MSA Compliant 10 Gigabit Fiber SFP+ Transceiver Module - 10GBase-SR - MM LC - 300 m MSA Compliant 10GBase-SR SFP+ - MM 300m
Scan code: LN84449 Manufacturer code: SFP10GBSRST Request call
Pay on Scan Finance with a 10% deposit from just £6.62 / month (APR 15.9%)
High End
Delivery options £5.48 By DPD On 18th Dec 2017 DPD Delivered to your specified address. Receive SMS with one-hour delivery window. £4.79 Collect from local shops UPS and DPD Pickup Collect your parcel from your newsagents, petrol stations and convenience stores. Free Collect Instore Q-Collect Place your order online and collect from our Bolton store with Q-Collect. Weekend, timed and European delivery options are available at checkout ScanProtect protection ScanProtect Protect against installation damage for 28 days.More
Product Overview Add reliable and cost-effective 10 Gigabit Ethernet connections over multimode fiber, with this SFP+ module

This 10GBase-SR SFP+ module delivers what you need most in your network connections: reliable performance. It’s built to exacting MSA specifications and fully tested to ensure seamless compatibility. The multimode SFP+ transceiver module offers a cost-effective way to add, replace or upgrade the ports on your networking equipment, and it’s backed by a lifetime warranty.

Delivers 10 Gigabit Ethernet connections
With data transfer rates of up to 10Gbps and support for Digital Diagnostics Monitoring (DDM / DOM), this LC SFP+ module can be installed into fiber networking equipment with an MSA compliant port. It delivers dependable 10 Gigabit connectivity over multimode fiber for 10GBase-SR compliant networks, with a maximum distance of up to 300 m (984.2 ft.) and 850 nm optical wavelength.

Built for reliable network performance
This optical transceiver is engineered to meet or exceed the industry’s MSA (Multi-Source Agreement) standards. brings its established reputation for high-quality connectivity solutions to SFP transceivers, providing SFPs that match major OEM brands in performance and reliability. Committed to the highest standards, provides an extensive range of networking products including copper and fiber network cards, fiber media converters, Ethernet switches and wireless products.

Convenient and scalable
Delivering both convenience and scalability, this fiber transceiver is fully hot-pluggable, which enables you to install it without interrupting network traffic or having to reboot your equipment. It provides a versatile solution that’s compatible with a wide range of networking equipment, allowing you to expand your network to remote segments cost-effectively. Features • Delivers reliable 10 Gigabit connections for 10GBase-SR compliant networks
• Meets or exceeds MSA (Multi-Source Agreement) industry standards
• Supports multimode fiber (LC connector)
• Maximum distance up to 300 m/984.2 ft.
• Maximum data rates up to 10Gbps
• 850 nm optical wavelength
• Digital Diagnostics Monitoring (DDM/DOM)
• Hot-pluggable

Compatible Brand: MSA Compliant
Industry Standards: IEEE 802.3ae 10GBASE-SR
Compatible Networks: 10 Gbps
DDM: Yes
Fiber Operating Mode: Full-Duplex
Fiber Type: Multi Mode
Max Transfer Distance: 300 m (984 ft)
Maximum Data Transfer Rate: 10 Gbps
Wavelength: 850nm
Local Unit Connectors: 1 - Fiber Optic LC Duplex Female
Humidity: 5~95% RH
Operating Temperature: 0°C to 70°C (32°F to 158°F)
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
Physical Characteristics
Colour: Silver
Enclosure Type: Aluminum
Product Height: 0.5 in [12.6 mm]
Product Length: 2.3 in [58.4 mm]
Product Weight: 0.7 oz [20 g]
Product Width: 0.5 in [13.9 mm]
Form Factor
Total Network Ports
PoE Support Type
No. of Ports Providing PoE
Other Non-Network Ports
Switching Capacity
Non-Blocking Throughput
Forwarding Rate
MAC Address Table Size
Network Capacity
Built-in Flash Memory
RAM Memory
Network Protocols
Acoustic Noise
Max. Power Consumption
Max. PoE Wattage per Port
Mean Time Between Failures (MTBF)
Power Supply
Dimensions (WxHxD)
