Steinberg UR824 Ultimate Recording Package

Steinberg UR824 Ultimate Recording Pack

*Steinberg e-licencer included in box*
The Ultimate Cubase Recording Pack bundles the UR824 USB rack audio interface together with the latest version of Cubase Pro. The UR824 provides plenty connectivity through the eight TRS/XLR combo inputs and eight TRS outputs alongside two pairs of ADAT and wordclock I/O. Switchable high impedance on two inputs, pad attenuation, phantom power and two individual headphone buses with separate outputs and controls round out its impressive I/O capabilities. Inside the interface are eight D-PRE mic preamps and premium audio converters to ensure the utmost quality in sound alongside DSPs for latency-free monitoring with effects. Cubase Pro comes with a suite of 75 audio effects including the VST Amp Rack guitar tone suite, 18 MIDI VST effect processors and eight VST instruments, such as Groove Agent SE 5, HALion Sonic SE 3, the Padshop granular synth and Retrologue 2.

Steinberg UR824 USB Audio Interface
The UR824 interface conveys pristine, transparent audio quality through various analog and digital I/O formats, offering convenience for studio and stage alike. Connecting to Mac or PC via high-speed USB 2.0, the rackmountable UR824 boasts 24 channels with 8 premium D-PRE mic preamps alongside its dspMixFx technology for latency-free monitoring with effects, also available as native VST 3 plug-ins.

Inputs and outputs as far as the eye can see
The UR824’s front panel hosts two Neutrik combo TRS/XLR connectors for balanced microphone/line input with switchable 48 volt phantom power and Hi-Z, pad push buttons for signal attenuation, gain controls with peak indicators. On the right hand side there’s a single output level rotary knob that allows you to easily adjust the levels of the eight line output signals alongside two headphone connectors, each with a dedicated level control. The output signal to be controlled by the front panel rotary is selected through the software.
The rear panel provides six Neutrik combo TRS/XLR inputs and eight analog balanced TRS outputs as well as two pairs of optical ADAT inputs and outputs. Also on board are two BNC connectors for switchable word clock input and output. Developed by using advanced technologies to offer seamless scalability, this mixing and recording interface offers options to expand the number of analog inputs and outputs across the system via ADAT to provide up to 24 input and output channels.

Best setups for your gear
With its expanded I/O capabilities, the UR824 interface lets you hook up a vast number of equipment and instruments, the signals of which can also be fed via its high-speed USB 2.0 link to your computer for mixing and recording at a maximum audio resolution of 24 bits and 192 kHz.
And with the free update to version 2, the UR824 also works with the iPad or iPhone through Apple’s iPad Camera Connection Kit or Lightning to USb camera adapter allowing you to record up to four input channels in an iOS audio application, such as Steinberg’s iPad-based Cubasis app.

Excellent sound, swift workflow
The UR824 is a recording and production solutions for ambitious musicians and professional engineers alike. Connections required for studios such as word clock and ADAT plus a range of Neutrik combo connectors are at hand. Also on board are EQ and compression tools in the form of the Sweet Spot Morphing Channel Strips on each channel, not to forget the REV-X plug-in that provides quality reverb for modifying the intricacy of a sonic space. The UR824’s eight line outputs offer full support for surround productions up to 7.1.

Keep on rockin
The UR824 is a perfect solution for band recording. Mount the UR824 in your rack and with the range of channels and connectors, pick up all the band’s instruments and vocals and record and mix them in Cubase AI or your preferred DAW. For live rigs, the UR824 offers inputs and outputs over a variety of formats, the two pairs of ADAT of which provide additional I/O expansion capability. Connect either to two 8-channel mic preamps with ADAT outputs or two UR units in standalone mode to get a stunning 24 channels for recording an entire rock band setup.

iPad connectivity and free dspMixFx app
With the latest firmware updates, the UR824 introduces iPad connectivity and the free dspMixFx app alongside some other new features. Together with the UR824, the dspMixFx app allows you to utilize the benefits of Yamaha’s custom-designed SSP2 DSP chip directly on your iPad. The dspMixFx app provides latency-free monitoring while running the highly acclaimed REV-X reverb, the Sweet Spot Morphing Channel Strip and Guitar Amp Classics with other iOS audio apps.
