Intel Core i7 6700K Unlocked OEM Skylake Desktop Processor/CPU

Intel Core i7 6700K, S 1151, Skylake, Quad Core, 4.0GHz, 4.2GHz Turbo, 8MB Cache, 1150MHz GPU, 40x Ratio, 91W, CPU, OEM

Intel
Scan code: LN68285 Manufacturer code: CM8066201919901 Request call
£329.48
Pay on Scan Finance with a 10% deposit from just £8.23 / month (APR 15.9%)
High End
Delivery options £5.48 By DPD On 23rd Jan 2018 DPD Delivered to your specified address. Receive SMS with one-hour delivery window. £4.79 Collect from local shops UPS and DPD Pickup Collect your parcel from your newsagents, petrol stations and convenience stores. Free Collect Instore Q-Collect Place your order online and collect from our Bolton store with Q-Collect. Weekend, timed and European delivery options are available at checkout ScanProtect protection ScanProtect Protect against installation damage for 28 days.More
Frequently Bought Together

i7 6700K Intel® Core™ Processor OEM

Take control with the 6th Generation Intel® Core™ processors codenamed “Skylake-S”. The i5 6600K is the flagship processor of the Skylake-S line-up that features exceptional performance that is increased by up to 22% and offers 6x faster storage bandwidth for quicker media access, all this means for an all-round more responsive PC. The ‘K’ prefix shows that this CPU is Unlocked and has overclocking enabled this is great news for extreme gamers and enthusiasts. Improved overclocking is supported on the 6700K when in conjunction with Z170 chipsets only, it uses the BCLK (base clock) overclocking feature.

Intel Core i7 Inside - 1151 Socket

Exceptional Performance
The Intel® Core™ i7 6700K boasts a 4.0 GHz base frequency and 4.2 GHz turbo frequency, the processor is also built on a 14 nm process, with a 91 W maximum TDP. The chip is a Quad-Core design with 8 threads. Integrated into the processor is Intel® HD Graphics 530 which delivers mainstream-level graphics with discrete-level performance and has full support for DirectX 12 API. Intel’s 6700K is fully unlocked allowing you to tune performance and obtain higher frequencies when used with Intel 100 series chipsets. Previous generation Intel processors such as the Intel® Core™ i7-4790K processor used DDR3 memory, typically running at 1600 or 2133MHz. The Core i7 6700K have an enhanced memory controller that supports DDR4 memory, giving you a very healthy performance boost over DDR3.

Intel® Core™ i7 is a brand name applies to several families of desktop and laptops, The Core™ i7 brand targets the business and high-end consumer markets for both desktop and laptop computers, and is distinguished from the enty-level Core™ i3 and the more mainstream Core™ i5.

Dramatic Increase in Media & Graphics
Intel® HD Graphics 530 can easily deliver an amazing visual experience in resolutions all the way up to Ultra HD 4K, so you can make the most of 4K displays. The Intel® Core™ i7 6700K also has support for the latest graphics APIs such as DirectX 12, this means that you will be able to run mainstream games and apps up to 2x better graphics than previous generation processors. Intel's on-board graphics processor is up to 28% faster than previous generation GPUs.

Intel HD Graphics 530
Intel 100 Series Chipset

Intel® Core™ Processor Features

Intel® Turbo Boost Technology 2.0
Dynamically increases the processor’s frequency, as needed, by taking advantage of thermal and power headroom when operating below specified limits.

Intel® Hyper-Threading Technology
Delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.

Intel® HD Graphics
Play HD videos with exceptional clarity, view and edit even the smallest details of photos, and play today’s modern games.

Intel® Quick Sync Video
Delivers excellent video conferencing capability, fast video conversion, online sharing, and fast video editing and authoring.

Intel® Clear Video HD Technology
Visual quality and colour fidelity enhancements for HD playback and immersive web browsing.

Integrated Memory Controller
DDR4 Memory offers stunning read/write performance through efficient prefetching algorithms, lower latency, and higher memory bandwidth.

Intel® Virtualisation Technology
Offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.

Intel® AES
Advanced Encryption Standard Instructions engine for a variety of encryption apps, whole disk encryption, file storage encryption, internet security, and VoIP.

Intel® Power Optimizer
increases periods of silicon sleep state across the platform ingredients, including the CPU, chipset, and third-party system components, to reduce power.

CPU / Memory / Graphics Overclocking
On select products, CPU / graphics and memory can be run at frequencies above the rated frequency of the part resulting in higher performance.

Intel® Secure Key
Security hardware-based random number generator that can be used for generating high-quality keys for cryptographic (encryption and decryption) protocols.

Intel® Transactional Synchronization Extensions
TSX-NI is a set of instructions focused on enterprise-level multi-threaded performance scaling, making parallel operations more efficient.

Intel® Advanced Vector Extensions 2.02
AVX 2.0 has new optimized instructions to deliver enhanced performance on floating point–intensive apps.

Intel® OS Guard
A hardware-based security feature that protects the OS (operating system) kernel. OS Guard helps prevent use of malicious data or attack code.

Intel® Ready Mode Technology
Provides quick access to your PC with applications that are up-to-date and constantly connected.

Intel® Identity Protection Technology
Protect your one-time-password (OTP) credentials and PKI certificates and add a layer of encrypted second factor authentication for online transactions.

Green Technology
Manufactured with lead-free and halogen-free component packages

Conflict Free
Does not contain conflict minerals that directly or indirectly finance or benefit armed groups in the Democratic Republic of the Congo (DRC) or adjoining countries.

Specifications
CPU Type Intel Core i7
CPU Model 6700K
Socket 1151
Architecture Skylake
Manufacturing Process 14 nm
No. of Cores Quad Core
No. of Threads 8
Core Ratio 40 x
Clock Speed 4.0 GHz
Turbo Speed 4.2 GHz
Max. Turbo Speed (On 2 Cores Only) N/A
Intel Turbo Boost Max Technology 3.0 No
FSB Speed N/A
QPI Speed N/A
UPI Links/Speed N/A
DMI Speed 8 GT/s
Unlocked Core Multiplier Yes
Unlocked Full Range Base Clock (B-Clock) Yes
Max. Memory Size 64 GB
Max. Memory Speed DDR4 - 2133 / DDR3L - 1600
Max. Memory Channels 2 (Dual Channel)
ECC Memory Support Not Supported
Intel Optane Memory Support No
Scalability
Max. PCIe Lanes Supported 16 (CPU) + 20 (PCH)
Processor Graphics Intel HD Graphics 530
Base GPU Speed 350 MHz
Max. GPU Speed 1150 MHz
Max. GPU Resolution 4096x2304 (4K)
L1 Cache 4x 32 KB instruction caches, 4x 32 KB data cache
L2 Cache 4x 256KB
L3 Cache *See Intel Smart Cache*
Intel® Smart Cache 8MB
Voltage
Max. TDP 91W
Thermal Specification
Heatsink Not Included, Sold Separately
Package Type OEM
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
12 months
Type:
Return to base
DOA Period:
28 days
RTB Period:
12 months
Manufacturer Contact Details
Manufacturer:
Scan OEM
Telephone:
0871 472 4747
Customers also bought
TekSpek Guides
Intel Core i5 6600K and Core i7 6700K
Intel Core i5 6600K and Core i7 6700K
Date Issued: 26th Aug 2015

Intel generally follows a tick-tock philosophy for new processor launches. The tick represents a shrinking of the manufacturing process - 32nm to 22nm, for example - while the tock is indicative of a new architecture based on the leading process of that time. This has been the case since 2007.

Read More

Reviews
Intel Core i7 6700K, S 1151, Skylake, Quad Core, 4.0GHz, 4.2GHz Turbo, 8MB Cache, 1150MHz GPU, 40x Ratio, 91W, CPU, OEM is rated 4.7 out of 5 by 11.
Rated 5 out of 5 by from insane cpu i went with this OEM listing over the retail one because it was about £10 cheaper. the only difference is the packaging. the retail has a nice box with paperwork and the cpu in a plastic case. the OEM came in a little black cardboard box protected by non static foam. i have no need for a fancy box but i know some people like to display their boxes so you just need to decide if it's worth the extra money for the packaging. this cpu replaces my i5-4590. at stock it feels way much faster even during normal system use. programs noticeably open much quicker. it just generally makes everything much faster/smoother and more responsive. i managed to overclock to 4.4Ghz at 1.30V, 4.5GHz at 1.35V and at 4.6Ghz it was using 1.44V but it may be possible to lower that voltage. i haven't tested it fully yet. right now i'm running at 4.5Ghz 1.35V / DDR4 2933 1.35V very stable. temperature wise the CPU doesnt go over 76C when running Prime95 blend test (hyper 212x cooler). lowest it goes under normal use is about 25C although i have seen it go as low as 19C but this is after start up and before the system warms up. really happy with my purchase. if you're just gaming you could probably get away with an i5-6600K but i wanted to future proof as more and more games are requiring an i7. this cpu should last you years.
Date published: 2016-07-04
Rated 4 out of 5 by from Capable processor As expected, Intel's i7 6700K is a fast - 4-core processor with the power to carry out many tasks, for a reasonable power consumption. With just 65W TDP (in a standard non-overclocked environment) it's economical, yet provides the opportunity to be over-clocked for those who need the extra speed.
Date published: 2016-06-26
Rated 5 out of 5 by from Great CPU with GPU built in Works well for me. I don't need a huge graphics capability so just went for this. I did notice the graphics stutter during speed tests on data transfer using my M.2 NVME card. Other than that its fast and works well with ASUS Z170 p MOBO and M.2 memory
Date published: 2016-05-20
Rated 5 out of 5 by from Best one out there so far! This is my first purchase of an Intel i7 CPU, and I have to say, I am not disappointed. I use it for video editing and it performs like a dream with eight threads to utilize; it makes short work of rendering. I deliberately chose not to buy an alternate versions which included a cooler, as I have always hated the bog standard Intel offering, not to mention the fitting!
Date published: 2016-05-02
Rated 5 out of 5 by from Worthwhile upgrade to any desktop CAD workstation Good price point and solid performance make this a great core to any cad system. If your Mother board doesn't support Skylake Go get a new one!
Date published: 2016-03-10
Rated 5 out of 5 by from Superb Processor I would recommend installing this processor, runs perfectly, and does not get hot, easy to install and unbelievable value from Scan. Highly recommend.
Date published: 2016-03-09
Rated 5 out of 5 by from Great Works perfectly. No need for a nice box in my opinion.
Date published: 2016-02-28
Rated 3 out of 5 by from Bought the OEM only to find out that retail version was being sold for less else where! This processor was listed as OEM and was about £30 cheaper than the retail version. OEM version is sold in a very basic cardboard packaging. The CPU itself was as expected, but was returned without opening the box as I found that retail version could be bought cheaper at another online site.
Date published: 2016-02-03
  • y_2018, m_1, d_20, h_5
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.6
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_11
  • loc_en_GB, sid_68285, prod, sort_[SortEntry(order=FEATURED, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_scan
Questions & Answers

Does Intel Skylake i7-6700K include a cooling fan?

Intel used to provide fans but my last i7 did not include one. http://www.scan.co.uk/products/intel-core-i7-6700k-s1151-oem
Asked by: Roboman28
nope. with skylake intel stopped including cooling fans with K chips. this is because you really shouldn't be using their stock cooler when overclocking. you should look at getting a Hyper 212X at least which will let you easily overclock to 4.6Ghz while keep temps under 75C at 100% usage across 8 cores.
Answered by: frankyj
Date published: 2016-07-04

OEM vs non OEM

Is there any difference between OEM and non OEM version of this product. I've noticed a 30 pound difference in price, why exactly is that? I'm planning on purchasing this item in the close future. Thanks!
Asked by: Grabo
the difference is the packaging. if you don't care about it, like myself, get the OEM if it's cheaper (was £10 cheaper for me). my i7 came in a little black cardboard box with non static foam. the retail model comes in a fancy colourful box with paperwork and the CPU in a plastic case.
Answered by: frankyj
Date published: 2016-07-04
