EKWB Radeon VII RGB Plexi+Nickel Vector GPU Water Block
EK-Vector Radeon VII RGB Waterblock, Acrylic Plexi Glassl+Nickel-plated, for Radeon VII Reference Graphics Cards
Scan code:
LN97326
Manufacturer code:
3831109816158
This product is no longer available to purchase.
Email me when the availability or price changes
- SCANPROTECT Protect against installation damage for 28 days.
- 48HR REPLACEMENT If you need to return this item, your replacement will be dispatched within 2 working days of your product arriving back at Scan.
Product Overview
EK-FC Radeon VII is a high-performance full-cover water block for multiple AMD® Radeon® VII graphics cards. Please check our Cooling Configurator online compatibility system for detailed compatibility list!
Vector series water blocks are part of the EK Quantum Product Line that emphasizes minimalistic, elegant design, and performance. For those who want to stand out!
This water block directly cools the GPU, 16GB of HBM2 memory, and VRM (voltage regulation module) as cooling liquid is channeled directly over these critical areas. These newly developed water blocks feature a redesigned cooling engine that has a larger footprint compared to the previous generation of EK® Full Cover water blocks. This results in a larger surface area for heat transfer which increases the thermal performance of these water blocks.
The EK® Vector Series water blocks use an Open Split-Flow cooling engine design which proved to be a superior solution for GPU water blocks. It is characterized by low hydraulic flow restriction, which means that it can be used with weaker water pumps, or pumps running on low-speed settings and still achieve top performance. The jet plate and fin structure geometry have been optimized to provide even flow distribution with minimal losses and optimal performances even when used in reversed water flow scenarios.
The base of the block is made of nickel-plated electrolytic copper while the top is made of high-quality acrylic material. Sealing is ensured by high-quality EPDM O-Rings. The brass standoffs are already pre-installed and allow for a safe and easy installation procedure. The front aesthetic corner piece is lit up with LED strip.
This product is compatible with popular RGB sync technologies from all major motherboard manufacturers. The arrow marking on the 4-pin LED connector is to be aligned with the +12V marking on the RGB header.
RGB Compatibility:
• ASUS Aura Sync.
• MSI Mystic Light.
• Gigabyte RGB Fusion.
• ASRock Polychrome Sync.
EKWB recommends the purchase of aesthetic retention backplate which improves the looks of your graphics cards and also provides some passive cooling to the circuit board VRM section. The EK-FC Radeon VII water block is compatible with both Nickel and Black versions of the EK-FC Radeon VII Backplates.
Features • This product should NOT be installed with any aluminum Fluid Gaming parts!
• Radeon VII stock backplates are compatible with EK-Vector Radeon VII water blocks only if installed with the stock backplate screws. For the best performance and aesthetics, EK recommends using the EK-Vector Radeon VII Backplates instead.
Enclosed:
• EK-FC Radeon VII series water block
• Mounting mechanism with screw-in brass standoffs
• Necessary mounting screws, nuts, and washers
• 2x EK plug G1/4”
• 6mm Allen key
• Thermal pads
• Thermal grease EK-TIM Ectotherm (1g)
Vector series water blocks are part of the EK Quantum Product Line that emphasizes minimalistic, elegant design, and performance. For those who want to stand out!
This water block directly cools the GPU, 16GB of HBM2 memory, and VRM (voltage regulation module) as cooling liquid is channeled directly over these critical areas. These newly developed water blocks feature a redesigned cooling engine that has a larger footprint compared to the previous generation of EK® Full Cover water blocks. This results in a larger surface area for heat transfer which increases the thermal performance of these water blocks.
The EK® Vector Series water blocks use an Open Split-Flow cooling engine design which proved to be a superior solution for GPU water blocks. It is characterized by low hydraulic flow restriction, which means that it can be used with weaker water pumps, or pumps running on low-speed settings and still achieve top performance. The jet plate and fin structure geometry have been optimized to provide even flow distribution with minimal losses and optimal performances even when used in reversed water flow scenarios.
The base of the block is made of nickel-plated electrolytic copper while the top is made of high-quality acrylic material. Sealing is ensured by high-quality EPDM O-Rings. The brass standoffs are already pre-installed and allow for a safe and easy installation procedure. The front aesthetic corner piece is lit up with LED strip.
This product is compatible with popular RGB sync technologies from all major motherboard manufacturers. The arrow marking on the 4-pin LED connector is to be aligned with the +12V marking on the RGB header.
RGB Compatibility:
• ASUS Aura Sync.
• MSI Mystic Light.
• Gigabyte RGB Fusion.
• ASRock Polychrome Sync.
EKWB recommends the purchase of aesthetic retention backplate which improves the looks of your graphics cards and also provides some passive cooling to the circuit board VRM section. The EK-FC Radeon VII water block is compatible with both Nickel and Black versions of the EK-FC Radeon VII Backplates.
Features • This product should NOT be installed with any aluminum Fluid Gaming parts!
• Radeon VII stock backplates are compatible with EK-Vector Radeon VII water blocks only if installed with the stock backplate screws. For the best performance and aesthetics, EK recommends using the EK-Vector Radeon VII Backplates instead.
Enclosed:
• EK-FC Radeon VII series water block
• Mounting mechanism with screw-in brass standoffs
• Necessary mounting screws, nuts, and washers
• 2x EK plug G1/4”
• 6mm Allen key
• Thermal pads
• Thermal grease EK-TIM Ectotherm (1g)
