Intel Quad Core i7 7740X Unlocked OEM CPU/Processor

Intel Core i7 7740X, S 2066, Kaby Lake-X, Quad Core, 8 Thread, 4.3GHz, 4.5GHz Turbo, 8MB, 16 Lane, 112W, CPU, OEM

Intel
Scan code: LN82209 Manufacturer code: CM8067702868631 Request call
£285.49
Pay on Scan Finance with a 10% deposit from just £7.13 / month (APR 15.9%)
High End
Delivery options £5.48 By DPD On 24th Oct 2017 DPD Delivered to your specified address. Receive SMS with one-hour delivery window. £4.79 Collect from local shops UPS and DPD Pickup Collect your parcel from your newsagents, petrol stations and convenience stores. Free Collect Instore Q-Collect Place your order online and collect from our Bolton store with Q-Collect. Weekend, timed and European delivery options are available at checkout ScanProtect protection ScanProtect Protect against installation damage for 28 days.More
Frequently Bought Together

Quad Core i7 7740X CPU. Intel X-Series Processor Family. OEM Version

Intel i7 X-Series Processor / CPU
Powerful performance from intel Kaby Lake X Processor

X-Series processors come in all sizes and speeds, ensuring you can find the CPU best suited to your needs. Intel’s i7-7740X is the first of their i7 family. The 7740X not only doubles the threads of it's X-series Core i5 predecessor, it pushes other technologies such as frequency speeds and Smart Cache further. It maintains the same dual channel DDR4 support (2666) and like all X-Series CPU’s runs on the 2066 socket(LGA).

The Intel Core i5-7640X and Core i7-7740X are quad core processors for the gaming enthusiast. Read more on this below.

This is the OEM version of the X-series i7-7740X

4.3GHz
Clock Speed
4
Cores
8
Threads
16
Lanes
8MB
Cache

X-Series Gaming, Recording and Streaming Performance

X-series Intel CPU game, record and stream feature
Experience in-game performance like never before

Enter the realm of extreme performance where game play is so life-like it is difficult to tell where reality ends and the game begins. Surrounded by multiple high-res displays and premium audio sound, you are totally immersed in the action of your AAA game title or the latest virtual reality thriller. Play extreme, live extreme, game extreme on a computer with an unlocked Intel Core X-series processor.

And because modern gaming extends beyond just gameplay, you want to simultaneously share your gameplay with the community and the world. Record all the action capturing that once in a life-time manoeuvre that brought you to victory, and convert your game play into a shareable format to immediately post on your social media page. That is extreme mega tasking and the power of the Intel Core X-series processor.

Core X-Series CPU and X299 Chipset Combo

Intel X-series processor chipset
A CPU Built for the ultimate platform

The Intel X299 chipset paired with intel Core X-series processors provide a world class platform for gaming, content creation and over-clocking. Whether it is responsiveness, expandability or performance you crave, this platform has you covered. Integrated USB 3.0 makes moving files to your tablet and smartphone blazing fast.

The platform also provides RAID support on PCI Express and Serial ATA storage devices, fast data transfers with support for PCIe 3.0 storage devices and finally, Intel Optane Memory support. Want to push the envelope with overclocking? The Intel X299 chipset and Intel Core X-series processor family bring new unlocked base clock capabilities.

Unlock your individual cores and memory frequencies to amazing levels while having the flexibility to keep other areas within specification. With support for Intel Extreme Memory Profiles (XMP), Intel Extreme Tuning Utility (XTU), and the Intel Performance Tuning Protection Package Plan the capabilities of the Intel X299 chipset and new Intel Core X-series processors are a threat to every overclocking world record.

Quad Core Intel Processor Power Output

Intel's Quad Core processors from the new X-Series range
Newcomers to the Intel Quad Core CPU family

The new family of Intel Core X-series processors introduces two quad core processor for broader expandability of the platform. The Intel Core i5-7640X and Intel Core i7-7740X enable customers to invest in a more powerful enthusiast platform that provides more headroom and scalability up the X-series stack when they are ready.

These two processors will start with a slightly higher base frequency and provide all of the ingredients, like higher memory speed and larger socket, for better overclocking performance compared to their mainstream counterparts.

Intel Core X-Series i7-7740X CPU Features

Turbo Boost Tech 2.0 Turbo Boost 2.0

Dynamically increases the processor’s frequency, as needed, by taking advantage of thermal and power headroom when operating below specified limits.

Integrated Memory Controller Integrated Memory Controller

Supports up to 2 channels of DDR4 (up to 2666) memory with 1 DIMM per channel. Support for the Intel Extreme Memory Profile (Intel XMP) specification, revision 2.0 for DDR4.

Advanced Encryption Standard Advanced Encryption Standard

A fast, secure AES engine for a variety of encryption apps, including whole disk encryption, file storage encryption, conditional access of HD content, internet security, and VOIP. Consumers benefit from protected internet and email content, plus fast, responsive disk encryption.

Overclocking Enabled Overclocking Enabled

Fully unlocked core multipliers, power, base clock and DDR4 memory ratios for amazing flexibility with overclocking.

PCI Express 3.0 PCI Express 3.0

Offers up to 8GT/S for fast access to peripheral devices and networking up to 40 lanes.

Intel X299 Chipset X299 Chipset

The X-Series CPU are supported by the new Intel X299 Chipset.

Virtualization Technology Virtualization Tech

Allows one hardware platform to function as multiple “virtual” platforms. Offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.

Smart Cache Smart Cache

Shared cached allows faster access to your data by enabling dynamic and efficient allocation of the cache to match the needs of each core significantly reducing latency to frequently used data and improving performance.

Green Technology Green Tech

Manufactured with lead-free and halogen-free component packages.

Intel Optane Memory Optane Memory

Provides performance improvements as well as fast app response times for system acceleration and responsiveness.

Hyper Threading Tech Hyper Threading Tech

Delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.

Specifications
CPU Type Intel Core i7
CPU Model 7740X
Socket 2066
Architecture Kaby Lake-X
Manufacturing Process 14 nm
No. of Cores Quad Core
No. of Threads 8
Core Ratio 43 x
Clock Speed 4.3 GHz
Turbo Speed 4.5 GHz
Max. Turbo Speed (On 2 Cores Only) N/A
Intel Turbo Boost Max Technology 3.0 No
FSB Speed N/A
QPI Speed N/A
UPI Links/Speed N/A
DMI Speed 8 GT/s
Unlocked Core Multiplier Yes
Unlocked Full Range Base Clock (B-Clock) Yes
Max. Memory Size 64 GB
Max. Memory Speed DDR4 - 2666
Max. Memory Channels 2 (Dual Channel)
ECC Memory Support Not Supported
Intel Optane Memory Support Yes
Scalability
Max. PCIe Lanes Supported 16
Processor Graphics N/A
Base GPU Speed N/A
Max. GPU Speed N/A
Max. GPU Resolution N/A
L1 Cache 4x 32 KB instruction caches, 4x 32 KB data cache
L2 Cache 4x 256KB
L3 Cache *See Intel Smart Cache*
Intel® Smart Cache 8MB
Voltage
Max. TDP 112W
Thermal Specification
Heatsink Not Included, Sold Separately
Package Type OEM
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
12 months
Type:
Return to base
DOA Period:
28 days
RTB Period:
1 months
Manufacturer Contact Details
Manufacturer:
Intel
