Scan code: LN82741 Manufacturer code: BX806736148

Intel 20 Core Xeon Gold 6148 Server/Workstation CPU/Processor

Intel Xeon Gold 6148, S 3647, Skylake-SP, 20 Cores, 40 Threads, 2.4GHz, 3.1GHz Turbo, 27.5MB Cache, 150W, Retail

Thumbnail 1 : Intel 20 Core Xeon Gold 6148 Server/Workstation CPU/Processor Intel 20 Core Xeon Gold 6148 Server/Workstation CPU/Processor : video thumbnail 1 Intel 20 Core Xeon Gold 6148 Server/Workstation CPU/Processor : video thumbnail 2 Intel 20 Core Xeon Gold 6148 Server/Workstation CPU/Processor : video thumbnail 3
Scan code: LN82741 Manufacturer code: BX806736148
£2,784.98Item currently awaiting an ETA
Pre Order
Pre order
From £133.68 / month (APR 14.9%)
Monthly Payment: £483.26
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £2,784.98
Total inc. interest: £2,899.54
Monthly Payment: £250.02
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £2,784.98
Total inc. interest: £3,000.19
Monthly Payment: £172.40
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £2,784.98
Total inc. interest: £3,103.04
Monthly Payment: £133.68
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £2,784.98
Total inc. interest: £3,208.19
If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 17.9% and may be even lower.

Representative Example:

Purchase Rate: 17.9% p.a. (variable)

Representative: 17.9% APR (variable)

Assumed Credit Limit: £1,200

Subject to status. Terms and Conditions apply.
With a 10% deposit from just £69.55 / month (APR 15.9%)
Delivery Options
  • By DPD to your specified address. | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

Product Overview Intel® Xeon® Gold 6148 20-Core Processor with Hyper-Threading
The Xeon Gold Series on the 3647 socket aims to provide Great Performance using Faster Memory, Increased Interconnect & Accelerator Engines, and all combined with Advanced Reliability. These Xeon Gold (61xx) CPUs improve upon on the Xeon Gold (51xx) Skylake-SP models, further boosting their capabilities by adding 2S-3UPI & 4S-3UPI support, raising the supported DDR4 speed to 2666MHz, along with providing Node Controller Support, additional 512-bit FMA for AVX-512, and an extra UPI Link, bringing the total to Three. Xeon Gold CPUs also move to an Advanced RAS. The Gold (61xx) Series continues to pack all the same features of Bronze & Silver to help power the next-generation of Workstations & Servers.

Introducing Intel® Xeon® Processor Scalable Family
The new Intel® Xeon® processor scalable family accelerates performance agility, strengthens security, and improves efficiency.

Change is in the air, and you and your operations are the biggest beneficiaries. Most notably, the Intel® Xeon® processor E5 and E7 families will merge into the first-ever Intel® Xeon® processor scalable family. New platinum, gold, silver, and bronze levels simplify choosing the right processor for your business needs. It will be easier than ever before for you to select the appropriate scalable, secure, agile, next-generation platform for your infrastructure. You will see huge leaps in performance and capabilities for a wide range of workloads from technologies such as Intel® Advanced Vector Extension 512, 1/10GbE Intel® Ethernet high-speed networking, Intel® QuickAssist Technology, and other accelerators. Features • 2S-2UPI, 2S-3UPI, 4S-2UPI, 4S-3UPI Capability.
• Support for 6-Channel DDR4 @ 2666 MHz.
• 3x UPI Links @ 10.4GT/s.
• Intel Turbo Boost Technology.
• Intel Hyper-Threading Technology.
• Intel AVX-512 (2x 512-bit FMA).
• 48 Lanes PCIe Gen3.
• Node Controller Support.
• Advanced RAS.
Specifications
CPU Type Intel Xeon Gold
CPU Model 6148
Socket 3647
Architecture Skylake-SP (Purley)
Manufacturing Process 14 nm
No. of Cores 20 Core
No. of Threads 40
Core Ratio 24 x
Clock Speed 2.4 GHz
Turbo Speed 3.1 GHz
Max. Turbo Speed (On 2 Cores Only) 3.7 GHz
Intel Turbo Boost Max Technology 3.0 No
FSB Speed N/A
QPI Speed N/A
UPI Links/Speed 3x UPI Links @ 10.4GT/s
DMI Speed N/A
Unlocked Core Multiplier No
Unlocked Full Range Base Clock (B-Clock) No
Max. Memory Size 768 GB
Max. Memory Speed DDR4 - 2666
Max. Memory Channels 6 (Hex Channel)
ECC Memory Support Yes
Intel Optane Memory Support No
Scalability
Max. PCIe Lanes Supported 48
Processor Graphics
Base GPU Speed N/A
Max. GPU Speed N/A
Max. GPU Resolution
L1 Cache
L2 Cache
L3 Cache 27.5MB
Intel® Smart Cache N/A
Voltage
Max. TDP 150W
Thermal Specification 86 °C
Heatsink/Cooler Included? Not Included, Sold Separately
Package Type Retail
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
36 months
Type:
Return to base
DOA Period:
28 days
RTB Period:
1 months
Manufacturer Contact Details
Manufacturer:
intel
Telephone:
0870 607 2439
TekSpek Guides
Intel Xeon Scalable Processors
Intel Xeon Scalable Processors
Date Issued: 21st Aug 2017

Intel has revamped its entire server- and workstation-specific line of Xeon processors for mid-2017. The new family is now known as the Intel Xeon Scalable Processors, formerly codenamed Purley, and is based on the newer Skylake-SP architecture. This TekSpek explains the key differences and improvements over the previous generation.
