Ceiling Mounted Loudspeaker
HH - TNi-C6 (White)
Tessen Install SeriesThe Tessen TNi-C6 delivers premium audio reinforcement. designed with the installer in mind, The TNi-C6 – 6.5 inch coaxial ceiling speaker - features a 6 position power tap selector located under the front steel grille, providing swift output adjustment once installed. With connectivity for 70V/100V and 8 ohm low impedance lines, The TNi-C6 delivers a highly flexible solution. The spring connection terminals ensure cables are secure once fitted.
113 dBMax SPL
85Hz - 16KHzFrequency Response (-3)
8 ΩImpedance
At A Glance
• 6.5 inch coaxial ceiling speaker
• 6 position power tap selector
• Connectivity for 70V/100V and 8Ω low impedance lines
• Protective front steel grille
HH Electronics
Tessen Installation TNi-C4, TNi-C6, TNi-C8 Ceiling Mount Loudspeaker Range Overview
The Tech Spec
| Features | Specification | 100V Power Options | 40W, 20W, 10W |
|---|---|
| 70V Power Options | 20W, 10W, 5W |
| Frequency Response (-10) | 75Hz > 20kHz |
| Frequency Response (-3) | 85Hz - 16KHz |
| LF Driver | 6.5 Inch, Paper Cone |
| HF Driver | 1.5 Inch Neodymium |
| Low Nominal System Impedance | 8 Ohm |
| Power | 55W AES, 220W Peak |
| Max SPL (1M) (Peak) | 113 dB SPL |
| Sensitivity (1W/1M) | 90 dB SPL |
| Nominal Coverage | 120° conical |
| Input Connector | Push spring connectors |
| Mounting Points | 4x dog ear brackets |
| Mounting Depth | 176mm, (6.9") |
| Installation Grip Range | 4 - 20mm |
| Cutout | 235mm, (9.3") |
| Outside Diameter | 260mm, (10.2") |
| Unit Weight | 2.1 kg, 4.6 lbs |
| Main Construction Material | ABS plastic |
| Grille | 1.5mm circular mesh steel |
| Finish | White |
