Thermaltake CTE E550 TG Snow Mid Tower Tempered Glass PC Gaming Case

Thermaltake CTE E550 TG Snow Mid Tower Chassis - CA-1Z8-00M6WN-00

Designed for an exceptional view, The CTE E550 TG is a dual chamber, mid-tower chassis with three TG panels that allows users to display PC parts in style. It supports the latest Hidden-Connector motherboards and offers a three-way GPU installation option, seamlessly blending aesthetics with compatibility. It also excels in cooling support, accommodating up to a 420mm AIO radiator on the M/B side, and up to eight 120mm fans (or six 140mm fans) can be installed in the chassis. Combining aesthetics with compatibility, the CTE E550 TG is the perfect choice where style meets function.

Visual Perfection

The CTE E550 TG is a panoramic mid tower with tempered glass panels on the front, rear and left side. These crystal-clear panels offer an ultra-wide viewing angle normally only available with an open-frame chassis, providing an unparalleled visual display of your internal components.

Flexible Way to Mount Your GPU

Thermaltake have made it easy to achieve specific looks with the CTE E550 TG, such as having a “Floating GPU", with their 400mm PCI-e 4.0 riser cable (separately sold). The PCI-e 4.0 standard-compliant riser cable offers a 16 GT/s transfer rate and supports up to 64 GB/s (bidirectional) data transfer.

Excellent Hardware Support & Cooling Solutions

The CTE E550 TG has excellent expandability, allowing you to build the most high-end system you can dream of. It can support up to an E-ATX (12”x10.5”) motherboard, a CPU cooler with a maximum height of 166mm, VGA clearance up to 443.8mm in length without a radiator, a power supply with a length of up to 220mm, and up to two 2.5” SSD or three 3.5” HDD. Optimised for superior cooling, the CTE E550 TG can accommodate up to eight 120mm fans (or six 140mm fans), a 240mm AIO cooler at the top, and 360mm/420mm AIO coolers on the side, allowing users to build their desired high-end system with many options.

Compatible with Hidden-Connector Motherboards

Created for next-generation motherboards, the CTE E550 TG features a special design that enables support for both standard motherboards and hidden-connector motherboards from ASUS, MSI and GIGABYTE.

Maximum Radiator Support

The CTE E550 TG offers multiple mounting locations and plenty of room to create your own configurations. DIY radiators up to 420mm in length can be installed on the bottom and M/B side, and for AIO compatibility, up to 420mm/360mm radiators can be installed on the M/B side, giving PC enthusiasts plenty of flexibility to create their ideal setup.

Perfect Dust Protection

There are fine removable filters at the top, bottom and right side of the chassis to provide excellent protection against dust, and they are easily removable for cleaning.

Optimal Cable Management

Thanks to the dual chamber design, the CTE E550 TG offers ample space in the right chamber for effective cable management. Numerous anchor points are available in this chamber, complimented with Velcro straps and cable ties from the accessory box to insure a neat and organized setup.

Everything You Need Is Located in One Place

Two USB 3.0 ports, one USB 3.2 Gen 2 Type-C, and HD Audio ports are placed on the top panel to grant direct access when needed.

•Expansion Slots: 7.
• Dimensions (W x H x D): 270 x 558.5 x 513mm.
• Drive Bays: 2 x 2.5” or 3 x 3.5”.
• Front I/O: USB 3.0 x 2, USB Type-C x 1, HD Audio x 1.
• Fan Support: 2 x 120mm (Top), 3 x 120mm or 3 x 140mm (Right), 3 x 120mm or 3 x 140mm (Bottom).
• Radiator Support: 1 x 120/240 (Top), 1 x 120/140/240/280/360/420mm (Right), 1 x 120/140/240/280/360/420mm (Bottom – DIY ONLY).
• CPU cooler max height: 166mm.
• VGA max length: 415mm (with radiator) 443mm (without radiator).
• PSU max length: 220mm.
