Scan code: LN62744 Manufacturer code: SST-SG13B

Silverstone Sugo SG13B Mini ITX Cube Case

Silverstone Sugo SG13B Cube Mini-ITX/DTX Case (ATX PSU)

MORE INFO
MORE INFO
Thumbnail 1 : Silverstone Sugo SG13B Mini ITX Cube Case Thumbnail 2 : Silverstone Sugo SG13B Mini ITX Cube Case Thumbnail 3 : Silverstone Sugo SG13B Mini ITX Cube Case
Scan code: LN62744 Manufacturer code: SST-SG13B
£39.98
Add To Basket
In stock
Order now and receive it by Tuesday, 3rd August
spend over £280 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
Delivery Options
  • By DPD On 3rd Aug to your specified address. | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • UPS and DPD Pickup Pickup from local convenience store | £4.79

    Collect your parcel from your newsagents, petrol stations and convenience stores

Services
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

  • 48HR REPLACEMENT If you need to return this item, your replacement will be dispatched within 2 working days of your product arriving back at Scan. More info
Frequently Bought Together
Product Overview

Newly Evolved Design

After bringing Mini-ITX into mainstream DIY (do it yourself) market in 2009 with the Sugo SG05, SilverStone is looking to define the category again with SG13, a newly evolved design that aims to satisfy every type of computer users. At only 11.5 liters in size, it has suitably small statue for easily integrating into numerous computing environments and will comfortably fit many standard components for general purpose or office builds. For enthusiasts and in keeping with Sugo series’ famed tradition, the SG13’s ability to fit 10.5” long expansion card, standard ATX power supply, and all-in-one liquid cooler in 120mm or 140mm size will help produce amazingly small and powerful systems.

Features
Special Features
• Support standard-length expansion cards (10.5 inches).
• Mini-DTX / Mini-ITX motherboard & ATX PSU compatible.
• Support 120mm or 140mm single fan All-in-One Liquid Cooler.
• Support 2.5” and 3.5” hard drives.
• Elevated standoff for motherboard back side components.

Technical Specifications
• Model No. SST-SG13B (black, mesh front panel).
• Material Mesh or plastic front panel, steel body.
• Motherboard Mini-DTX, Mini-ITX.
• Internal 3.5" x 1 or 2.5" x 2 , 2.5" x 1.
• Cooling system Front 1 x 120mm/140mm fan slot compatible with radiator(option).
• Side Oversized vents.
• Top Oversized vents.
• Radiator support Front N/A.
• Rear 120mm x 1.
• Top N/A.
• Bottom N/A.
• Expansion slot 2.
• Front I/O port USB 3.0 x 2.
• audio x 1.
• MIC x 1.
• Power supply Optional standard PS2(ATX).
• Expansion card Compatible up to 10.5" (266mm) long, width restriction-5.11" (129mm).
• Limitation of CPU cooler 61mm.
• Limitation of PSU 150mm*.
• Net weight SG13B:2.47Kg / SG13B-Q:2.43Kg.
• Dimension 222mm (W) x 181 mm (H) x 285 mm (D) 11.5 litres.
Specifications
Core Chassis Specifications
Case Edition SG13
Case Form Factor Mini-ITX
Motherboard Form Factor
  • Mini-DTX
  • Mini-ITX
I/O, Bays & Expansion
Front/Side/Top Panel I/O
  • 1 x Headphone Out
  • 1 x Mic In
  • 2 x USB 3.0
Drive Bays
  • 1 x 2.5" Internal
  • 2 x 2.5"/ 3.5" Internal
Standard Expansion Slots 2
Vertical Expansion Slots
Fans & Filters
Fan Bays 1 x 120/140mm
Fans Included None
Fan Controller/Hub
Dust Filters
Liquid Cooling Support
Front Radiator Compatibility
Top Radiator Compatibility
Bottom Radiator Compatibility
Rear Radiator Compatibility
Side Radiator Compatibility
Clearances
Max CPU Cooler Height 61 mm
Max GPU Card Length mm
Cable Routing Space
Side Panels
Window/s No
Window Configuration
Window Construction
LED Lighting Functionality
LED Lighting No
LED Lighting Emitters
LED Lighting Colour
LED Lighting Support & Control
Power Supply Compatibility
PSU Included No
PSU Wattage (If Included)
PSU 80+ Rating (If Included)
PSU Support ATX
PSU Mounting Location
Max PSU Length
Chassis Physical Specifications
Colour
Chassis Contruction Materials Steel
Dimensions
Weight
Please Note
Additional Information
Scan Code LN62744
Model Number SST-SG13B
GTIN 4710007221983
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
24 months
Type:
Return to base
DOA Period:
28 days
RTB Period:
12 months
Manufacturer Contact Details
Manufacturer:
SilverStone Technology GmbH
Telephone:
Carsten Buss Tel.: +49 40 675931-35
Loading Please Wait

Please wait . . .

TekSpek Guides
Computer Cases
Computer Cases
Date Issued: 6th Jul 2011

There's more choice than ever before, but which computer case is right for you and which features should you look out for?

Read More

Chassis Airflow
Chassis Airflow
Date Issued: 20th Oct 2008

The modern PC is potentially a mass of heat output and heat production hot spots. With CPUs rated at more than 100W of heat output, single graphics boards carrying similar ratings (and people want to run two!), multiple hard drives the norm, lots of memory and mainboards covered in heatpipes to combat toasty core logic and PWM circuits, a PC appreciably warming up a room when it’s working hard is no joke.

Read More

Silverstone Sugo SG13B Cube Mini-ITX/DTX Case (ATX PSU) is rated 4.8 out of 5 by 4.
Rated 5 out of 5 by from Brilliant SFF case for the money! I bought this case to replace a Kolink Rocket SFF case I was using that was making my GPU too hot for my liking. The SG13 from my experience building, was a very pleasant case to work with, and fit my components inside quite easily without much fuss. I opted to go for an air cooled build, using a 120mm intake, Noctua 120mm low profile CPU cooler, and a Noctua 92mm fan zip tied to exhaust warm air out of the side vent next to the motherboard. So far my CPU temps are a tad higher at idle compared to my old case, but my GPU temps are much improved! Very happy with the performance and quality of this case, especially for the price. There are no tool-less features and removing the front panel is a bit fiddly, but all the components and screws are good quality. My build: Ryzen R5 3600 Geforce RTX 2070 Super Founders Edition Noctua NH-L12S CPU cooler Corsair SF750 SFX power supply (using an ATX to SFX adapter to fit the back panel of this case, this gives an extra 20mm clearance for the CPU cooler for a total of 80mm clearance, vs 60 allowed by an ATX power supply, this was key to allowing the Noctua cooler, which performs very well)
Date published: 2020-02-16
Rated 5 out of 5 by from Brilliant case for a tiny ITX build I bought this case after a lot of research on mITX cases. Many of them seemed rather large and defeated the point of a tiny but powerful PC. The Sugo provided exactly what I was after. The case itself is pretty attractive in metal and black plastic, with a mesh panel on the front. There is a lot of space inside and you can remove the various parts including the mounts for HDDs/SSDs and the PSU bracket. It will possibly fit a full size ATX PSU but this may also foul on any CPU cooler. I had gone for a Corsair H80i and the pipes on this were pushing too much against my PSU so I added an SFX one instead. There is room for a large GPU but be sure to check sizes. The outer shell has been very cleverly designed with a large grill that should line up with the fans on most GPUs, allowing it to pull in air from outside. Of course this means no dust filtration. I was able to fit the aforementioned cooler into the front of the case, it will also fit a 140mm fan there but this will take away room for the GPU. I did use an m.2 drive for my build which greatly reduced cables needed, so I can't comment on the ease of fitting in 2.5" or 3.5" drives. All in all, a very nice and very well priced case for a tiny build. Quality is high for what you are paying, and it wasn't difficult to work with. I would always suggest a modular PSU and be careful with any all in one coolers as the pipes do need to have some space when you bend them round.
Date published: 2016-12-22
Rated 5 out of 5 by from A great replacement/substitute for my old case! I bought this case as I was getting a few heat issues in my Lian Li TU100. The problem with the Lian Li, is that there is little space for the graphics card to vent, and I haven't found a blower-style mini-itx card that could have solved the problem. So I decided that I would get a new case either as a replacement, or as somewhere to house my system while I mod the Lian Li. Well, I have to say that it might take me a while to make the effort with the TU100, because this case is fantastic! My GPU is running under 30 degrees idle, and barely hits 75 under load! This case is easy to install in, and even has room for all-in-one liquid solutions. For around £35, this case is brilliant for a small-size high power system. Buy it!
Date published: 2016-01-13
Rated 4 out of 5 by from Great Case for price but not perfect It allows for a lot of potential and can fit most hardware inside at an itx form factor. A liquid cooler fits perfectly. The only bad points are the case, i think dust filters should be on all vents as there is a lot of open vents and with such a small space and being annoying to clean, it would help greatly. The only other bad thing is that its not the best one on the market, there are some others with similar cooling, filter and hardware capability and options but have extra features and slightly better placement of things inside. However i do not think this is bad, for the price, its good.
Date published: 2015-06-19
  • y_2020, m_9, d_10, h_15
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.12
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_4
  • loc_en_GB, sid_62744, prod, sort_[SortEntry(order=FEATURED, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_scan

Will there be enough clearance for a h90 and SSD

I will be mounting my SSD onto the floor of the case so I am unsure whether my MSI gtx 770 and SSD will interfere with the radiator.
Asked by: BinaryJava
I've not seen someone use the bottom SSD mount AND an AIO liquid cooler before, but I would suggest that you consider bodging it a bit. As SSDs have no moving components, you don't have to worry about shock damage. So get yourself some stick on Velcro and pop the SSD wherever you can find space! There will be a way.
Answered by: Ben1092
Date published: 2019-09-10
