to be secured by these VPN functions.

Intuitive Tether App for Easy Management
Setup and manage your Wi-Fi through the free TP-Link Tether app, available for both Android and iOS. Tether’s simple layout lets you quickly access all of your Wi-Fi settings on your phone or tablet.

HomeCare for Protection, Safety and Fast Wi-Fi
You don’t need to buy a separate security box device like Cujo or Circle to add security to your network. TP-Link HomeCareTM is powered by Trend MicroTM* and comes with antivirus, parental controls and QoS.

Antivirus
Every device that uses Wi-Fi is protected by HomeCareTM. That includes things that don’t normally have protection from cyber threats, like Wi-Fi cameras, smart locks and game consoles. It even protects devices that your friends use at your home.

Parental Controls
Whether you want to block websites, set time limits, see which sites your kids are using or pause the internet, you can with HomeCareTM. And you can do it all from the Tether app.

Prioritize What Matters
Choose which devices or activities you want to prioritize with Quality of Service (QoS). In just a few taps, you can make sure your laptop or streaming movie is first in line for Wi-Fi or Ethernet. Features • Faster Wi-Fi Speeds: Dual band speeds up to 2.25Gbps, 1625Mbps on 5GHz, 600Mbps on 2.4GHz.
• Powerful Processing: 1.8GHz Dual-Core Processor with co-processor.
• More Devices: MU-MIMO achieves 3X efficiency by communicating with up to 3 devices at once.
• Higher Efficiency: Beamforming technology delivers highly efficient wireless connection.
• Ultra Range: Range Boost + Power Amplifier + High-performance Antennas, giving you even greater coverage.
• Smoother Performance: Smart Connect intelligently assigns devices to the best available band.
• Better VPN Connection: OpenVPN & PPTP VPN server supported and VPN Acceleration speeds up VPN connection to ultra-level.
Specifications
Networking, Connectivity & Ports
Model Archer C2300
Form-Factor Desktop
Device Type Router
Compatible Internet Connections Cable-based Modems
Network Connectivity
  • 10/100/1000
  • Wireless LAN
Network Ports
  • 4 x RJ45 10/100/1000 (Gigabit) BaseT for LAN
  • 1 x RJ45 10/100/1000 (Gigabit) BaseT for WAN
Other Connectors
  • 1 x USB 2.0
  • 1 x USB 3.0
USB Applications
Wired Protocols
  • IPv4
  • IPv6
Total LAN Connections
Total WAN Connections
64 Bytes L3 Forwarding Performance
512+ Bytes L3 Forwarding Performance Unknown
Wireless
Wireless Speed N/A
Wireless Protocols
  • IEEE 802.11a
  • IEEE 802.11ac
  • IEEE 802.11b
  • IEEE 802.11g
  • IEEE 802.11n
Wireless Band Dual Band
Frequency
  • 2.4 GHz
  • 5 GHz
Operation Channel
Wireless Transmitter Power [email protected]: -69dBm, [email protected]: -56dBm
Antenna 3 External
Core Features
Features
  • DHCP Server
  • DynDNS
  • MU-MIMO
Router/Modem Processor Broadcom 1.8GHz Dual Core
Internal RAM Memory 512MB
Internal RAM Memory Type
Internal Flash Memory 128MB
LED Indicators
  • 1 x 2.4 GHz Wi-Fi LED
  • 1 x 5 GHz Wi-Fi LED
  • 1 x Internet LED
  • 1 x LAN LED
  • 1 x Power LED
  • 2 x USB LED
  • 1 x WAN Activity LED
Buttons
  • 1 x LED On/Off Button
  • 1 x Power Button
  • 1 x Reset Button
  • 1 x Wireless On/Off Button
  • 1 x WPS Button
OS Support
  • Linux
  • Mac OS
  • UNIX
  • Windows 10
  • Windows 2000
  • Windows 7
  • Windows 8
  • Windows 8.1
  • Windows Vista
  • Windows XP
Max. Power Consumption Unknown W
PSU Type
Security & VPN
Security Protocols
  • Access Control
  • DHCP server/client
  • Parental control
  • WEP
  • WPA
  • WPA-PSK
  • WPA-PSK2
  • WPA2
Firewall/NAT No
Management
VPN Support
Physical Specifications
Dimensions 216 x 36.8 x 164 mm (WxHxD)
Weight
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
24 months
Type:
Direct
DOA Period:
28 days
RTB Period:
12 months
Manufacturer Contact Details
Manufacturer:
tp-link
Telephone:
0845 147 0017
