Laney - BCCLOUDPEDAL-LTQ, 60W Guitar Amplifier Pedal
Laney Black Country Customs - LIONHEART LOUDPEDAL - 60W - Tom Quayle
60W Guitar Amplifier Pedal
Laney - BCCLOUDPEDAL-LTQ
Lionheart Tom Quayle (LTQ) LOUDPEDALThe Laney Lionheart Tom Quayle (LTQ) LOUDPEDAL is a 60-watt 2 channel LIONHEART amplifier, with BOOST, Reverb and powerful EQ settings, designed in collaboration to meet the needs of, arguably, the greatest fusion player in the world today. BCCLOUDPEDAL-LTQ: Tom Quayle UK designed and crafted, artist collaboration LOUDPEDALS “I am blown away by this LIONHEART, it’s sooo good!..”
As a long-term Laney artist, Tom is the foremost fusion legato player in the world with a great reputation as an artist and educator, having produced and sold a large number of highly acclaimed tuition products to= thousands of guitar players from every corner of the planet.
A true player’s player, Tom is renowned the world over and can count Dweezil Zappa, John Petrucci, Brett Garsed, Greg Howe, Andy Timmons and Tim Miller amongst his many fans. His immense reach in the guitar community lead to two signature Ibanez guitars and one of their most successful clinic tours. Tom has always loved the LIONHEART sound for its rich and uniquely responsive tone.
Meticulously designed in Laney's UK workshop to offer real LIONHEART tone in an analogue, pedal amp format. The LIONHEART LOUDPEDAL is a two channel, 60-watt amplifier featuring powerful EQ switching, stunning reverb and – for the first time ever on a LIONHEART – a BOOST. Designed in collaboration with Tom Quayle, who continuously tested the design helping us deliver incredibly articulate, rich LIONHEART tones in a pedalboard-ready form.
at a glance
• 60W RMS High Power
• Two Independent Channels with footswitchable control
• Replicates the Tone and feel of the Lionheart tube series
• Drive Channel with Gain, Volume and switchable Bright, Natural and Dark voicing
• Clean Channel with Bright Switch
• 3 Band Passive Tone Stack and Tone Control
• Digital Reverb with footswitchable control
• LA·IR High Quality Digital IR emulated balanced XLR Out
Find Your Sound
ReverbDigital Reverb with footswitchable control based around the Black Country Customs Secret Path “Spring” algorithm.
EQ SwitchingThe EQ switches effect the tonal character of the channel allowing you to select BRIGHT/FLAT/DARK EQ settings for each channel.
BoostBuilt in Footswitchable Pre-Boost with level. Based on the acclaimed Black Country Customs STEELPARK boost circuit, Tom’s favourite.
Versatile I/O
USBUSB-C provides latency free Audio Out to your preferred DAW. Additionally providing access to the LA.IR App. The app allows ultimate control over the Impulse Responses in the amp.
Aux/HeadphonesUse the Aux/Headphones output to run backing tracks or practice silently.
LA.IRThe UK-Built LOUDPEDALs feature Laney's advanced Impulse Response technology
MIDIAll footswitchable features on the BCCLOUDPEDALS can be switched remotely via MIDI CC numbers, so it will interface effortlessly with your existing controller set up.
Laney Black Country Customs LOUDPEDALS feat Tom Quayle and Martin Miller
The Tech Spec
| Features | Specification | Type | Pedal Board Guitar Amplifier |
|---|---|
| Input Impedance | 1MΩ |
| Amplifier Power | 60W RMS |
| Channels | Clean and Drive (Footswitchable) |
| EQ | Bass, Middle Treble (Passive tone stack) Overall Tone Control, plus Bright switch (Clean Channel) and Tone character Switch (Drive Channel) |
| Effects | Digital Springline Reverb (Footwitchable),External FX Loop |
| Controls | Pre-Boost, Clean Volume, Clean Bright Switch, Channel Switch, Drive Gain, Drive Volume, Drive Tone Character (Normal, Bright, Dark), Bass, Middle, Treble, Reverb |
| Indicators | LEDs for Boost, Channel 1, Channel 2, and Reverb |
| Inputs | 6.3mm (1/4") Mono Instrument Input Jack, 6,3mm FX Return jack, 3.5mm stereo aux in jack |
| Outputs | 6.3mm Transformer Isolated FX Send (Doubles as Line Out), 3.5mm stereo headphone jack, Balanced Male XLR DI out with LA·IR Speaker Emulated Digital Impulse Response with high quality 1x12 and 4x12 options. |
| Other | USB C for Class compliant audio streaming @48kHz (Emulated and unemulated main out) and loading of custom IR's |
| Power Supply | Regulated 24V 2.5A 60W DC PSU Included: Centre Positive, 2.1 x 5.5 x 12mm connector type |
| Typical Power Consumption | 60W |
| Dimensions (HWD) | 67 x 199 x 143mm 2.6" x 7.8" x 5.6" |
| Weight | 1.7Kg 3.7 lbs |
