Moog Matriarch Semi-Modular Analogue Synthesizer

Moog Matriarch Semi-Modular Analogue Synthesizer, 4-note Paraphonic, 256 Step Sequencer, 4x Analogue Oscillators

Thumbnail 1 : Moog Matriarch Semi-Modular Analogue Synthesizer Thumbnail 2 : Moog Matriarch Semi-Modular Analogue Synthesizer Thumbnail 3 : Moog Matriarch Semi-Modular Analogue Synthesizer Thumbnail 4 : Moog Matriarch Semi-Modular Analogue Synthesizer
Scan code: LN98280 Manufacturer code: MOD-MATR-03
Order now and get it tomorrow, Tue 4th Aug
From £52.20 / month (APR 14.9%)
Monthly Payment: £171.56
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £1,911.00
Total inc. interest: £2,058.67
Monthly Payment: £91.73
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £1,911.00
Total inc. interest: £2,201.38
Monthly Payment: £65.29
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £1,911.00
Total inc. interest: £2,350.26
Monthly Payment: £52.20
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £1,911.00
Total inc. interest: £2,505.12
If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 19.9% and may be even lower.

Representative Example:

Purchase Rate: 19.9% p.a. (variable)

Representative: 19.9% APR (variable)

Assumed Credit Limit: £1,200

Subject to status. Terms and Conditions apply.
Delivery Options
  • By DPD On 4th Aug to your specified address. | Free Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

Product Overview Moog Matriarch is a patchable 4-note paraphonic analogue synthesizer with a built-in Sequencer, Arpeggiator, stereo Ladder Filters, and stereo Analog Delay. Create rich evolving chord patterns immediately with "no patching required", then tap into an abundance of inspiring textures, new sounds, and an endless supply of happy accidents through Matriarch's 90 modular patch points. Based on the vintage circuitry of classic Moog synthesizer modules, Matriarch is a catalyst for creative ideas and a medium for multidimensional expression.

Matriarch is an analogue synthesizer with an emphasis on imagination. The pinnacle of Moog's semi-modular family of synthesizers, Matriarch's patchable architecture and classic Moog circuits reward open exploration with endless sonic possibilities and unparalleled analogue sound.

Easily create rich harmonic shapes with up to 4 notes of paraphony that can be sequenced, shifted, and stored with Matriarch's intuitive 256 step sequencer, or stack the analogue VCOs to play on a massive 4 oscillator mono synth.

With a deep assortment of synthesis modules based on Bob Moog's original circuit designs, Matriarch's 100% analogue signal path spans a dynamic sonic vocabulary - from overdriven monophonic bass to gently evolving paraphonic plucks that cycle through waveshapes into a wash of infinite delay trails . Coupling the power of vintage-designed stereo ladder filters, dual Envelope Generators, stereo Analog Delays, and stereo VCAs, Matriarch delivers a multi-dimensional sound that empowers the sonic exploration of space and time .

Though Matriarch's semi-modular design requires absolutely no patching, 90 modular patch points are easily accessible throughout the panel via the included 3.5mm patch cables. This powerful electronic instrument is a highly-versatile addition to any stage or studio that can effortlessly transform from a performance keyboard into a fully modular analogue synthesizer at a moment's notice.

In addition to its standalone function, Matriarch is also an ideal processor of external sound sources and a powerful keyboard front-end for expanding a DFAM, Mother-32, Grandmother, or Eurorack modular system.
Features • Mono, duo, and 4-note paraphonic playability
• Stereo analogue delay w/ up to 700ms of MIDI sync-able stereo or ping/pong style repeats
• 256 step sequencer w/ up to 4 notes per step and 12 stored patterns. (Can be decoupled from Matriarch to independently sequence external gear)
• Arpeggiator with selectable modes (Order, Forward/Backward, Random)
• Semi-modular analogue synthesizer - no patching required
• 90 modular patch points for endless exploration
• Expressive 49-note Fatar keyboard w/ patchable velocity and aftertouch
• 4 analogue oscillators w/ selectable waveshape and hard sync per-oscillator
• Full-range analogue LFO with 6 selectable waveshapes
• Dual analogue filters with parallel (HP/LP), stereo (LP/LP), and series (HP/LP) modes available
• Dual analogue ADSR envelopes
• Dual analogue VCAs
• 3x bipolar voltage controlled attenuators with ring mod capability
• 2x4 parallel wired unbuffered mults
• Additional simple analogue LFO useful for adding modulation to delay, filters and VCAs
• 1/4 external audio input for processing guitars, drum machines, and more through Matriarch`s analogue circuits
• Stereo 1/4 and 3.5mm Eurorack level audio outputs

Module Provenance
• Oscillators based on the Minimoog
• Mixer based on the classic CP3 module
• Filters based on the classic 904A module
• Envelopes based on the classic 911 module
• VCAs based on the classic 902 module
• Analog Delay based on the MF-104M and 500 Series effects

• Type: - Semi-Modular Analog Synthesizer
• Sound Engine: - 100% Analog
• Number of Keys: - 49 Full-Size Keys
• Type of Keys: - Velocity-sensing with Aftertouch (Velocity and Aftertouch are not hard-wired - available via MIDI, KBD VEL OUT and KB AT OUT jacks)
• Other Controllers: - Pitch Bend, Mod Wheel, Variable Glide, Expression pedal in to CV out, and Sustain Pedal in
• Polyphony: - Monophonic, 2-Note Paraphonic, and 4-Note Paraphonic
• Sound Sources: - 4x Analog Oscillators with Selectable Waveforms (Oscillators 2, 3, and 4 support Hard Sync), White Noise Generator, External Input jack.
• Mixer: - 6 input (5 eurorack level and 1 instrument level) DC coupled discrete mixer with asymmetrical clipping behaviour
• Filters: - 24dB/Octave Low Pass Filter with Resonance, 24dB/Octave switchable Low Pass/High Pass Filter with Resonance. Configurable in parallel (HP/LP), stereo (LP/LP), and series (HP/LP).
• Mod Sources: - Analog Modulation Oscillator with selectable and patchable output (Sine, Saw, Ramp, Square, Stepped Triangle, Smoothed Random, Sample and Hold, Noise). Additional LFO (Tri, Square)
• Envelopes: - 2x Four-Stage ADSR with End of Envelope gate outputs
• Attenuators: - 3x Bipolar Voltage Controlled Attenuators with Ring Mod capabilities
• Mults: - 2x4 Parallel-wired Non-buffered Patch Points
• VCAs :- 2x discrete analogue VCAs routed in stereo
• Effects: - Stereo Analog Delay with Ping/Pong, MIDI and CV clock sync, voltage controlled Mix, and independent L/R delay times, feedback, and I/O.
• Arpeggiator / Step Sequencer: - 256 Steps with up to 4 notes per step; 12 Sequence locations
• Patch Points: - 90 x 3.5mm front and rear panels, 49 Inputs, 33 Outputs, 2x4 Parallel-wired Mults.
• Pedal Inputs: - 1/4" Sustain, 1/4" Expression
• Audio Input: - 1/4" TS jack (Rear Panel)
• Audio Outputs: - 2x 1/4" TS jacks for line level output (Rear Panel), 1/4" Headphone jack with dedicated level knob (rear panel), 2x 3.5mm Eurorack level outputs, 2x 3.5mm Delay outputs
• Midi I/O: - 5-pin DIN In, Out, Thru; plus, MIDI over USB (Rear Panel)
• Dimensions: - 32" (81.28cm) Wide x 14 1/4" (36.19cm) Deep x 5 1/2" (13.97cm) High
• Power: - Included Power Adapter 12V DC (positive tip), 2A, 100 to 240 Volts AC, 50/60Hz with screw-on barrel connector.
• Weight: - 24lbs. / 10.89kg
Product Type Analog Synthesizer
PC Interface N/A
Keys 49 Full-Size Keys
Connectivity (Input)
Connectivity (Output)
Sample Rate
Bit Rate N/A
Frequency Response (Input) N/A
Frequency Response (Output) N/A
Maximum Input Level N/A
Maximum Output Level
Dynamic Range
Dimensions (mm)
Misc. Notes
Package Type Retail
Additional Information
Scan Code LN98280
Model Number MOD-MATR-03
GTIN 040232238987
