Scan code: LN99042 Manufacturer code: TS-EC1680U-E3-4GE-R2/192TBEXOS

QNAP 16 Bay Desktop NAS Enclosure

QNAP 16 Bay TS-EC1680U-E3-4GE-R2 NAS 3U Rackmount, 4GB DDR3, Intel Xeon, 24TB HDD, PCIe 3, 10GbE SFP+, USB 3.0

Thumbnail 1 : QNAP 16 Bay Desktop NAS Enclosure Thumbnail 2 : QNAP 16 Bay Desktop NAS Enclosure Thumbnail 3 : QNAP 16 Bay Desktop NAS Enclosure Thumbnail 4 : QNAP 16 Bay Desktop NAS Enclosure
Scan code: LN99042 Manufacturer code: TS-EC1680U-E3-4GE-R2/192TBEXOS
£9,598.99Item currently awaiting an ETA
Pre order
From £460.74 / month (APR 14.9%)
Monthly Payment: £1,665.65
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £9,598.99
Total inc. interest: £9,993.88
Monthly Payment: £861.73
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £9,598.99
Total inc. interest: £10,340.76
Monthly Payment: £594.19
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £9,598.99
Total inc. interest: £10,695.37
Monthly Payment: £460.74
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £9,598.99
Total inc. interest: £11,057.71
If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 19.9% and may be even lower.

Representative Example:

Purchase Rate: 19.9% p.a. (variable)

Representative: 19.9% APR (variable)

Assumed Credit Limit: £1,200

Subject to status. Terms and Conditions apply.
With a 10% deposit from just £239.73 / month (APR 15.9%)
Delivery Options
  • By DPD to your specified address. | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

Product Overview

16-bay High Performance Unified Storage With Built-in 10GbE

QNAP TS-EC1680U R2, featuring the easy-to-use QTS operating system, provides a reliable and scalable NAS solution to fulfill data backup, file synchronization and remote access. The TS-EC1680U R2 is 10GbE-ready, delivers exceptional performance, and supports cross-platform file sharing, comprehensive backup solutions, iSCSI and virtualization applications, and many practical business functions, making it the ideal choice for SMBs to secure important business data. It also includes abundant multimedia applications backed by its powerful hardware specifications.


QTS - Simple and Efficient

Thanks to QTS’s intuitive user interface, system operations of the TS-EC1680U R2 are smooth and handy. Its intelligent desktop allows you to find the desired functions quickly, create desktop shortcuts or group shortcuts, monitor important system information on a real-time basis, and open multiple application windows to run multiple tasks concurrently, bringing greater working efficiency.


Qsirch – a Smarter, Faster Way to Search

Quickly and easily find documents, photos, videos, and music with Qsirch, QNAP's new built-in NAS search application lets you find what you need by real-time, natural search. Simply type in as much as you know about what you are trying to find, including bits of the file name or even words/phrases in the document, and Qsirch will display a list of matches, complete with thumbnails, as you type. Qsirch even remembers your search history so you can quickly navigate to files you've previously searched for. Qsirch is a huge productivity boost – it greatly reduces the amount of time spent looking for files on the NAS so you can focus on other tasks.


Breakthrough Performance

The TS-EC1680U R2 supports 6Gbps hard drives driving over 3,500 MB/s throughput and 390,000 IOPS*. Featuring with Intel® Xeon® E3 v3 Quad-Core Processor and 4 GB DDR3 ECC RAM, the TS-EC1680U R2 greatly enhances efficiency of CPU-consuming tasks and serves more concurrent tasks at the same time.


Internal Cache Port for IO Acceleration

The TS-EC1680U R2 supports two on-board mSATA internal cache ports, and up to 4 SSDs can be used for caching. By installing mSATA flash modules (optional purchase), the IOPS performance of storage volumes can remarkably boost. It is perfect for improving overall workflow of random IOPS demanding applications such as database and virtualization. The internal cache port design reserves the space of hard drive tray for more storage capacity.


Removable Motherboard Drawer for Easy Maintenance

With the TS-EC1680U R2's removable motherboard drawer, IT administrators have easier access in upgrading/installing components such as RAM, the internal cache and 10GbE adapter. The motherboard itself can be removed and replaced without needing to remove the heavy TS-EC1680U R2 from the rack cabinet, making it especially useful in maintaining the TS-EC1680U R2 in data centers with multiple rack cabinets.


10GbE Ready

The TS-EC1680U R2 offers four inbuilt Gigabit Ethernet ports and features two inbuilt 10GbE SFP+ ports to deliver 10 Gigabit high speed network. The 10GbE-ready TS-EC1680U R2 delivers lightening data throughput. Coupled with the support for large storage capacity, the TS-EC1680U R2 is perfect for data centers to storage big data and excel in fast data transmission, and for editing large size videos on-the-fly without transferring the videos between the TS-EC1680U R2 and desktop computers.


Seamless Capacity Expansion

The TS-EC1680U R2 supports online capacity expansion by cascading multiple QNAP RAID expansion enclosures to meet the needs of growing business data. With QNAP scale-up solution, total storage capacity can be gradually expanded on demand. It is especially useful for large data applications, such as video surveillance, data archiving, and TV broadcast storage, to name few.


Powerful QNAP Flexible Volume

QNAP flexible volume provides a more secure and flexible way to store the NAS data. This next generation volume offers powerful features such as storage pooling with multiple RAID group protection, thin provisioned volume with space reclaim, block-level iSCSI LUN, and online capacity expansion. The QTS Storage Manager neatly presents tools and options for managing system storage which simplifies the process of NAS capacity expansion and QNAP RAID expansion enclosure management.


Cross-platform File Sharing, Centralized Data Storage

The TS-EC1680U R2 supports SMB/CIFS, NFS, and AFP protocols for file sharing across Windows, Mac, Linux/UNIX networks. Data, logs and ISO image of CDs and DVDs can be centralized store in the NAS and protected by integrated antivirus solution. The Windows AD and LDAP services enable system administrators to configure user permissions by using existing Windows AD server, LDAP server or NAS build-in LDAP service.


Well-rounded Backup Solutions to Secure Data

The TS-EC1680U R2 offers well-rounded backup solutions as a reliable backup center. QNAP NetBak Replicator supports scheduled and real-time data backup on Windows OS. Mac Time Machine is also supported to provide Mac OS X users with an effortless solution to back up data to the TS-EC1680U R2.


Disaster Recovery Solutions Brings Peace of Mind

The TS-EC1680U R2 offers various data recovery options. RTRR (Real-Time Remote Replication) supports real time or scheduled data backup to a remote Turbo NAS or FTP server and synchronizes files to a remote folder from a local folder with better backup efficiency and reduced backup time. The TS-EC1680U R2 also supports rsync protocol to back up data to another remote server on scheduling basis. Besides, data can be backed up to cloud storage, such as Amazon® S3, Amazon Glacier, Microsoft® Azure, ElephantDrive®, Dropbox® and Google Cloud Storage, and restored to the TS-EC1680U R2 anytime.


Comprehensive Security Options

In the open network environment, business data might be exposed in potential hack. The TS-EC1680U R2 provides numerous security options, such as encrypted access, IP blocking, and so on. Besides, IT administrators can control the access rights of each user to different folders, preventing unauthorized access to important files. The TS-EC1680U R2 provided AES 256-bit folder-based and volume-based encryptions which are validated by FIPS 140-2 CAVP (Cryptographic Algorithm Validation Program), preventing sensitive business data from unauthorized access and breach even if the hard drives or the entire system were stolen.


Storage for Comprehensive Virtualization Applications

The TS-EC1680U R2 is VMware® Ready™, Citrix® Ready™, compatible with Microsoft® Hyper-V™ certification and Windows Server 2012, benefiting flexible deployment and management in the virtualization environments. The TS-EC1680U R2 supports VMware VAAI and Microsoft ODX to increase performance by offloading server loading for ESXi and Hyper-V respectively, and supports QNAP vSphere Client plug-in and QNAP SMI-S provider with enhanced efficiency of operations and management in virtualization applications.


Run Multiple OS’ on the TS-EC1680U R2

The Virtualization Station transforms the TS-EC1680U R2 into a 2-in-a-box NAS that can function as an all-in-one NAS and a virtualization platform supporting multiple operating systems, fast virtual machine creation, virtual machine import/export, snapshot, and enables desktop operations on web browser. With the easy-to-use interface, you can centrally manage all virtual machines created on the TS-EC1680U R2 with least efforts. Furthermore, you can download VMs on demand from the online VM markets and import them to TS-EC1680U R2 to use directly without any complex procedure.


Highly-efficient Storage Solution for Video Editing

Digital film and video production produces volumes of data that require high performance RAID storage with sustainable throughput to balance with the demanding output of video editing. The TS-EC1680U R2 fulfills storage and video editing needs with a high speed 10GbE network interface. Digital videos can be quickly stored and edited on the TS-EC1680U R2 directly over the network.


File Synchronization Across Multiple Devices

The Qsync utility turns your TS-EC1680U R2 into a safe data center for file synchronization with large storage capacity. Any file uploaded to the TS-EC1680U R2 will be made available for all linked devices, such as computers, laptops or mobile devices. Qsync is especially useful for frequent travelers to manage files and always have the most updated files on different devices. Qsync provides multiple ways of file synchronization and group file sharing, greatly enhancing the flexibility of collaboration.


Comprehensive Surveillance Solution With 24/7 Security

The TS-EC1680U R2 Surveillance Station is a professional surveillance solution with a wide range of over 2,600 compatible IP camera models and expandable IP camera channel licenses. It supports real-time monitoring, video and audio recording and playback with flexible options to customize. You can also install the Vmobile app on your iOS® or Android™ mobile devices to manage the monitoring channels anytime and anywhere, and safeguard your office environment.


Install-on-demand Apps Extend NAS Features

The TS-EC1680U R2 has built in App Center providing various install-on-demand apps developed by QNAP and third-party developers, including backup/sync, business, content management, communications, download, entertainment, and so on. It’s also a central place to manage and update installed apps. Besides, QNAP’s development platform brings forth the open-source spirit to welcome program developers to develop various applications, adding values to the TS-EC1680U R2 for extensive opportunities.

Features
• Built-in 10GbE, highly-efficient storage solution for HD video editing and sharing
• 3,500+ MB/s throughput and 390,000+ IOPS
• Two internal cache ports and up to 4 SSDs for caching
• Scalable up to 144 drive capacity with QNAP expansion enclosures
• Virtualization-ready, centralized data storage, backup, sharing and disaster recovery
Specifications
Edition TS-EC1680U-E3-4GE-R2
NAS Form Factor 3U Rackmount
Bays 16 Bay
Total Storage Included 192,000 GB
Type of Drives Included HDD (3.5" SATA3 6Gb/s)
Edition of Drives Included Seagate Exos X14
Capacity of Drives Included
Max. Storage Capacity
Drive Interface Support
  • 2 x mSATA
  • 16 x SATA III - 6Gb/s
Drive Form Factor Support
  • 16 x 2.5"/3.5"
  • 2 x mSATA
Internal Flash Memory Yes
Internal Flash Memory Capacity 512MB
DOM Module Yes
DOM Capacity
CPU Type Intel Xeon
CPU Model E3-1245 v3
CPU Cores Quad Core
CPU Speed 3.5 GHz
RAM Memory Included 4GB (2x2GB)
RAM Memory Type DDR3 ECC
Max. RAM Memory Supported 32GB (4x8GB)
Cache Drive Interface
Included Cache Drive Capacity
Included Cache Drive Type
LAN Type N/A
Expansion Slots
  • 1 x PCIe 3.0 x4
  • 1 x PCIe 3.0 x8
External Connectivity
  • 4 x RJ45
  • 2 x SFP+
  • 4 x USB 2.0
  • 4 x USB 3.0
Cooling Fan
Noise Level 40.5 dB(A)
PSU Type Redundant/Hot Swap
PSU Wattage 650 W
Max. Power Consumption 166.58 W
Physical Security
Dimensions 442.5 x 130 x 530.5 (WxHxD mm)
Weight 18.3 kg
Additional Information
Scan Code LN99042
Model Number TS-EC1680U-E3-4GE-R2/192TBEXOS
