JWIPC H076 ARM Platform Media Player
The JWIPC H076 ARM Platform Media Player is a compact, fanless digital signage solution designed for commercial displays, information systems, kiosks and conference environments. Powered by the Rockchip RK3576 octa-core processor, combining four Cortex-A72 cores and four Cortex-A53 cores, it delivers efficient processing for demanding multimedia applications. With support for dual 4K displays at 60Hz, Android 14 and flexible connectivity, the H076 provides a versatile platform for commercial digital signage and information distribution.
Designed for continuous operation in commercial environments, the H076 combines a fanless cooling system with dual HDMI outputs, HDMI input, Gigabit Ethernet and wireless connectivity. Its USB ports, RS232 serial interface, MicroSD card slot and optional 4G/5G connectivity provide flexibility for integrating the player into a variety of signage installations, while Power over Ethernet (PoE) power-device input can simplify deployment in compatible network environments.
Powerful Octa-Core ARM Processing
Built around the Rockchip RK3576 platform, the H076 features four ARM Cortex-A72 cores and four Cortex-A53 cores, operating at up to 2.2GHz. Its ARM Mali-G52 MC3 GPU supports graphics processing for multimedia applications, making the player suitable for digital signage, kiosks, conference displays and commercial information systems.
Dual 4K Display Support
The H076 features two HDMI 2.0 outputs, each supporting resolutions up to 4K at 60Hz, enabling simultaneous playback across two compatible displays. An additional HDMI input supports video signals up to 1920 × 1080 at 60Hz, providing further flexibility for conference and audio-visual applications.
Fanless Design for Continuous Operation
The H076 uses a fanless cooling design to minimise mechanical noise and eliminate the need for a cooling fan. With support for watchdog functionality, automatic power-on and real-time clock scheduling, it is designed to support reliable operation in commercial signage and information display installations.
Flexible Networking and Connectivity
Gigabit Ethernet with an RJ45 connector provides wired network connectivity, with support for 48W Power over Ethernet power-device input. Wi-Fi 6 and Bluetooth 5.2 provide wireless connectivity, while optional 4G/5G support enables alternative network deployment options. The H076 also includes USB 3.0, USB 2.0, USB Type-C, an RS232 serial interface, a MicroSD card slot and a SIM card slot.
Android 14 and Integrated Storage
Running Android 14, the H076 provides a platform for compatible digital signage software and commercial applications. Its 4GB LPDDR4x memory supports system operation, while 32GB of onboard eMMC 5.1 storage provides space for the operating system, applications and locally stored content. Additional storage configurations are available on the platform, with the exact capacity dependent on the supplied configuration.
• Rockchip RK3576 octa-core processor up to 2.2GHz.
• Four ARM Cortex-A72 cores and four Cortex-A53 cores.
• ARM Mali-G52 MC3 GPU.
• 4GB LPDDR4x memory.
• 32GB eMMC 5.1 onboard storage.
• Android 14 operating system.
• Dual HDMI 2.0 outputs supporting up to 4K at 60Hz.
• HDMI input supporting up to 1920 × 1080 at 60Hz.
• Gigabit Ethernet with 48W PoE PD-in support.
• Wi-Fi 6 and Bluetooth 5.2.
• USB 3.0, USB 2.0 and USB Type-C connectivity.
• RS232 serial interface, MicroSD card slot and SIM card slot.
• Fanless cooling design.
• Watchdog support and scheduled power-on/off functionality.
