Focusrite 18i16 18 In/16 Out USB Audio Interface
Focusrite - 18i16 18 In/16 Out Desktop USB Audio Interface with 4 Mic Preamps, SPDIF and ADAT
- SCANPROTECT Protect against installation damage for 28 days. More info
18-In/16-Out USB Audio Interface
Focusrite - Scarlett 18i16
The Original. Remastered.The Focusrite Scarlett 18i16 is the perfect interface for creative recording artists. Featuring world-class converters taken directly from Focusrite’s RedNet range and four 4th Gen mic preamps with an impressive 69dB of gain, capable of capturing the most dynamic performances. Auto Gain and Clip Safe modes handle the levels so you can focus on the take. Scarlett 18i16 is the ideal hub to integrate your DAW and hardware with enough analogue and digital I/O to connect external instruments, processors, and effects, and manage complex routing with incredible ease via Focusrite Control 2 software.
USB Type-CConnectivity
24-bit/192 kHzA/D Resolution
20 x 18Simultaneous I/O
Amazing Features
• 18 inputs and 16 outputs; including four mic preamps, line, instrument, and MIDI I/O
• Re-engineered Air mode with Presence and Harmonic Drive
• 24-bit, 192 kHz conversion with 120dB of dynamic range
• 4th Gen pre-amps with 69dB of gain
• Auto Gain and Clip Safe modes
• Super-low latency monitoring
• Three-year warranty
Capture Every Detail
Class-leading audio qualityFeaturing the same converters taken from Focusrite’s broadcast-ready RedNet range, Scarlett 18i16 is the industry-leading USB audio interface for project studios. You get 18 inputs and 16 outputs — including four mic preamps, Hi-Z instrument and line inputs, ADAT, SPDIF, and MIDI connectivity. The 4th Generation preamps provide an impressive 69dB of headroom, so you can capture the most dynamic performances. With a total of six analogue inputs, you have plenty of connectivity for outboard gear. Powerful outputs provide clean, ultra-low distortion playback; plus, two brand new custom-designed headphone amps which can drive high-impedance headphones.
The Scarlett 18i16 uses completely revamped audio circuitry, equipped with the same professional-grade 24-bit, 192kHz converters found in Focusrite’s RedNet range, used in top recording studios and broadcast facilities worldwide. Experience unmatched clarity with 120dB of dynamic range to capture everything from a whisper to a jet engine.
Enhance Your Sound
Air modeRe-engineered Air mode takes your sound’s unique character and pushes it to the front of the mix, adding musical presence or rich harmonic drive to vocals and acoustic instruments; replicating the sound of driving a classic studio console.
Auto GainScarlett 18i16 features unique workflow tools designed to benefit engineers of all levels. With Auto Gain, in just a few seconds, Scarlett will set the perfect level for whatever you’re recording. Set usable levels for multiple microphones instantly, so you can get complex sessions up and running quickly.
Clip SafeWith Clip Safe actively monitoring levels up to 96,000 times per second, Scarlett 18i16 automatically adjusts gain to prevent clipping so you avoid introducing any unwanted artefacts from hard limiting. Never miss a crucial take, especially in high-pressure recording environments such as live shows and location recordings.
App ControlThe Focusrite Control 2 software simplifies setting up routing, levels, monitor mixes, and other functions on Scarlett 18i16 in addition to the desktop application, the iOS and Android Focusrite Control 2 apps, so engineers and performers can adjust monitor mixes and mic pre-gains without needing to go back to the computer.
Top-Tier Production Software
all for youThe 4th generation Scarlett 18i16 includes Ableton Live Lite, a three-month subscription to Pro Tools Artist, three months of Splice Sounds, and a comprehensive selection of software instruments, processors, and effects from industry-leading names. Unlock a wealth of studio tools for writing, recording, mixing, and mastering. Focusrite’s Easy Start web tool will get 18i16 up and running with zero effort, helping you locate the drivers, take you through the installation process, and direct you towards the included software.
• Antares® Auto-Tune® Access
• Softube® Marshall® Silver Jubilee 2555
• Native Instruments® MASSIVE
• Sonnox VoxDoubler
• Landr Studio, plus five free masters
• Brainworx® bx_console Focusrite SC
• Focusrite Red 2 & 3 Plug-in Suite
• XLN Audio® Addictive Keys
• XLN Audio® Addictive Drums 2: Studio Rock
• Relab’s LX480 Essentials
• FAST Balancer
The Tech Spec
Features | Specification | Number of Microphone Preamps | 4 |
---|---|
Phantom Power | Yes (Independent) |
Instrument Inputs | 2 |
Line Inputs | 8 |
Air Mode | Yes |
Auto Gain | Yes |
Clip Safe | Yes |
Line Outputs | 4 |
Headphone Outputs | 2 |
ADAT Inputs | 1 |
ADAT Outputs | 1 |
SPDIF Input | 1 |
SPDIF Output | 1 |
MIDI Input | 1 |
MIDI Output | 1 |
Loopback | Yes |
Connectivity | USB Type-C |
Protocol | USB 2.0 |
Form Factor | Desktop |
Simultaneous I/O | 20 x 18 (including Loopback) |
A/D Resolution | 24-bit/192 kHz |
Bus Powered | Yes 3A |
Software Compatibility | Scarlett 18i16 is class compliant so will work with Mac, Windows PC, Chromebook, and USB-C iPad |
Power Requirements | USB-3.0 Bus power 5V @3A 15W External power supply: 5V @ 3A (included) |
Dimensions (WxHxD) | 240 x 60.5 x 169.4mm |
Weight | 1.494 kg/3.29 lbs (without accessories) 1.738 kg/3.83 lbs (with accessories) |
