RCF Digital active speaker system 15"" + 4"" v.c., 700Wrms, 1400Wpeak
RCF - ART 745-A MK4 - 15" 2-Way 1400W Active Speaker
Email me when the availability or price changes
- SCANPROTECT Protect against installation damage for 28 days.
15" 2-Way 1400W Active Speaker
RCF - ART 745-A MK4
PROFESSIONAL ACTIVE TWO-WAY SPEAKERThe ART 745-A MK4 is the flagship speaker in its category. The titanium dome, 4.0” voice coil neodymium compression driver offers a unique vocal clarity and sound projection. The 15” neodymium woofer offers an extremely linear response and a precise, deep low frequency control. The transducers are produced using the most advanced assembly technologies. The amplifier delivers 1400 watts and is controlled by a DSP that takes care of crossover, equalisation, phase control, soft limiting and speaker protections.
New perspective on linearityRCF speakers are designed using a proprietary and advanced digital FiR technology, conceived to deliver transparent sound, absolute clarity, and perfect imaging to the listener.
The special FiRPHASE filters allow for coherent distribution of sound for all listeners without phase distortions, ensuring minimum latencies in the system.
133 dBMax SPL
45Hz - 20kHzFrequency Response
15"LF Driver
at a glance
• 1400 WATT 2-way peak power
• 1.4" Titanium Compression Driver, 4.0" v.c. Neodimium
• FiRPHASE Technology
Superior Compression Drivers
high-temperature kapton formerThe RCF Compression Drivers in pure Titanium are perfect for a crossover point lower than 650 Hz. This allows a better impulse response, fast decay and superior efficiency. Lightweight and powerful, our neodymium drivers are a reference in performance and reliability.
The voice coil features a high-temperature kapton former. The assembly process takes advantage of the RCF proprietary Direct Drive technology. The diaphragm’ s suspension has been designed following extensive studies aimed at minimising distortion and extending low frequency range.
Red Dot Design Award Winner
Powerful class D amplifiersRCF's Class-D power amplifier technology packs huge performance operating with high efficiency into a lightweight solution. ART 7 amplifiers deliver ultra-fast attack, realistic transient response and impressive audio performance. The amplifier features a solid mechanical aluminum structure which not only stabilises the amplifier during transportation but also helps the fan-less heat dissipation.
Bring ART with youThe RCF ART 7 Series has earned the prestigious international Red Dot Design Award in the Product Design category. Receiving the renowned Red Dot acts as proof of the excellent design achievements of professionals and up-and-coming talent alike, thus symbolising a seal of quality.
The Tech Spec
| Features | Specification | Configuration | Active 2-Way |
|---|---|
| Total Power Capacity | 1400 W Peak 700 W RMS |
| Amplifier Power Rating | HF: 400 W Peak 200 W RMS LF: 1000 W Peak 500 W RMSs |
| Amplifier Class | Class-D |
| HF Driver | 1 x 1.4" / 36 mm Titanium |
| HF Voice Coil | 4" / 10.2 cm |
| LF Driver | 1 x 15" / 381 mm Woofer |
| LF Voice Coil | 3.5" / 88.9 mm |
| Frequency Response | 45 Hz to 20 kHz -3 dB |
| Maximum SPL | 133 dB |
| Coverage Angle | 90° H x 60° V |
| Input Sensitivity | Line Input: +4 dBu to -2 dBu Mic Input: -32 dBu |
| Protections | RMS, Thermal |
| Audio I/O | 1 x XLR 3-Pin Balanced Input 1 x 1/4" TRS Balanced/Unbalanced Input 1 x XLR 3-Pin Male Balanced Output |
| Crossover | 650 Hz |
| Mounting | 2 x M10 Pole Socket |
| Handles | 1 x Top 2 x Side |
| Dimensions | 27.9 x 17.2 x 15.3" / 708 x 437 x 389 mm |
| Weight | 41.5 lb / 18.8 kg |
