Fractal North XL Chalk White Mesh Side Panel Mid Tower PC Case
Fractal North XL Chalk White Mesh Side Panel Mid Tower PC Case
Scan code: LN143170 Manufacturer code: FD-C-NOR1X-03
£164.99Item due on 15 May 2025
Pre Order
Due 15th May
  • Thumbnail 1 : Fractal North XL Chalk White Mesh Side Panel Mid Tower PC Case
  • Thumbnail 2 : Fractal North XL Chalk White Mesh Side Panel Mid Tower PC Case
  • Thumbnail 3 : Fractal North XL Chalk White Mesh Side Panel Mid Tower PC Case
  • Thumbnail 4 : Fractal North XL Chalk White Mesh Side Panel Mid Tower PC Case

Fractal North XL Chalk White Mesh Side Panel Mid Tower PC Case

Fractal North XL Chalk White Mid Tower Chassis, Mesh Side Panel, 3x 140mm Fans, mITX/mATX/ATX/E-ATX(330mm)
MORE INFO
MORE INFO

Scan code: LN143170 Manufacturer code: FD-C-NOR1X-03
£164.99
Item due on 15 May 2025
Pre Order
Due 15th May
Pay in 3 interest-free payments of £55.00

Email me when the availability or price changes

  • By DPD Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout
  • Collect instore Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE) | Free
  • UPS and DPD Pickup Pickup from local convenience store | £4.99 Collect your parcel from your newsagents, petrol stations and convenience stores

Finance this product

  • Spend over £280.00 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
  • SCANPROTECT Protect against installation damage for 28 days.
  • 48HR REPLACEMENT If you need to return this item, your replacement will be dispatched within 2 working days of your product arriving back at Scan.

Suggested Alternatives

Fractal North XL Chalk White Mesh Side Panel Mid Tower PC Case

Fractal North XL

Transformative Design In A Generous Format The North XL offers a transformative take on the gaming PC case in a generous form factor. With fine-patterned mesh ventilation and an open front featuring FSC-certified wooden panel, the design of North XL makes it a stylish addition to any living space while helping components stay cool. The design is complemented by sleek brass or steel details and an integrated tab for easy access to the top of the case. Inside, it boasts a spacious, flexible, and intuitive interior layout so you can make the most of your building aspirations and gaming experience.

3 x 140mmFans Included

7 x 120mm / 6x 140mmFan Bays

29mmCable Routing Space

Mid TowerForm Factor

Impressive Features of the Fractal North XL

DJI Air 3 Drone

Natural designEnjoy a sophisticated looking case which integrates effortlessly into your living space. Enhance your gaming station with an FSC-certified oak or walnut front, a faux leather tab and sleek steel or brass details.

DJI Air 3 Drone

Gaming readyChoose a GPU up to 413 mm, or up to 380 mm with a 420 mm front radiator. Make the most of your build with a generous layout compatible with full E-ATX motherboards.

DJI Air 3 Drone

Extended coolingSupports front radiators up to 420mm and top radiators up to 360mm. Three Aspect 14 PWM fans preinstalled with room to expand up to a total of eight 140mm or nine 120mm fans.

DJI Air 3 Drone

Type-C interfaceThree front USB ports including one USB 3.1 Gen 2 Type-C with speeds up to 20Gbps.

DJI Air 3 Drone

Ventilated performanceNatural ventilation through an open front and a stylishly integrated mesh top panel. The mesh version of the case features a full mesh side panel in addition to the top.

DJI Air 3 Drone

Naturally uniqueEnjoy a unique finish, with front panel bars cut from FSC-certified oak or walnut.

DJI Air 3 Drone

Easy accessRemove the side panels, unclip the front and pop off the top panel using an integrated tab.

DJI Air 3 Drone

Build versatilityMake the most of your building experience with an intuitive interior layout. Designed for E-ATX / ATX / mATX / mITX motherboards.

Specifications
Core Chassis Specifications
Case Edition Fractal North XL Mesh - Chalk White
Case Form Factor Mid Tower
Motherboard Form Factor
  • ATX
  • E-ATX (330 mm)
  • MicroATX
  • Mini-ITX
Back Connect Compatible No
I/O, Bays & Expansion
Front/Side/Top Panel I/O
  • 1 x Headphone Out
  • 1 x Mic In
  • 1 x Power Button
  • 2 x USB 3.0
  • 1 x USB 3.1 Gen2 Type-C
Drive Bays
  • 2 x 2.5" Internal
  • 2 x 3.5" / 1x 2.5"
Standard Expansion Slots 7
Vertical Expansion Slots
Fans & Filters
Fan Bays 9 x 120mm / 8x 140mm
Fans Included 3 x 140mm
Fan Controller/Hub
Dust Filters
  • Front
  • PSU
Liquid Cooling Support
Front Radiator Compatibility
Top Radiator Compatibility
  • 1 x 280/360mm
  • 1 x 360/420mm
Bottom Radiator Compatibility
Rear Radiator Compatibility 1 x 120/140mm
Side Radiator Compatibility
Clearances
Max CPU Cooler Height 155 with Fan Bracket / 185 w.o mm
Max GPU Card Length 413 with front fan mounted / 380 with 420/360 front mounted Rad mm
Cable Routing Space 29 mm
Side Panels
Window/s No
Window Configuration
Window Construction
LED Lighting Functionality
LED Lighting No
LED Lighting Emitters
LED Lighting Colour
LED Lighting Support & Control
Power Supply Compatibility
PSU Included No
PSU Wattage (If Included)
PSU 80+ Rating (If Included)
PSU Support ATX
PSU Mounting Location Bottom Mount, Rear
Max PSU Length 1 HDD Tray: 290 mm max / 2 HDD Tray: 175 mm max mm
Chassis Physical Specifications
Colour White
Chassis Construction Materials Steel
Dimensions 240 X 509 X 503 (WxHxD mm)
Weight 9.7 kg (Approx)
Package Type
Please Note
Additional Information
Scan Code LN143170
Model Number FD-C-NOR1X-03
GTIN 7340172706557
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
24 months
Type:
Return to base
DOA Period:
28 days
RTB Period:
12 months
Manufacturer Contact Details
Manufacturer:
Fractal Design
