Electro-Voice - EVOLVE 50 - Portable Column System

Electro-Voice - EVOLVE 50-KB 1000W Portable Column System, Bluetooth Connectivity, QuickSmartDSP, Collapsible Design

Thumbnail 1 : Electro-Voice - EVOLVE 50 - Portable Column System Thumbnail 2 : Electro-Voice - EVOLVE 50 - Portable Column System Thumbnail 3 : Electro-Voice - EVOLVE 50 - Portable Column System Thumbnail 4 : Electro-Voice - EVOLVE 50 - Portable Column System
Scan code: LN125260 Manufacturer code: F.01U.345.828
Order now and get it tomorrow, Wed 6th Jul
£1,469.00
Get it Tomorrow, 06 JulIn stock
FREE DELIVERY ON YOUR ENTIRE BASKET
From £34.33 / month (APR 5.9%) or 0% for 4 months
Monthly Payment: £126.26
Instalment Rate: 5.9% p.a. (fixed)
Cost of purchase: £1,469.00
Total inc. interest: £1,515.11
Monthly Payment: £64.94
Instalment Rate: 5.9% p.a. (fixed)
Cost of purchase: £1,469.00
Total inc. interest: £1,558.53
Monthly Payment: £44.53
Instalment Rate: 5.9% p.a. (fixed)
Cost of purchase: £1,469.00
Total inc. interest: £1,602.72
Monthly Payment: £34.33
Instalment Rate: 5.9% p.a. (fixed)
Cost of purchase: £1,469.00
Total inc. interest: £1,647.79
Example
Minimum Spend: £99
Instalment Rate: N/A
Cost of purchase: £99
Total inc. interest: £99
If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 21.9% and may be even lower.

Representative Example:

Purchase Rate: 21.9% p.a. (variable)

Representative: 21.9% APR (variable)

Assumed Credit Limit: £1,200

Subject to status. Terms and Conditions apply.
With a 10% deposit from just £36.69 / month (APR 15.9%)
Delivery Options
  • By DPD On 6th Jul to your specified address. | Free Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

Portable Powered Column System
Electro-Voice - EVOLVE 50

Electro-Voice EVOLVE 50

Superior Electro-Voice sound qualityThe Electro-Voice EVOLVE 50 Portable Column System is a three component loudspeaker system powered by a 1000 W Class-D amplifier and driven by Electro-Voice's QuickSmartDSP. The system is made up of a 15 mm wooden, ported, powered subwoofer enclosure that houses a 12” subwoofer capable of a functional frequency output as low as 37 Hz. The bi-directional aluminum pole’s connection to the subwoofer is secured by a magnet, and the column array is held to the sub pole by gravit, whilst the signal is internally routed to the components.

Eight 3.5" neodymium drivers in the column array together with the 12" subwoofer delivers up to 127 dB SPL. The eight composite waveguides control high frequencies with 120° of horizontal coverage, and 40° of asymmetrical (down-facing) vertical coverage, so you get suitable output for both sitting and standing audiences. The sub pole and column array also come prepackaged in a carrying bag for easy transport and storage.

127 dBMax SPL

43Hz - 20kHzFrequency Response

1000WTotal Power

at a glance • 8 column-arrayed 3.5" neodymium drivers coupled with a brawny 12" subwoofer that delivers huge power
• Bluetooth connectivity comes built-in so you can configure, control, and monitor up to 6 systems simultaneously
• Made up of 3 components - a column array, subwoofer, and bi-directional aluminum pole
• Composite waveguides provide spacious coverage for the entire venue
• Collapsible design allows for compact storage and easy transport

Enhanced Performance

Electro-Voice EVOLVE 50

Easy SetupThe EVOLVE 50 features a processing engine which allows for easy setup using four presets (Music, Live, Speech, and Club), three-band EQ, five user-programmable presets (Store and Recall settings), output delay, phantom power (+15V), visual monitoring of limiter status, input level control and meters, and master volume control to provide optimal gain structure.

QuickSmart Mobile App

Electro-Voice EVOLVE 50

Wireless ControlThe new Electro-Voice QuickSmart Mobile application uses Bluetooth Low Energy (BTLE) technology for the wireless configuration, control, and monitoring of up to six EVOLVE 50 systems at the same time.

High resolution Bluetooth audio streaming provides additional convenience for wireless music playback in breakout rooms, intermission, and musical accompaniment.

Check Out This Video For The EVOLVE 50!

The Tech Spec

Features Specification
Type Portable PA System
Speaker Drivers 1 x 12" LF, 8 x 3.5" HF
EQ QuickSmart DSP
Inputs 2 x XLR-1/4" combo (mic/line), 1 x 1/8" (aux in), 1 x Dual RCA Stereo (aux in)
Outputs 1 x XLR (mix out), 1 x XLR (thru)
Bluetooth Yes
Power Amp 1000W
Max SPL 127 dB
Frequency Response 43Hz - 20kHz
Enclosure Material 15mm plywood, Composiite, Aluminum
Mounting Options Floor with Column Speaker
Power Source Standard AC IEC power supply
Dimensions Width: 13.6" (sub), 4" (column)
Height: 20.9" (sub), 32.5" (column)
Depth: 18.5" (sub), 6.9" (column)
Weight 57.75 lbs.
Specifications
Number of Speakers N/A
Number of Input Channels N/A
Frequency Response -3dB N/A
Frequency Response -10dB N/A
Coverage (Dispersion H x V ) N/A
HF wattage (RMS)
LF Wattage (RMS) N/A
Maximun SPL N/A
Power rating (Peak) N/A
Power rating RMS N/A
Speaker size N/A
Enclosure Type N/A
Dimensions
Net weight
Shipping weight N/A
Connections (Input) N/A
Connections (Output)
Colour
Bluetooth No
Battery Powered No
Wifi No
App control No
Rigging Points No
Pole Mountable No
Integrated Bracket No
Sub Woofer No
Built in DSP No
Front of House No
Floor Monitor No
Additional Information
Scan Code LN125260
Model Number F.01U.345.828
