Roland BRIDGE CAST ONE
Roland BRIDGE CAST ONE, Compact Dual Bus Streaming Mixer
Compact Dual Bus Streaming Mixer
Roland - Bridge Cast One
Pro Sound, Simple OperationLevel up your gaming and streaming sound with BRIDGE CAST ONE, a compact livestreaming audio mixer with hands-on controls. Gain a competitive advantage with powerful features like dual bus mixes, vocal transformer effects, fast-access presets, and support for a broadcast-grade mic and headphones. For even more control, the companion BRIDGE CAST app offers extended audio tools and royalty-free background music and sound effects through BGM CAST on Roland Cloud.
at a glance
• Compact desktop streaming interface with core BRIDGE CAST audio features
• Powerful 32-bit hardware DSP allows you to dedicate all your computer resources to gaming and streaming
• Create independent mixes for you and the online audience with dual audio busses
• USB-C connectivity with Windows and Mac computers, the Sony PlayStation®5 console, and Nintendo Switch
• High gain (+75 dB) XLR microphone preamp with phantom power for broadcast-grade mics
• Mic rehearsal feature for fast and easy audio setup
• High-quality vocal processing: EQ, compressor, noise suppressor, de-esser, and reverb
• Headphone jack with a professional high-sensitivity output and support for a headset or inline mic
• 5.1 or 7.1 USB virtual surround sound audio and 10-band EQ**
• Enhance your gaming performance with five customizable Game Effects presets
• Game effects limiter to lower loud game sounds
• Voice transformer effects derived from the Roland VT series
• Delay function to synchronize audio with video when needed
• Aux input for playing audio from a smartphone or external device
Upgrade Your Streams with Enhanced Sound Quality and Real-Time Controls
BRIDGE CAST ONE OverviewWatch how the streamlined audio tools in BRIDGE CAST ONE make it easy to upgrade your streams with enhanced sound quality and real-time controls.
Compact Audio Command Center
50 years of Roland AV technologyWith BRIDGE CAST ONE, your online sound is always on par with your gameplay. Backed by 50 years of Roland AV technology, it gives you all the essentials for mixing streams with professional quality. Sleek, multi-function controls provide instant access to vital functions, supported by a deep selection of extended tools in the BRIDGE CAST app.
Pro Microphone Support
rich, dynamic soundA great mic is key if you want to sound like a pro. Chat and broadcast online with crystal-clear audio using a high-quality dynamic or condenser microphone connected to the XLR input. The onboard preamp delivers rich, dynamic sound, eliminating the need for external preamps or costly mic activators.
Set up is simple with mic rehearsal mode—just follow the quick-start guide in the app. It’s also possible to connect a headset mic via the mini headphone jack.
Cutting-Edge Sound Tools
crystal clear audioThe pro audio tools in BRIDGE CAST ONE mean you’ll always keep your audience engaged and your teammates aligned. Quickly manage game sounds and chat audio with a single multi-function knob.
Stream clear sound with EQ, compression, noise suppression, and other tools. Add spaciousness with a high-quality reverb effect.
Fine-Tune Game Audio
make it yoursEnhance game sounds and dominate your competition with customizable Game EQ presets. Call up a custom mix highlighting crucial audio elements, or craft a distinct stream mix to boost your online interaction. A limiter also automatically lowers loud game sounds like gunshots and explosions, reducing ear strain during long sessions.
Virtual Surround SoundEnvelop yourself in your adventures with 5.1 or 7.1 virtual surround sound for headphones and stereo speaker systems, powered by advanced Roland technology. Audio is converted from a PC to virtual surround sound via a USB connection, providing a powerful and immersive sound experience. Use the BRIDGE CAST app to customize the virtual speaker angles and effortlessly shape your sound.
BGM CAST: Curated Music & Sound Effects
maximum personalisationWith BGM CAST, adding background music and sonic color to streams has never been easier. Available through the BRIDGE CAST app and Roland Cloud, BGM CAST puts a growing selection of royalty-free background music and sound effects at your fingertips. Choose music by mood and genre or create playlists of your favorites for stress-free music management. You can also assign sound effects to the BRIDGE CAST ONE hardware buttons for instant triggering.
A free Roland Account provides 36 background music tracks and 16 sound effects to use at no charge. Signing up for Roland Cloud Core membership through the BRIDGE CAST app unlocks thousands of additional music tracks and hundreds of sound effects, with new selections added each month. Membership also includes powerful tools for modern music creators, including the ZENOLOGY synthesizer, Zenbeats production software, Sound Packs, and more.
The Tech Spec
| Features | Specification | Input Channel | MIC AUX USB CHAT (*1) USB GAME (Speakers) (*1) USB MUSIC (*1) USB SYSTEM (*1) USB CONSOLE (Speakers) (*2) (*1) When the USB port connection setting is "PC" (*2) When the USB port connection setting is "CONSOLE" |
|---|---|
| Output Channel | LINE OUT PHONES AUX (*3) USB MIC (*4) USB STREAM (*4) USB PERSONAL (*4) USB CONSOLE (Microphone) (*5) (*3) Microphone audio is output from the CTIA MIC jack (*4) When the USB port connection setting is "PC" (*5) When the USB port connection setting is "CONSOLE" |
| Audio Mixing Bus | 2 (STREAM MIX, PERSONAL MIX) |
| Sampling Frequency | Windows: 44.1 kHz, 48 kHz, 96 kHz macOS/Other: 48 kHz |
| Signal Processing | AD/DA: 24 bits Internal Processing: 32-bit Floating point |
| Effects | MIC: Voice Changer, Noise Suppressor, Compressor, Equalizer, De-esser, Reverb, Low Cut CHAT: De-esser, Compressor GAME/AUX (*6): Equalizer, Limiter, Virtual Surround STREAM: Delay (*6) Select with GAME EFFECTS setting |
| Audio File Player | Number of tracks: 2 Data Formats: WAV (Linear PCM, 48 kHz, 16 bits, stereo/mono) Maximum Time: 5 seconds/track |
| Input Level | MIC: -85-- -10 dBu (Maximum: +2 dBu) HEADSET MIC: -58.5-- -20.5 dBu (Maximum: -8.5 dBu) AUX: -10 dBu (Maximum: +2 dBu) |
| Input Impedance | MIC: 3.4 k ohms HEADSET MIC: 1.3 k ohms AUX: 10 k ohms |
| Output Level | LINE OUT: -4 dBu (Maximum: +8 dBu) HEADSET: +1 dBu (Maximum: +13 dBu) HEADSET: 78 mW + 78 mW (32 ohms) HEADSET: 35 mW + 35 mW (250 ohms) |
| Output Impedance | LINE OUT: 1 k ohm HEADSET: 10 ohms |
| Connectors | MIC jack: XLR type (Phantom power DC 48 V, 6 mA Max) HEADSET jack: Stereo miniature phone type (CTIA, PLUG-IN power) AUX jack: Stereo miniature phone type (TRRS) LINE OUT jack: Stereo miniature phone type (TRS) USB port: USB Type-C (R) (Audio/MIDI/HID Supported) |
| Power | USB bus power * Connect to a USB connector that can supply 5 V, 900 mA or more. |
| Operating System | Microsoft Windows 10, Windows 11 Apple macOS 12 or later * Although Roland has tested numerous configurations, and has determined that on average, a computer system similar to that described above will permit normal operation of the BRIDGE CAST ONE, Roland cannot guarantee that a given computer can be used satisfactorily with the BRIDGE CAST ONE based solely on the fact that it meets the above requirements. This is because there are too many other variables that may influence the processing environment, including differences in motherboard design and the particular combination of other devices involved. |
| Accessories | Leaflet "Read Me First" USB 2.0 Type-C to Type-C Cable (2 m, 6.5 feet) |
| Width | 111 mm |
| Depth | 109 mm |
| Height | 56 mm |
| Weight | 275 g |
