Phanteks Enthoo Mini XL micro-ATX/mini iTX Mid Tower Case (Dual Motherboard ready optional) LN62257

Product Overview The MINI XL introduces a new form factor, super micro ATX. With its unique power supply location, the Mini XL case has been redesigned with optimal cooling in mind. Resembling the Enthoo Primo, it offers extensive water-cooling possibilities and supports the thickest radiators in the market (80mm). The case brings modularity to a new level. Almost every single panel or bracket can be removed or relocated to serve different purposes. For the ones who desire even more, the Mini XL leaves options for additional upgrades. Perhaps the most interesting one is the possibility to transform the MINI XL into a dual motherboard system.

Dual Motherboard ready optional with mini-ITX Upgrade Kit - LN62257

Enthoo Mini XL Dual Motherboard Support Upgrade Kit (LN62257) (not included) is available here.
So you can have 2 systems in this case a micro-ATX and a mini-ITX with this upgrade Kit.


Appearance:
• Sandblasted aluminum faceplates with matte finish
• Multi-color LED light strips
• Stealth interior design

Cooling:
• Extreme cooling capacity
• Support for up to 14x 120mm / 8x 140mm
• Comes with 3 Phanteks premium fans
• PWM fan hub plus 2x y-splitters allow for 8 fan connections* (11 fans max with additional y-splitters sold seperately)
• Extensive water cooling support. Provides up to 5 different installation areas for slim and thick radiators varying from single to triple (120mm and 140mm form factors). Clearance for push-pull fan configurations.

Functionality:
• Dual removable harddrive cages
• 2x removable Drop-N-Lock SSD brackets
• Fully equipped with dustfilters (1x top, 1x front, 2x bottom)
• Removable top panel for easy fan installation and dust filter cleaning
• Compartment for fan installation in top panel
• Clean cable management using Phanteks' preinstalled Hoop-N-Loop cable ties
• Mod friendly structure uses screws NOT rivets
• 10 color abient lighting controller
• 2x USB 3.0, microphone, 3.5mm audio jack Features Option dual Motherboard kit
Phanteks also make an upgrade for the Enthoo Mini XL to support Dual Motherboards (LN62257) Upgrade Kit.
Upgrade Kit not included, sold separately.

Dimension
260 mm x 550 mm x 480 mm (W x H x D)

Form Factor
Super Micro Chassis

Material(s)
Aluminum faceplates, Steel Chassis

Motherboard Support
uATX, mITX - (optional dual Motherboard support)

Front I/O
2x USB 3.0, Mic, Headphone

Side Window
Yes, split-window design

Expansion slots
5
External 5.25"
3
Internal 3.5"
6 (2x 3 HDD cages)

Internal 2.5"
8 (2x 3 HDD cages + 2x SSD brackets )
