Scan code: LN118128 Manufacturer code: BX806895320

Intel Hexacosa-Core Xeon Gold 3rd Gen 5320 Scalable Server CPU/Processor

Intel Xeon Gold 5320, FCLGA4189, Ice Lake, 26 Core, 52 Threads, 2.2GHz Base, 3.4GHz Turbo, 39MB Cache, 64 Lane

Scan code: LN118128 Manufacturer code: BX806895320
Delivery Options
  • By DPD to your specified address. | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

Services
  • 48HR REPLACEMENT If you need to return this item, your replacement will be dispatched within 2 working days of your product arriving back at Scan. More info
Product Overview

Intel® Speed Select Technology – Core Power

Enables flexibility for workloads that benefit from higher base frequency on a subset of the processor’s cores. While the max turbo frequency across the cores remain constant across the cores, a subset of the cores can be assigned as to run at a higher base frequency than specified, while the other cores run at lower base frequency.


Intel® Speed Select Technology – Turbo Frequency

Enables flexibility for workloads that benefit from higher turbo frequency on a subset of the processor’s cores. While the base frequency remains constant across the cores, a subset of the cores can be assigned to run at a higher turbo frequency than specified, while the other cores run at lower turbo frequency.


Intel® Deep Learning Boost (Intel® DL Boost)

A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.


Intel® Speed Select Technology - Base Frequency

Enables users to increase guaranteed base frequency on certain cores (high priority cores) in exchange for lower base frequency on remaining cores (low priority cores). Improves overall performance by boosting frequency on critical cores.


Intel® Resource Director Technology (Intel® RDT)

Intel® RDT brings new levels of visibility and control over how shared resources such as last-level cache (LLC) and memory bandwidth are used by applications, virtual machines (VMs) and containers.


Intel® Speed Shift Technology

Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.


Intel® Turbo Boost 2.0

Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.


Intel® Hyper-Threading Technology

Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.


Intel® Virtualization Technology (VT-x)

Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.


Intel® Virtualization Technology for Directed I/O (VT-d)

Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.


Intel® VT-x with Extended Page Tables (EPT)

Intel® VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel® Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management.


Intel® Transactional Synchronization Extensions

Intel® Transactional Synchronization Extensions (Intel® TSX) are a set of instructions that add hardware transactional memory support to improve performance of multi-threaded software.


Intel® 64

Intel® 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software.¹ Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.


Intel® Volume Management Device (VMD)

Intel® Volume Management Device (VMD) provides a common, robust method of hot plug and LED management for NVMe-based solid state drives.

Features

• Cores: 26.
• Threads: 52.
• Processor Base Frequency: 2.20 GHz.
• Max Turbo Frequency: 3.40 GHz.
• Cache: 39 MB.
• UPI Links: 3.
• TDP: 185W.
• Intel® UPI Speed: 11.2 GT/s.

Specifications
Model & Type
CPU Type Intel Xeon Gold
CPU Model Intel Xeon Gold 5320
Socket FCLGA4189
Architecture
Manufacturing Process 10 nm
Cores & Clocks
No. of Cores 26 Core
No. of Threads 52
Core Ratio
Clock Speed 2.20 GHz
Turbo Speed 3.40 GHz
Turbo Boost Max Technology 3.0 Speed N/A
Unlocked Core Multiplier No
Unlocked Full Range Base Clock (B-Clock) No
Bus Speeds
FSB Speed N/A
QPI Speed N/A
UPI Links/Speed 3x UPI Links @ 10.4GT/s
DMI Speed N/A
Memory Support
Max. Memory Size 6000 GB
Max. Memory Speed DDR4 - 2933
Max. Memory Channels 8 (Octa Channel)
ECC Memory Yes
Intel Optane Memory Yes
Intel Optane DC Persistent Memory No
Lanes & Features
Intel Deep Learning Boost Support Yes
Scalability Upto 2 Sockets/Processors
Node Controller Support No
PCIe Version 4.0
PCIe Lanes 64
Integrated Graphics
Features Integrated Graphics No
Integrated Graphics Model/Type
iGPU Cores
iGPU Base Clock N/A
iGPU Boost Clock N/A
iGPU Max. Resolution
CPU Cache
L1 Cache
L2 Cache
L3 Cache 39MB
Intel® Smart Cache N/A
Thermals & Package
Max. TDP 185W
Thermal Specification
Heatsink/Cooler Included?
Package Type Retail
Note
Additional Information
Scan Code LN118128
Model Number BX806895320
GTIN 0675901958158
