Magewell Eco Capture Quad SDI M.2
Magewell Eco Capture Quad SDI M.2 Capture Card, MMCX, 3G-SDI/2K-SDI
Email me when the availability or price changes
Four-Channel 2K Capture card
The Magewell Eco Capture Quad SDI M.2 Capture Card allows you to capture four channels of SD/HD/3G/2K-SDI video with embedded audio with a single M.2 2280 capture card. Compatible with video formats up to 2048x1080 with four MMCX ports supporting up to 2K-SDI via the included MMCX to BNC cables. Capture uncompressed video from a camera or switchers SDI output on your Windows or Linux computer for recording, editing, or streaming. Extraction of audio-formation and channel-status data is supported, as are closed caption and multiple colour spaces in 8-bit formats. Video processing features include frame-rate conversion, cropping, scaling, de-interlacing, and aspect-ratio conversion.
Features
Input Interface
• SD/HD/3G/2K SDI x4
• Support input resolution up to 2048×1080 pixels
Host Interface
• M.2 (PCIe Gen2 x4)
Video Engine
• Auto detection of input signal format
• Colour formats conversion
• Low latency mode
• SG-DMA transmission mode
• Multiple replicated capture streams
• Closed caption (SDK required)
Software
• Window & Linux driver and SDK
• Upgradable firmware
• Compatible with Capture Express, Magewell Bridge for NDI®, Plugin for Premiere®
Others
• 2-year warranty
• Continuously work for 24hx7
• LED status indicator
• Multiple devices on one host
• On-board dip switch to set card number
