Dune HD Lite 53D WI-FI Pro Streamer
Scan code: LN40697
Manufacturer code: Dune HD Lite 53D WI-FI
End Of Life
Dune HD Lite 53D WI-FI Pro Streamer
Dune HD Lite 53D WI-FI Edition Sigma 8653 Network 1080p MKV Streamer with NAS, BitTorrent, IPTV Functions
Scan code:
LN40697
Manufacturer code:
Dune HD Lite 53D WI-FI
This product is no longer available to purchase.
Email me when the availability or price changes
Product Overview
Dune HD Lite 53D is an entry-level universal media player which allows to play back video of standard and high definition up to Full HD (1080p), and also can be used as a specialized set-top-box for digital TV programs reception.
The device is compact and looks attractive.
Key Features:
• The newest Sigma Designs 8653 media processor: enjoy excellent playback and performance of interactive features.
• HDD player: connect an HDD to the player and play content directly from the HDD.
• Network player: connect the player to a local network and play content directly from PC or NAS (UPnP, SMB, NFS).
• MKV player: play HD and SD video in a popular MKV format and other modern video file formats, including top quality HD video with very high bitrate.
• 2 USB ports: conveniently connect HDDs, USB flash drives, USB card readers and other USB storage devices.
• SD card slot: easily play media files on SD memory cards from your camera or other devices, or use an SD memory card as a local storage.
• HDMI 1.3: ensure the best possible quality of HD video and audio.
• A rich set of standard A/V connectors: use S/PDIF optical audio, stereo audio, component video, composite video outputs to easily connect any A/V equipment.
• Video output flexibility: output video in any resolution and format (from SD to 1080p, 24p/PAL/NTSC).
• Upscaling: high quality upscaling of DVD and any other SD video content to Full HD (1080p) or other HD resolution.
• File browser: convenient file browser with powerful file management (copy, move, delete, rename, organize, sort).
Extra Functions:
• High-quality music playback: play very high-quality (up to 192 Khz / 24-bit) music files in various formats (FLAC, Monkey’s Audio APE, WAV/PCM, DTS, etc).
• Playlists: build playlists from your folders, use your own playlists, use repeat and shuffle functions.
• NAS function: access files on storage devices (HDD, optical drive, etc) attached to the player from the local network (using SMB or FTP).
• BitTorrent: use built-in BitTorrent client to download files from P2P networks.
• Customizable user interface: work with media collections using cover art and icon browsing (with Full HD graphics).
• Internet radio: playback and record various Internet radio stations (HTTP/MP3).
• IPTV: playback and record IPTV streams (multicast UDP/RTP) from your Internet provider (check availability of multicast UDP/RTP streams with your Internet provider).
• Digital TV option: playback and record Digital TV channels using an optional Digital TV USB dongle (Digital TV USB dongle is not included; this option can be purchased separately). Features Specification:
• Processor: Sigma Designs 8653.
• RAM: 256 MB.
• Flash memory: 128 MB, expandable with a HDD partition, USB flash drive, or SD card (2GB recommended).
• Media sources: internal HDD (SATA 2.5”), external HDD (USB), external optical drive (USB), USB devices (USB flash drive, USB card reader, etc), built-in SD card reader (SD/SDHC), PC and NAS in local network (SMB, NFS, UPnP, HTTP), other Internet and local network media sources (HTTP, multicast UDP/RTP).
• Video codecs: MPEG2, MPEG4, XVID, WMV9, VC1, H.264; support for very high bitrate video (up to 50 MBit/s and higher).
• Video file formats: MKV, MPEG-TS, MPEG-PS, M2TS, VOB, AVI, MOV, MP4, QT, ASF, WMV, DVD-ISO, VIDEO_TS.
• Optical disc formats: data discs (CD/DVD/BD) (MP3, JPEG, etc), Audio CD (PCM/DTS), DVD-Video (retail and user-authored discs) (playback of optical discs requires an external optical drive).
• Video output modes: wide range of supported output resolutions (up to 1080p) and framerates (including 23.976p, 24p, PAL, NTSC).
• Video output framerate: automatic (according to the played content) and manual.
• Audio codecs: AC3 (Dolby Digital), DTS, MPEG, AAC, LPCM, WMA, FLAC, multichannel FLAC, Ogg/Vorbis; support for very high quality audio (up to 192 kHz / 24-bit).
• Audio file formats: MP3, MPA, M4A, WMA, FLAC, APE (Monkey’s Audio), Ogg/Vorbis, WAV, DTS-WAV, DTS, AC3, AAC.
• Subtitle formats: SRT (external), SUB (MicroDVD) (external), text (MKV), SSA/ASS (MKV, external), VobSub (MP4, MKV, external SUB/IDX), PGS (TS, MKV).
• Picture file formats: JPEG, PNG, BMP, GIF.
• Playlist file formats: M3U, PLS.
• Photo viewer functions: slideshow, transition effects, picture rotation, zoom, browse playlist, repeat, shuffle.
• Audio playback functions: browse playlist, repeat, shuffle, ID3 tags, plasma TV burn-in prevention.
• Filesystems: FAT16/FAT32 (read-write), EXT2/EXT3 (read-write), NTFS (read-write).
• Ethernet: 10/100 Mbit.
• WiFi: internal (only for the players equipped with internal WiFi adaptor) or optional external 802.11n WiFi (via an external USB WiFi stick, Dune HD Air recommended).
• Dune Network Playback Accelerator: special optimizations ensuring best-in-class network playback performance for the Sigma Designs 865x/864x platform and enabling smooth playback of any supported kind of media content via any network protocol (including NFS and SMB) even in 100 Mbit/s Ethernet networks.
• Dimensions:
Player itself without leg: 142 mm (width) x 142 mm (depth) x 40 mm (height).
Player itself with leg: 83 mm (width) x 142 mm (depth) x 162 mm (height).
Gift box: 235 mm x 212 mm x 128 mm.
• Weight:
Net weight: 0.62 kg.
Gross weight: 1.6 kg.
