Gigabyte NVIDIA GeForce GTX 1070 G1 Gaming Graphics Card
Gigabyte GeForce GTX 1070 G1 Gaming 8GB GDDR5 VR Ready Graphics Card, 1920 Core, 1594 MHz GPU, 1784 MHz Boost
Gigabyte GeForce GTX 1070 G1 Gaming
GIGABYTE G1 GAMING GTX 1070
A remarkable piece of technology, the G1 1070 GAMING from GIGABYTE. Dominate new games at peaked settings, run online games with improved FPS or get creative running 3D and other heavy designer applications without issues. Running with DirectX 12 the 1070 is the next stage in graphic levels.
Take on today’s most challenging graphics intensive PC games without missing a beat. The GeForce GTX 1070 graphics card delivers the incredible speed and power of NVIDIA Pascal™ the most advanced GPU architecture ever created. This is the ultimate gaming platform. #GameReady.
G1 GAMING WindForce Cooling System
WINDFORCE 3X technology features 2 pure composite heat-pipes, special fin architecture and unique blade fan design. These technologies come together to deliver a powerful cooling system with effective dissipation capacity, creating a high performance level at lower temperatures.
ADVANCED GIGABYTE FANS
1070 LED Fan Indicator From GIGABYTE
The semi-passive fans will remain off when the GAMING G1 1070 GPU is under a set loading or temperature for low power gaming. This saves every bit of power possible whilst keeping your PC as silent as possible.
GIGABYTE 1070 Unique Fan Blade Deisgn
The GAMING G1’s airflow is spilt by the triangle fan edge, which is then guided smoothly through the 3D stripe curve on the fan surface. This effectively enhancing the air flow by 23% over traditional fans - increasing the cooling.
GIGABYTE COPPER PIPES
Copper Composite Heat Pipes
GIGABYTES GAMIGN G1 utilizes copper heat-pipes that manages to transfer heat between two solid surfaces through thermal conductivity and phase transition. This causes an increase in cooling capacity of up to 29%.
G1 GAMING HEAT PIPE
GIGABYTE G1 GPU Direct Touch
Specifically shaped to achieve peaked direct contact to the GPU in order to transfer maximum amount of heat possible. The pipes are moulded into a smooth squared shape..
GIGABYTE SPECTRUM RGB LED
LED Customizable Color Lighting
With a total of 16.8M customizable colour options and numerous lighting effects, you can now choose the right scheme for your gaming rig, this can be done quick and easily through XTREME Engine utility.
SMART 1070 POWER LED
GIGABYTE Power Smart 1070 LED
Be alerted when the PCI-E voltage going to your GAMING G1 graphics card abnormal. When this is the cass the LED on your 1070 will flash, when stable it will turn off and when the power cable has been disconnected it will stay on.
OVERCLOCKING YOUR GTX 1070 G1 GAMING
One-Click 1070 GPU Overclocking
Utilizes the XTREME engine for single click overclocking. This makes overclocking much easier for those with zero overclocking knowldge, saving any issue or hassle with a manul approach. Gamers can easily tune the card to meet their various gaming requirements without any overclocking knowledge, while saving the hassle of manual adjustment.
GIGABYTE XTREME Engine
Adjust various attributes of your GTX 1070 and more. Gain control over clock speeds, voltage, fan performance, RGB lighting effect, power target and OSD settings can be monitored and tuned in real-time according to your own preference through this intuitive interface.
GTX 1070 CONNECTIONS
HDMI 2.0b / 3x DisplayPort 1.4 / Dual-Link DVI
GEFORCE GTX VR READY
GeForce® GTX graphics cards provide a powerful next-generation platform for the ultimate immersive virtual reality experience. Rigs and cards marked with "GeForce GTX VR Ready" ensure that your VR games will be optimized with a best-in-class GPU.
Immersive VR requires seven times the graphics processing power of traditional 3D apps and games. NVIDIA's unique set of features - such as multi-res shading - mean you get the right level of performance, image quality, and latency to ensure your VR experience is nothing short of amazing.
|Chipset||GeForce GTX 1070|
|Manufacturing process||16 nm|
|Core Clock||1594 (1620 in OC Mode) MHz|
|Boost Clock||1784 (1822 in OC Mode) MHz|
|Memory Clock||8008 MHz|
|Memory Bus||256 Bit|
|Cooling Solution||Tri Fan (3)|
|Cooler Design||WINDFORCE 3X|
|Interface||PCIe 3.0 (x16)|
|Maximum Digital Resolution||7680x4320 @ 60Hz|
|Maximum Analog (VGA) Resolution||N/A|
|Max. Concurrent Displays||4 Displays|
|NVIDIA SLI Support||2-Way SLi with High Bandwidth Bridge Support|
|GeForce GTX VR Ready||Yes|
|Microsoft DirectX Support||12 API with Feature Level 12.1|
|Low Profile Compatible||No|
|Low Profile Support||N/A|
|Graphics Card TDP/Power||150W|
|Graphics Card Power Connectors||1 x 8-pin PCIe|
|Minimum Recommended PSU||500 W|
|Maximum GPU Temperature|
|Dimensions||115 x 42 x 286 mm|
