Electrovoice - EKX-18S Passive 18" Subwoofer

Electrovoice - EKX-18S Passive 18" Subwoofer, 400W Continuous/1600W Peak Power, 134dB SPL

Thumbnail 1 : Electrovoice - EKX-18S Passive 18" Subwoofer Thumbnail 2 : Electrovoice - EKX-18S Passive 18" Subwoofer Thumbnail 3 : Electrovoice - EKX-18S Passive 18" Subwoofer
Scan code: LN128321 Manufacturer code: F.01U.303.367
Call for price
FREE DELIVERY ON YOUR ENTIRE BASKET
Delivery Options
  • By DPD to your specified address. | Free Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

Services
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

18" Passive Subwfooer
Electrovoice - EKX-18S

Electrovoice EKX-18S

Add some 'Umph' To Your SetupElectrovoice’s EKX-18S is a passive subwoofer perfectly suited for live music settings and DJ applications. Featuring 1600W peak power, the EKX-18S is capable of delivering up to 134dB Max SPL, utilizing high sensitivity transducers designed and engineered by EV for this express purpose. The EKX-18S is lightweight and compact, made from a 15mm wooded enclosure with internal bracing, and durable EVCoat finish. The large slot ports also allow for low distortion and excellent bass extension. The EKX-18S will make a fine addition to your loudspeaker set up, giving you that room filling low end everybody loves!

134 dBMax SPL

1600WPeak Power

Impedance

at a glance • 1600W peak power, 400W continuous power with a maximum SPL of 134dB
• Features highs ensitivity transducers designed and engineered by EV
• Lightweight, compact 15mm wood enclosure with internal bracing, and durable EVCoat finish
• Large slot ports for low distortion and excellent bass extension
• Two metal grille reinforcement bars
• M20 threaded pole mount plate

suitability • Ideally suited to live gigs, clubs & DJ Setups

Electro-Voice EKX Loudspeaker - An Overview

The EKX series is the newest member of the Electro Voice portable loudspeaker family, and combines legendary EV sound quality and reliability with the latest technology — all in a compact package suitable for a wide range of sound reinforcement scenarios, including musicians/DJs and live/club/installed sound applications.

The EKX series features eight models (four powered and four passive), including 12" and 15" two-way models and 15" and 18" subwoofers. EKX is positioned above the ZLX and ELX series and below the ETX series.

The Tech Spec

Features Specification
Frequency Range (-10 dB) 35 Hz - 300kHz (Half Space Measurement)
Minimum Impedance 7.0Ω
Speaker Type Subwoofer
Woofer Size 18inch
Powered or Passive Passive
Frequency Response (-3 dB) 50 Hz - 100Hz (Half Space Measurement)
Max. SPL/1m (calc) 134dB
LF Transducer EVS-18C 457 mm (18 in)
Power Rating 1600W
Connector Type Dual NL4
Enclosure Material 15 mm, plywood with EVCoat
Grille 18 AWG steel with powdercoat
Recommended High-Pass Frequency 30Hz
Dimensions Width: 23.86" (606mm)
Height: 20.47" (520mm)
Depth: 24.09" (612mm)
Net Weight 70.11lbs (31.8kg)
Shipping Weight 88.41lbs (40.1kg)
Family EKX
Nominal Impedance
Axial Sensitivity (SPL, 1 W @ 1 m) 96dB
Power Handling (Continuous / Peak) 400W/1600W
Maximum SPL 134dB
Passive Power Handling 1600W peak
Specifications
Frequency Response -3dB N/A
Frequency Response -10dB 35 Hz - 300kHz
Max SPL 134 (dB)
Power handling (RMS) 400 Watts (RMS)
Power handling (Peak) 1600 Watts (Peak)
Speaker size (inch) 18
Nominal Impedance (Ohms) 8
Enclosure Type Wood
Dimensions Width: 23.86" (606mm) Height: 20.47" (520mm) Depth: 24.09" (612mm)
Net weight 31.8 KG
Shipping weight 40.1 KG
Connections None
Pole Mountable No
Integrated Bracket No
Rigging Points No
Sub Woofer Yes
Front of House No
Floor Monitor No
