Intel 8 Core i7 7820X Unlocked OEM CPU/Processor

Intel Core i7 7820X, S 2066, Skylake-X, 8 Core, 16 Thread, 3.6GHz, 4.3GHz Turbo, 11MB, 28 Lane, 140W, CPU, OEM

Intel
Scan code: LN82211 Manufacturer code: CD8067303611000 Request call
£530.99
In stock
Pay on Scan Finance with a 10% deposit from just £13.26 / month (APR 15.9%)
High End
Delivery options £5.48 By DPD On 24th Jul 2017 DPD Delivered to your specified address. Receive SMS with one-hour delivery window. Free Collect Instore Q-Collect Place your order online and collect from our Bolton store with Q-Collect. Weekend, timed and European delivery options are available at checkout ScanProtect protection ScanProtect Protect against installation damage for 28 days.More

Intel i7 7820X CPU. New X-Series Core Processor. OEM Version

Intel i7 X-Series Processor / CPU
SkyLake X CPU Power from intel X-Series range

There are a wide range of Intel’s X-Series CPU’s, which allows users to find the CPU that fits their PC build best. The i7-7820X CPU supports 4 DDR4 memory channels and 28 PCI Express lanes such as the i7-7800X but is the first of the i7 family to feature Turbo Boost 3.0. Intel Smart Cache and other features are also bolstered to help get the most from your PC system.

This is the OEM version of the X-series i7 7820X

3.6GHz
Clock Speed
8
Cores
16
Threads
28
Lanes
11MB
Cache

Advanced X-Series Gaming, Recording and Streaming

X-series Intel CPU game, record and stream feature
Experience in-game performance like never before

Enter the realm of extreme performance where game play is so life-like it is difficult to tell where reality ends and the game begins. Surrounded by multiple high-res displays and premium audio sound, you are totally immersed in the action of your AAA game title or the latest virtual reality thriller. Play extreme, live extreme, game extreme on a computer with an unlocked Intel Core X-series processor.

And because modern gaming extends beyond just gameplay, you want to simultaneously share your gameplay with the community and the world. Record all the action capturing that once in a life-time manoeuvre that brought you to victory, and convert your game play into a shareable format to immediately post on your social media page. That is extreme mega tasking and the power of the Intel Core X-series processor.

X299 Chipset and Intel X-Series Processor

Intel X-series processor chipset
A CPU Built for the ultimate platform

The Intel X299 chipset paired with intel Core X-series processors provide a world class platform for gaming, content creation and over-clocking. Whether it is responsiveness, expandability or performance you crave, this platform has you covered. Integrated USB 3.0 makes moving files to your tablet and smartphone blazing fast.

The platform also provides RAID support on PCI Express and Serial ATA storage devices, fast data transfers with support for PCIe 3.0 storage devices and finally, Intel Optane Memory support. Want to push the envelope with overclocking? The Intel X299 chipset and Intel Core X-series processor family bring new unlocked base clock capabilities.

Unlock your individual cores and memory frequencies to amazing levels while having the flexibility to keep other areas within specification. With support for Intel Extreme Memory Profiles (XMP), Intel Extreme Tuning Utility (XTU), and the Intel Performance Tuning Protection Package Plan the capabilities of the Intel X299 chipset and new Intel Core X-series processors are a threat to every overclocking world record.

Advanced Creativity Levels Through Intel CPU

Advanced speeds with creative technicalities
Intel CPU: less waiting and more creating

Your creativity is limitless and once you are in the flow of ideas, you need a system that will keep up. You need the uncompromising performance in a PC powered by the Intel Core X-series processor. The Intel Core X-series processor family with 8, 12 or even 18 cores delivers amazing performance when multiple real-time workloads are stacked.

Spend more time creating while your Intel Core X-series CPU powered system simultaneously handles uploading massive 4K files, rending effects and other compute intensive workloads in the background. And with the updated Intel Turbo Boost Max Technology 3.0, you have the control to give priority to the apps that need the power of the two best performing cores.

Quad channel memory also delivers improved responsiveness and decreases start up time when you are working with large files and content creation applications. With an Intel Core X-series processor you can focus on creating with the confidence your results will be as remarkable as you imagined.

Intel Core X-Series i7-7820X CPU Features

Turbo Boost Tech 2.0 Turbo Boost 2.0

Dynamically increases the processor’s frequency, as needed, by taking advantage of thermal and power headroom when operating below specified limits.

Turbo Boost Tech 3.0 Turbo Boost 3.0

Identifies the two fastest cores on the processor die to provide improved single threaded performance on X-series processors. The driver provided along with the feature allows end users to direct workloads to the fastest core by setting priority to preferred applications.

Integrated Memory Controller Integrated Memory Controller

Supports up to 4 channels of DDR4 (up to 2666) memory with 1 DIMM per channel. Support for the Intel Extreme Memory Profile (Intel XMP) specification, revision 2.0 for DDR4.

Advanced Encryption Standard Advanced Encryption Standard

A fast, secure AES engine for a variety of encryption apps, including whole disk encryption, file storage encryption, conditional access of HD content, internet security, and VOIP. Consumers benefit from protected internet and email content, plus fast, responsive disk encryption.

Overclocking Enabled Overclocking Enabled

Fully unlocked core multipliers, power, base clock and DDR4 memory ratios for amazing flexibility with overclocking.

PCI Express 3.0 PCI Express 3.0

Offers up to 8GT/S for fast access to peripheral devices and networking up to 40 lanes.

Smart Cache Smart Cache

Larger amounts of shared cached allows faster access to your data by enabling dynamic and efficient allocation of the cache to match the needs of each core significantly reducing latency to frequently used data and improving performance.

Virtualization Technology Virtualization Tech

Allows one hardware platform to function as multiple “virtual” platforms. Offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.

Intel X299 Chipset X299 Chipset

The X-Series CPU are supported by the new Intel X299 Chipset.

Green Technology Green Tech

Manufactured with lead-free and halogen-free component packages.

Intel Optane Memory Optane Memory

Provides performance improvements as well as fast app response times for system acceleration and responsiveness.

Hyper Threading Tech Hyper Threading Tech

Delivers two processing threads per physical core. Highly threaded applications can get more work don’t parallel, completing tasks sooner.

Specifications
CPU Type Intel Core i7
CPU Model 7820X
Socket 2066
Architecture Skylake-X
Manufacturing Process 14 nm
No. of Cores 8 Core
No. of Threads 16
Core Ratio 36 x
Clock Speed 3.6 GHz
Turbo Speed 4.3 GHz
Max. Turbo Speed (On 2 Cores Only) 4.5 GHz
Intel Turbo Boost Max Technology 3.0 Yes
FSB Speed N/A
QPI Speed N/A
UPI Links/Speed N/A
DMI Speed 8 GT/s
Unlocked Core Multiplier Yes
Unlocked Full Range Base Clock (B-Clock) Yes
Max. Memory Size 128 GB
Max. Memory Speed DDR4 - 2666
Max. Memory Channels 4 (Quad Channel)
ECC Memory Support Not Supported
Intel Optane Memory Support Yes
Max. PCIe Lanes Supported 28
Processor Graphics N/A
Base GPU Speed N/A
Max. GPU Speed N/A
Max. GPU Resolution N/A
L1 Cache 8x 32 KB instruction caches, 8x 32 KB data cache
L2 Cache 8x 1MB
L3 Cache *See Intel Smart Cache*
Intel® Smart Cache 11MB
Voltage
Max. TDP 140W
Thermal Specification
Heatsink Not Included, Sold Separately
Package Type OEM
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
12 months
Type:
Return to base
DOA Period:
28 days
RTB Period:
1 months
Manufacturer Contact Details
Manufacturer:
Intel
