tp-link 10/100MbE Desktop Switch with 8-Port PoE

8 PoE+ Ports (65W Total) for Network Deployment

Ports 1-8 support PoE, and each of them support a maximum of 30W, complying with the 802.3af/at Powered Devices standard. MS110P provides 2 ports without PoE+ for uplink devices, one of which is used to connect to the internet, and the other for NVR. The total 65W PoE power total fort the 8x PoE allow for a variety of uses, particularly for surveillance & small business management. IP cameras, access points, IP phones, PCs, video recorders are all compatible.

Long-Range up to 250m with Extend Mode

Extend Mode increases PoE transmission distance to 250m. MS110P has 8 long-range ports with PoE+, so enabling this setting makes it ideal for installing cameras over wide areas.

Durable & Silent

MS110P's durable metal case allows for efficient heat dissipation, excellent interference protection, equipment stability and long network life. It is silent in its operation and can be mounted to the wall.

Traffic Separation

With only one click, isolation mode divides traffic for ports 1-8 to prevent snooping/tampering and isolate broadcast storms for greater protection. MS110P provides 2× uplink ports when turning on the isolation mode.

Port Prioritisation

Prioritising the data of specific ports would ensure the high quality of delicate applications, such as voice and video, in crucial business domains.

PoE Auto Recovery

The switch continuously detects data transmission with PoE-powered devices (PD). When a PD stops sending data packets to the switch for an extended length of time, the switch will reboot it automatically.

Plug & Play

MS110P offers auto-negotiation (10/100 M) and automated MDI/MDIX. There is no additional configuration needed. It is simple to use and saves time and effort.

• 10 Ports: 10× 10/100 Mbps RJ45 ports with 8 PoE+ ports
•Two Cables in One: With 8 PoE+ ports, transfers data and power on one single cable
• High Power PoE+: Support PoE Power up to 30 W for each PoE port and 65 W for all PoE ports*
• 2× Uplink Ports: MS110P provides 2× uplink ports when turning on the isolation mode. One for connecting to the Internet and one for connecting to the NVR.
• Long-Range up to 250 m: Increases PoE transmission distance to 250 m by Extend Mode*
• Isolation Mode: One click to divide traffic for specific ports for stability and security
• Compliant with Powered Devices: Works with IEEE 802.3af/at compliant PDs
• Durable Metal Casing: Allows for efficient heat dissipation and long network life
• Plug and Play: Simple to use and saves time and effort
• PoE Auto Recovery: Automatically reboots your dropped or unresponsive PoE-powered devices
