Scan code: LN91569 Manufacturer code: RAVEN MTi2

Slate Media Technology RAVEN MTi2

Slate Media Technology RAVEN MTi2 27" Multi-Touch Control Surface, 10-Point Touch, Completely LED Backlit

Thumbnail 1 : Slate Media Technology RAVEN MTi2 Thumbnail 2 : Slate Media Technology RAVEN MTi2 Thumbnail 3 : Slate Media Technology RAVEN MTi2 Slate Media Technology RAVEN MTi2 : video thumbnail 1
Scan code: LN91569 Manufacturer code: RAVEN MTi2
£949.00Item overdue since 15 November 2018
Pre order
Free Delivery
From £45.55 / month (APR 14.9%)
Monthly Payment: £164.68
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £949.00
Total inc. interest: £988.04
Monthly Payment: £85.20
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £949.00
Total inc. interest: £1,022.33
Monthly Payment: £58.75
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £949.00
Total inc. interest: £1,057.37
Monthly Payment: £45.55
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £949.00
Total inc. interest: £1,093.23
If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 17.9% and may be even lower.

Representative Example:

Purchase Rate: 17.9% p.a. (variable)

Representative: 17.9% APR (variable)

Assumed Credit Limit: £1,200

Subject to status. Terms and Conditions apply.
With a 10% deposit from just £23.70 / month (APR 15.9%)
Delivery Options
  • By DPD to your specified address. | Free Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

ScanProtect
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

Product Overview In the past decade, the technological revolution has transformed audio into a medium that is produced and delivered in the digital domain. Powerful Digital Audio Workstations have transferred the entire recording studio into a virtual environment where all elements of the studio appear conveniently on a computer screen. But what has been lacking with the modern digital studio is the same powerful workflow as what was accomplished on tactile mixing consoles. So back in 2012, Slate Media Technology came up with a solution.

If the entire production studio was on a computer screen, why not turn the actual computer screen INTO a world class control surface? And the RAVEN series of Multi-Touch consoles was born. Soon the RAVEN would be the preferred control surfaces of major studios, engineers, producers, artists, and educational institutions like Mark Needham, Terry Lewis, Will.i.am, Jimmy Douglas, Full Sail University, and SAE.

Now in 2015, we are proud to offer the newest addition to the RAVEN series, the MTi2. The MTi2 has all of the powerful features of its predecessors, but at a cost that is the same as most regular high end 27" computer monitors!

The RAVEN MTi2 is a state of the art 27” Multi-Touch Production Console featuring a state of the art multi-touch panel and the powerful new RAVEN 3.0 Control Software. Using the RAVEN MTi2, users have access to multi-touch faders, pans, sends, and tweak plugins with their fingers as if they were real hardware. The RAVEN 3.0 Control Software also features a user-customizable multifunction TOOLBAR and the award winning BATCH COMMAND SYSTEM, a powerful automated task application that will save audio engineers hours per day by cutting out tedious technical tasks.

RAVEN 3.0
With the introduction of RAVEN 3.0, we have taken the already game-changing RAVEN software to a new level by adding compatibility with EVERY MAJOR DAW.

RAVEN 3.0 now adds customised multi-touch control of Ableton Live, Cubase/Nuendo, Digital Performer, Logic Pro X, Protools 10-12, and Studio One V3 on Mac as well as our first PC compatibility for Protools 10-12. The 3.0 update demonstrates exactly why the RAVEN is so groundbreaking: through real time interaction we have the ability to code our way to any fix or enhancement, and RAVEN has continued to evolve.

The RAVEN Toolbar
In Toolbar mode, the RAVEN Toolbar is anchored directly in front of your hands at the base of the touch display. Your DAW controls are where you want them: Transport, Edit/Mix window selector – convenient tools for tracking too, like Record Looping, Click, Create Group, and Undo. Use intuitive multi-touch gestures on the RAVEN NAVPAD to perform Scrub/Shuttle, Waveform Zoom, Track Zoom, and Track Banking, and RAVEN Batch Commands. Best of all, because the RAVEN Toolbar is virtual, it's user-customizable – put the controls you want where you want them.

The Batch Command System
The RAVEN Batch Command System is a true revolution in control. The BCS is a series of preset and customizable buttons that can execute up to 1,000 key commands and mouse clicks automatically. With just one button, BCS allows you to create instant headphone sends, name tracks, put entire drum tracks on the grid, export stems, and so much more! The BCS comes pre-programmed with 100 preset batch commands in every DAW we support, with layouts for Music, Mastering, Post Production and more. Record your own mouse click automation or program user commands with our QUICKLIST, which features hundreds of predefined DAW operations. Just touch and hold on a Batch Command button to edit, and you'll have access to almost limitless possibilities. With the Batch Command system you'll get it all done faster and smarter.

Slate Remote
Slate Remote revolutionises your workflow in ways you must experience to believe. Slate Remote is a free app for iOS users, available at the app store to anyone with a Raven MTi2. Slate Remote automatically synchronizes with your Raven session via wifi network and gives you access to your custom batch Commands, allowing it to remotely perform time-saving tasks for you from the palm of your hand.

FADERS 3.0
FADERS 3.0 are our newest multi-touch faders that allow the most precise control of your DAW faders. By integrating multi-touch 100mm virtual faders directly into each DAW, the engineer has seamless control over mix levels and automation.

The new 3.0 algorithm gives the faders a virtual 'feel' that allows an intuitive feeling action that is comfortable and even fun to use. And for the most critical automation, FINE FADER mode can quadruple the resolution of the faders so you can get even the most minute moves down in the first pass with ease and perfection.

The RAVEN MTi2 is the most affordable way to turn your DAW into a world class control surface that will take your workflow into the 21st Century. Features Screen
• iLok2 Required
• State-of-the-art 27" multi-touch display HD resolution of 1920×1080
• Completely LED backlit to consume less power and emits less EMI
• 10-touch display allows various multitouch features like fader control and more instant integration with most major DAWs
• Gives you hands-on control of all your DAWs parameters as well as acts as your computer’s main touch-capable display
• Flexible and user-customizable, multifunction TOOLBAR
• Easy compatibility using a standard HDMI cable and a USB 2.0 connection
• All Major DAWs For RAVEN are currently supported with MAC OS X and Pro Tools 10, 11, 12 & 2018 as well as Cubase 8, 9 & 9.5 and Nuendo 7 & 8 are all supported for Windows

Compatible DAWs:
• Pro Tools 10, 11, 12 & 2018 - Mac & Windows
• Logic Pro X - Mac Only
• Cubase 8 , 9 & 9.5 - Mac & Windows
• Nuendo 7 & 8 - Mac & Windows
• Digital Performer 8 & 9 - Mac Only
• Ableton Live 9 & 10 - Mac Only
• Studio One 3 - Mac Only

PLEASE NOTE: RAVEN Hardware comes with your choice of one supported DAW. Additional DAW support licenses can be purchased for a nominal fee from the Slate MT Store.

Required for Use:
• Computer with USB 2.0 connection
• Standard VGA cable (included) or HDMI cable (not included)
• Uses industry-standard V-control pro
• No Ethernet or MIDI Required
• iLok 2 or 3 Dongle (not included)

Minimum Mac Mini/MacBook Pro Requirements:
• i5 Processor or Greater
• Intel HD 4000 Graphics Card (512MB VRAM)
• 4GB RAM
• Minimum Mac Pro Requirements:
• OS X 10.7 (Lion), 10.8 (Mountain Lion), 10.9 (Mavericks)
• 2.5Ghz Xeon Processor
• Intel HD 4000 Graphics Card (512MB VRAM)
• 4GB RAM
• Note: Quality of your graphics card is very critical to the quality of your RAVEN's performance.

Power Supply:
• The Raven MTi2 comes with an outboard 12 volt/3.3 amp power supply.
• The power supply accepts 110v-220v AC input.
• 2.1mm x 5.5mm barrel connector, center pin positive.
Specifications
Product Type
PC Interface N/A
Assignable Faders
Assignable Knobs
Assignable Pads
Keys
Wheels
Connectivity (Input)
Connectivity (Output)
Sample Rate
Bit Rate N/A
Frequency Response (Input) N/A
Frequency Response (Output) N/A
Maximum Input Level N/A
Maximum Output Level
Dynamic Range
Dimensions (mm)
Misc. Notes
Package Type
Warranty
