Scan code: LN96673 Manufacturer code: DP-ATX-E-SHIELD

DEEPCOOL E-SHIELD Tempered Glass Midi PC Gaming Case

DEEPCOOL E-SHIELD Mid Tower Chassis, Black, Tempered Glass, 120mm Fan, Radiator Support, E-ATX/ATX/MicroATX/MiniITX

Thumbnail 1 : DEEPCOOL E-SHIELD Tempered Glass Midi PC Gaming Case Thumbnail 2 : DEEPCOOL E-SHIELD Tempered Glass Midi PC Gaming Case Thumbnail 3 : DEEPCOOL E-SHIELD Tempered Glass Midi PC Gaming Case Thumbnail 4 : DEEPCOOL E-SHIELD Tempered Glass Midi PC Gaming Case
Scan code: LN96673 Manufacturer code: DP-ATX-E-SHIELD
£34.99
Order now and receive it by Wednesday, 5th August
Delivery Options
  • By DPD On 5th Aug to your specified address. | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • UPS and DPD Pickup Pickup from local convenience store | £4.79

    Collect your parcel from your newsagents, petrol stations and convenience stores

Services
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

Product Overview

DEEPCOOL E-SHIELD

The all-new E-SHIELD comes with 4mm thick Tempered Glass side-panel, which gives the case a unique look to perfectly show off your inner structure. A square-hole Array style front panel is used to keep sufficient intake airflow from the front, and also to keep the exterior semi-transparent for RGB devices. Cooling performance is crucial for a computer case, and E-SHIELD does a great job on this point thanks to its square-hole array style front panel. Exquisite and optimised structural design makes E-SHIELD a leading choice for PC enthusiasts who want a PC chassis with great performance.


4mm Tempered Glass

4mm thick Tempered Glass side-panel gives the case a unique look to perfectly show off your inner structure.


Square-Hole Array Style Front Panel

Square-hole Array style front panel used to keep sufficient intake airflow from front, and also keep semi-transparent for RGB devices.

Features
• Supports up to E-ATX motherboard.
• Supports installation of 120/140/240/280/360mm radiator liquid cooling system at front (360mm radiator without CD-ROM installed).
• Supports installation of 120/140/240mm radiator liquid cooling system on top (240mm radiator without CD-ROM installed).
• Supports installation of 120mm radiator liquid cooling system at rear.
• Supports 370mm (MAX) long Graphics Card installation.
• Magnetic dust proof net on top, easy for cleaning.
• Friendly designed internal structure for easy installation.
• 4mm thick tempered glass side-panel.
• 1×USB 3.0 +2*USB 2.0 Ports.
• 25mm clearance for cable management.
Specifications
Core Chassis Specifications
Case Edition E-SHIELD
Case Form Factor Mid Tower
Motherboard Form Factor
  • ATX
  • E-ATX
  • MicroATX
  • Mini-ITX
I/O, Bays & Expansion
Front/Side/Top Panel I/O
  • 1 x Headphone Out
  • 1 x Mic In
  • 2 x USB 2.0
  • 1 x USB 3.0
Drive Bays
  • 4 x 2.5" Internal
  • 2 x 3.5" Internal
  • 1 x 5.25"
Standard Expansion Slots 7
Vertical Expansion Slots
Fans & Filters
Fan Bays
  • 7 x 120/140mm
  • 1 x 120mm
Fans Included 1 x 120mm
Fan Controller/Hub
Dust Filters
Liquid Cooling Support
Front Radiator Compatibility 1 x 120/140/240/280/360mm
Top Radiator Compatibility 1 x 120/140/240mm
Bottom Radiator Compatibility
Rear Radiator Compatibility 1 x 120mm
Side Radiator Compatibility
Clearances
Max CPU Cooler Height 168 mm
Max GPU Card Length 370 mm
Cable Routing Space 25mm mm
Side Panels
Window/s Yes
Window Configuration 1 x Main Side
Window Construction Tempered Glass
LED Lighting Functionality
LED Lighting No
LED Lighting Emitters
LED Lighting Colour
LED Lighting Support & Control
Power Supply Compatibility
PSU Included No
PSU Wattage (If Included)
PSU 80+ Rating (If Included)
PSU Support ATX
PSU Mounting Location Bottom Mount, Rear
Max PSU Length 170 mm
Chassis Physical Specifications
Colour Black
Chassis Contruction Materials SPCC / Plastic
Dimensions 210 x 477 x 438 (WxHxD mm)
Weight 6.36 kg (Approx)
Please Note
Additional Information
Scan Code LN96673
Model Number DP-ATX-E-SHIELD
GTIN 6933412713647
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
24 months
Type:
Return to base
DOA Period:
28 days
RTB Period:
24 months
Manufacturer Contact Details
Manufacturer:
Scan
Telephone:
0871-472-4747
Reviews
DEEPCOOL E-SHIELD Mid Tower Chassis, Black, Tempered Glass, 120mm Fan, Radiator Support, E-ATX/ATX/MicroATX/MiniITX is rated 4.2 out of 5 by 5.
Rated 4 out of 5 by from Excellent value with only 1 minor gripe I really love this case, there's plenty of space for cable management, loads of ventalation and of course a full tempered glass side panel. My only complaint is that the included motherboard standoffs are pretty poor quality but fortunately I was swapping from an older case so I could use my old ones. For £34.99 though this is an absolute bargain! It looks great and the full mesh front panel provides plenty of airflow.
Date published: 2020-06-03
Rated 4 out of 5 by from First Build I just finished my first ever pc build inside this case, I wanted something not overly gamer-y but we'll cooled and nice looking. This case suited my needs perfectly. It was easy enough to build in, and has a reasonable build quality, front panel is a bit plasticy but the buttons are nice. Also pretty insane that a case of this price has a tempered glass side panel. Overall I'm happy with it :)
Date published: 2020-01-29
Rated 4 out of 5 by from Needed a cheap case for a Second PC I needed a cheap case for a second PC, it’s situated in the front room next to the TV and acts as a HTPC and local co-op machine. No complaints, it looks nice, it’s cheap and it has quite a few handy features for PC Building which I didn’t think a cheap case would have. The glass panel is easy to take off and cable routing was a pleasure. I was really pleasantly surprised by this case and I’d wholeheartedly recommend it to anyone looking for a standard, semi decent looking case.
Date published: 2020-01-24
Rated 4 out of 5 by from Fantastic value case. I wanted an ATX case with good water cooling and optical drive support and some 3.5" drive bays, ideally with a window, but as I'm a little short on desk depth I didn't want the case depth that comes with a full tower case, although you do get many drive bays with those. As this may not be a forever case, but rather one to put something together to use now I didn't want to spend too much, so opted for this. When I opened it up I was surprised by the quality. It looks like a more premium product. The glass side panel is very nice, clean, scratch free and mounts nicely. I was a little disappointed to see it packed in polystyrene, not ideal if I wanted to put my complete system back into the box to transport it, but understandable. I certainly wouldn't like to ship a system in the case packaging. Building was a simple. Loads of space in the back for cable routing, and lugs to tie onto. I was hesitant looking at photos as the cable routing holes didn't have rubber trim, but I needn't have worried, they all have very nice safe edges that won't chew cables up. The stand-offs were pre-installed for ATX, so that saved me a minute. Building I noticed that the steel chassis is somewhat flexible, and this is where the case feels a little cheap. Included screws were generous, although there was only 1 for a radiator. I already had radiator mounts though, so day saved. Expansion bays require knocking out blanks, so if a card is ever removed in the future, then I'll need to buy blanks. It comes with one pre-installed in the top slot. The cover to dress the screw mounts for expansion cards was a little tight to fit, but went in with a little persuasion and being careful not to get too close to PCBs. The included fan is a very quiet 3-pin, DEEPCOOL branded, but with no specs. It is much quieter at full speed than be quiet! Pure Wings 2 120mm and the standard Cooler Master 1200rpm case fans I compared it to, but moves much less air, and doesn't generate much in the way of pressure, but as a single exhaust, it's ok if there are other fans to push air into the case, which will spill out past this one. All in all, not perfect, but I'm still amazed to have a glass side panel at this price. The glass would literally cost more from my local glass merchant.
Date published: 2020-01-04
Rated 5 out of 5 by from Truly great case for the price! This case is truly unmatched in terms of size, performance and looks compared to many other cases in this price point. In my opinion this case holds its own right up until some of the higher end market! I'm one of those people that will never spend much on a case, as far as I am concerned, they are just a box to house my components in... Yet this case does so much more than that! At such a low price of £34.99 that I paid for this case, not many compromises were made, it even has a true glass side panel window! What more could you want at this price!? It is nice and sturdy, has good mounting mechanisms, supports E-ATX (yes, at this price point I know, it's amazing!), has great cable management and even has six 120mm fan mounts, truly great for airflow. Each fan mount has a filter to it as well so there is no cash spared in this case. I've made quite the beast of a PC in this (which can be seen in the photos attached, specs are also listed below for context) and I have no issues whatsoever with thermals. Admittedly, it does have some flaws but these are nothing game changing or what I think will change your choice of case, but I must mention them anyway. I put in an E-ATX motherboard and I was hoping to have my SSD's on show whilst mounted to the motherboard tray, yet I cannot do this because the mounts are too close to the rest of the motherboard. This therefore only gives me two drive bay mounts, both of which I have populated with a 480GB 2.5" SSD and a 1TB 3.5" HDD, so storage upgradability is limited when using E-ATX... Plus I must mention that at the rear of the case, there is a cover for the expansion slots, this cover does not have a great means of mounting though. This broke on my first installation so I've screwed it in place with a nut and screw, this may be something you'll do as there is a large space in which will be showing at the back of the case to see inside. Other than these two little grovels, however, I absolutely love this case and I am sure you will too! Cable management behind the motherboard tray is also very clean and easy for management as well. For context of what kind of rig you can very easily and comfortably fit into this case... My Specs are as follows: - Xeon E5 1680 V2 @ 4.2GHz - Asus Rampage Extreme IV - 16GB = 8 x 2GB Samsung 1333MHz Dimms - GTX 1080 HP OEM - DeepCool E-Shield E-ATX Tempered Glass Case - 1 x 480GB Kingston A400 SSD 1 x 1TB Seagate 7200rpm Drive - EVGA 750W GQ Gold+ Rating - 3 x Acer Nitro 23.8" 1080p 75Hz IPS 1ms Freesync Panels = NVidia Surround @ 75Hz - Akasa Venom R20 240 RGB Cooler & 5 x 120mm silent fans - Lenovo KBBH21 - Asus Cerberus Mouse - Windows 10 1809 64-Bit I have also added an image of my set up to show what kind of vibe the case will easily mold to... I truly love my set up and I'm trying not to show off! I promise! Hopefully you get the same feeling when you buy this case! It's great :)
Date published: 2019-08-22
