Sennheiser XSW-D Portable Eng Set
Sennheiser XSW-D Portable Eng Set, 2.4Hz, 5 Hours Battery Life
- SCANPROTECT Protect against installation damage for 28 days. More info
Sennheiser - 'XSW-D' Portable Eng Set
2.4 GHz transmission for
worldwide operationXS Wireless Digital. Like any classic romance, it’s elegant to see, complex in theory, but intuitive in action. These might sound like strong words for a wireless solution to your audio needs, but like any love story, you know it when you experience it. It’s an instant connection...
XS Wireless Digital is essentially a cable replacement. It works digitally, using a 2.4GHz transmission to create a wireless peer-to-peer connection.
≥ 106dBSignal-to-noise ratio
2,400 - 2,483.5MHzFrequency range
<0.1 %THD
at a glance
• One touch ease-of-use
• 2.4 GHz digital transmission for worldwide operation
• 75m range (250ft) in optimal conditions
• Up to 5 hours battery life on a single charge
• Switch between multiple transmitters linked to one receiver
• Configure any combination of transmitters and receivers
• Mute from either transmitter or receiver
Empower your Inner Creativity
reliable connectionFreedom. With a simple touch of a button, step away from the cables and maintain a faithful connection. As a liberating solution for the musician moving about on stage, or a convenient approach to practicing in the rehearsal room, XS Wireless Digital empowers your inner creativity by allowing you to roam free.
It means interacting with the crowd like you never have before and enables you to take your performance to the next level. It’s the power to turn audio limitations into audio opportunities.
Frankly, it’s a simple but versatile tool that means more than Sennheiser had the time to discover. It works, and if you’re looking to change your relationship with cables and frequencies, then you need to try it out.
Enjoy Wireless Freedom!
no obstacles - no distractionsA good connection doesn’t require being tied down. Wireless means no obstacles, no distractions, just effortless audio, every time. As a liberating solution for the musician moving about on stage, or a convenient approach to practicing in the rehearsal room, XS Wireless Digital empowers your inner creativity by allowing you to roam free. Lose the cables but keep the connection.
One touch ease-of-useIt’s simple, each XS Wireless Digital has only one button. Press to power up and link simultaneously, click once to mute, and hold to power down. It’s as easy as plugging in a cable, minus the cable part.
The Tech Spec
| Features | Specification | Input voltage | typ. 5.0 V |
|---|---|
| Charging temperature | 0 °C - 60 °C (32 °F - 140 °F) |
| Charging time | typ. 3 h |
| Cell type | Li-Ion |
| Nominal voltage | 3.7 V |
| Cell capacity | 850 mAh |
| Operating time | up to 5 h |
| Codec | aptX® Live |
| Audio frequency response | 3.5 mm Jack/XLR: 80 - 18,000 Hz 6.3 mm Jack: 10 - 18,000 Hz |
| Audio output | max. 12 dBu |
| Signal-to-noise ratio | ≥ 106 dB |
| THD | < 0.1 % |
| Audio latency | < 4 ms |
| Frequency range | 2,400 - 2,483.5MHz |
| Transmission power (EIRP) | max. 10 mW |
| Modulation | GFSK with TDMA |
| Operating temperature | -10 °C to +55 °C (14 °F to 131 °F) |
| Relative humidity | 95 % (non-condensing) |
