Palmer AoC Loom TRS M

Palmer - AoC Loom TRS Male, Audio Over Cat Loom from etherCON to 4 x 6.3mm TRS Jack

Thumbnail 1 : Palmer AoC Loom TRS M Thumbnail 2 : Palmer AoC Loom TRS M Thumbnail 3 : Palmer AoC Loom TRS M Thumbnail 4 : Palmer AoC Loom TRS M
Scan code: LN147590 Manufacturer code: PAOCLTRSM
Order now and receive it by Thursday, 25th July
£109.99
Get it Thursday, 25 JulIn stock
FREE DELIVERY ON THIS ITEM
From £9.97 / month (APR 16.9%) or 0% for 4 months
Monthly Payment: £9.97
Instalment Rate: 16.9% p.a. (fixed)
Cost of purchase: £109.99
Total inc. interest: £119.58
Example
Minimum Spend: £99
Instalment Rate: N/A
Cost of purchase: £99
Total inc. interest: £99
If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 23.9% and may be even lower.

Representative Example:

Purchase Rate: 23.9% p.a. (variable)

Representative: 23.9% APR (variable)

Assumed Credit Limit: £1,200

Subject to status. Terms and Conditions apply.
spend over £280 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
Delivery Options
  • By DPD On 25th Jul to your specified address. | Free Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • UPS and DPD Pickup Pickup from local convenience store | £4.79

    Collect your parcel from your newsagents, petrol stations and convenience stores

Audio Over Cat Loom from etherCON to 4 x 6.3mm TRS jack
Palmer - AoC Loom TRSm

Palmer AoC Loom TRSm

AoC Loom TRS MaleThe P AOC L TRS M is a multicore adapter cable that enables stable transmission of 4 separate analogue and balanced audio signals through a network cable (not included). The 6.3 mm TRS jacks are numbered and colour-coded for easy identification. The Ethercon connection is safeguarded against unlocking to prevent accidental cable disconnection.

Audio is transmitted via a single, standard Ethernet cable, allowing the P AOC L TRS M to be used flexibly across various applications, if its for live concerts, studio sessions, press conferences, or other productions.

Made using high-quality Neutrik components, a solid aluminum-steel housing, and robust mesh cables with a 50 cm splice, the P AOC L TRS M guarantees reliable signal transmission and durability in professional environments. Its simple, high-quality design also enhances the visual appeal of any setup.

All these factors make the P AOC L TRS M a reliable and durable tool that provides an affordable and flexible alternative to conventional 4-channel multicores without compromising audio quality - just as you would expect from Palmer.

At a glance • 4 balanced analogue audio channels over Cat5e or higher (Ethernet cable not included)
• etherCON to 4 x 6.3 mm TRS jack
• AES72 Type 5E
• Premium Neutrik components
• Robust mesh cable, 0.5 m
• Solid casing made of aluminium and steel
• Engineered in Germany

The Tech Spec

Features Specification
Product type Audio over Cat adapter
Number of inputs 4
Input type Balanced
Input connector RJ45
Number of outputs 4
Output type Balanced
Output connector 6.35mm TRS stereo jack
Material Aluminium, Steel
Cable Length 0.5m
Dimensions Width: 128mm
Height: 50mm
Depth: 140mm
Operating Temperature - 20 - 70 °C
Air humidity > 80 % (non-condensing)
Max. input level (< 1% THD, 1 kHz) + 32 dBu dBu
Frequency range 0 Hz - 20 kHz
THD (1 kHz, +4 dBu, unity, unweighted) < 0,0005 %
Specifications
Connector A None
Connector B None
Length 0.5 Metre
Additional Information
Scan Code LN147590
Model Number PAOCLTRSM
GTIN 4049521908460
