Fender Quantum HD 8 USB-C Audio Interface
Fender - Quantum HD 8, 26 x 30 USB-C Recording Interface with MAX-HD Mic Preamps, 32-bit / 192 kHz
Email me when the availability or price changes
Finance this product
- From £26.09 / month (APR 16.9%) for 36 months or 0% for 4 months
- With a 10% deposit from just £18.61 / month (APR 15.9%)
- SCANPROTECT Protect against installation damage for 28 days.
USB-C Audio Interface
Fender - Quantum HD 8
26 x 30 USB-C recording interface with MAX-HD mic preamps and 32-bit / 192 kHz convertersThe Fender Quantum HD 8 delivers high-performance precision with 26 x 30 channels, ADAT expansion, and versatile monitoring—perfect for full-band recordings and complex production setups. Featuring MAX-HD mic preamps, ultra-low-latency drivers, and 32-bit / 192 kHz converters, the HD 8 captures every detail of instruments, vocals, and line-level sources with studio-grade fidelity.
Front-facing Fender instrument inputs, Auto Gain, and re-amp outputs provide fast setup and creative flexibility. Expanded I/O includes ADAT inputs and outputs, additional TRS line outputs, MIDI I/O, and ADAT preamp standalone mode — making it easy to scale your studio and accommodate larger sessions.
Control preamp gain, phantom power, and outputs through Fender Studio Pro or the Universal Control app, while built-in DSP monitor mixing and loopback routing ensure a streamlined workflow. The HD 8 also comes with a perpetual Fender Studio Pro license.
at a glance
• Expanded Digital I/O: 16 ADAT channels, S/PDIF I/O, and ADAT preamp standalone mode
• Front-facing Fender instrument inputs optimized for guitar and bass
• Auto Gain button for fast and accurate recording levels
• Re-amp outputs for creative tone experimentation
• DSP monitor mixer and loopback routing for streaming and recording
• Control preamps, phantom power, and outputs via Fender Studio Pro or Universal Control app
• Fender Studio Pro Perpetual Included – Professional DAW with Mustang and Rumble plug-in
• Full-colour high-resolution display with illuminated push encoder for intuitive operation
• MIDI I/O and DC-coupled line outputs for modular synth control
Feature Highlights
HIGH-FIDELITY PERFORMANCECapture every nuance with MAX-HD mic preamps and 32-bit / 192 kHz converters, paired with ultra-low-latency drivers—delivering pristine, professional-quality audio for complex multi-instrument sessions.
INSTRUMENT INPUTS & RE-AMP OUTPUTSFront-facing Fender instrument inputs and dedicated re-amp outputs provide fast setup, transparent guitar and bass tone, and creative flexibility for recording and experimenting with amp-driven sounds.
PRO SOFTWARE INCLUDEDJump into production with Fender Studio Pro included. Record, mix, and perform using a professional DAW with intuitive workflow, creative tools, and exclusive Mustang Guitar and Rumble Bass amp plug-ins.
The Tech Spec
| Features | Specification | Headphone Jack | Two - 1/4" TRS Female Stereo |
|---|---|
| Connectivity | USB-C |
| Voltage | 230V UK |
| Phantom Power | +48 VDC |
| Digital Audio Bit Depth | 32-bit |
| Digital Audio Dynamic Range | 124 dB |
| Instrument Inputs Dynamic Range | 111 dB (A-Weighted, Minimum Gain) |
| Instrument Inputs Frequency Response | 20 Hz to 20 kHz, +/- 0.1 dB (Unity Gain, Reference 1 kHz) |
| Instrument Inputs Gain Range | 75 dB |
| Instrument Inputs Maximum Level | +21 dBu (Unbalanced, Minimum Gain) |
| Line Inputs Dynamic Range | 118 dB (A-Weighted, Minimum Gain) |
| Line Inputs Frequency Response | 20 Hz to 20 kHz, +/- 0.1 dB (Unity Gain, Reference 1 kHz) |
| Line Inputs Gain Range | ± 10 dB |
| Line Inputs Impedance | 10K Ohms |
| Line Inputs Maximum Level | +18 dBu (Balanced, Minimum Gain) |
| Line Inputs Total Harmonic Distortion | 0.001% (1 kHz, Minimum Gain) |
| Microphone Input Connection Type | XLR Female (Combo), Balanced |
| Microphone Preamp Dynamic Range | 116 dB (A-Weighted, Minimum Gain) |
| Microphone Preamp Equivalent Input Noise | -130 dBu (Maximum Gain, 150 Ohms, 20 kHz BW, A-Weighted) |
| Microphone Preamp Frequency Response | 20 Hz to 20 kHz, +/- 0.1 dB (Unity Gain, Reference 1 kHz) |
| Microphone Preamp Gain Control Range | 75 dB |
| Microphone Preamp Input Impedance | 1600 Ohms |
| Microphone Preamp Maximum Input Level | +18 dBu (Balanced, Minimum Gain) |
| Microphone Preamp Total Harmonic Distortion | 0.002% (1 kHz, Minimum Gain) |
| Headphone Outputs Dynamic Range | 118 dB (A-Weighted) |
| Headphone Outputs Frequency Response | 20 Hz to 20 kHz, +/- 0.3 dB (Unity Gain, Reference 1 kHz) |
| Headphone Outputs Impedance | 33 Ohms |
| Headphone Outputs Maximum Output | 11 dBu (50 Ohms) |
| Headphone Outputs Total Harmonic Distortion | 0.001% (1 kHz) |
| Line Outputs Connection Type | 1/4" TRS Female |
| Main And Line Outputs Dynamic Range | 123 dB (A-Weighted) |
| Main And Line Outputs Frequency Response | 20 Hz to 20 kHz, +/- 0.2 dB (Unity Gain, Reference 1 kHz) |
| Main And Line Outputs Maximum Level | +18 dBu (Balanced) |
| Main And Line Outputs Output Impedance | 51 Ohms |
| Main And Line Outputs Total Harmonic Distortion | 0.001% (1 kHz, +4 dBu) |
| Main Outputs Connection Type | 1/4" TRS Female |
| MIDI IO | 5-Pin Female DIN |
| Word Clock IO | BNC Connector, 4.5 Vpp @ 75Ω Load |
