CodeGen 4U 4 x GPU Rackmount Server Chassis 650mm Deep

Codegen 4U 650GPU4

The Codegen 4U 650GPU4 is a premium 4U rackmount server chassis built for performance and flexibility, making it ideal for data centers, professional workstations, and advanced home labs. Featuring robust steel construction and a spacious 650mm internal layout, it supports SSI-EEB, E-ATX, ATX, micro ATX, and mini ITX motherboards, offering broad compatibility for a range of builds. With up to eight PCIe expansion slots, generous space for multiple GPUs and storage drives, and excellent front-to-back directional airflow, the 4U 650GPU4 comes pre-installed with three 120mm x 38mm hot-swappable PWM fans achieve faster heat dissipation. the 650GPU4 ensures your hardware stays cool and reliable. Its user-friendly design includes lockable panels, easy-access drive bays, and modern front I/O with USB Type-C, making it a top choice for anyone seeking a scalable, durable, and high-capacity server enclosure.

• 4U Rackmount Case: 650mm deep & 437.5mm wide (Exc. handles). This 4U 650mm rackmount is specially designed for high performance computing applications, particularly in data centres and server rooms. The larger size allows for a greater amount of internal hardware to be installed including multiple processors, more memory, and a larger number of storage drives. This form factor also accommodates more expansion slots for add-on cards and GPUs.
• Unique Exterior: The 4U 650GPU4 is made with a unique front panel featuring 8 x hot swappable 3.5" Bays or 8 x hot swappable 2.5" Bays with handle bars allowing for easy accessibility to the internal components.
• Cooling Capabilities: Excellent front-to-back directional airflow, 4U 650GPU4 comes pre-installed with three 120mm x 38mm hot-swappable PWM fans achieve faster heat dissipation.
• PWM Functionality: The 120mm x 38mm pre-installed fans are included with automatic speed control of the Motherboard through the 4 Pin PWM fan cable interface, which can determine the speed according to the temperature readings from various parts of the PC. This further helps to keep your system as quiet as possible, using only as much fan power as needed.
• Storage Device Performance: HDD backplane supports Mini-SAS (SFF-8643) with SGPIO & temperature control chipset.
• Huge Scalability: Specially designed with eleven expansion slots allows installation of high-end Graphic Cards & supports up to four GPU's.
• Server Motherboard Support: Supports up to E-ATX form factor dual-socket Motherboards.
• Optimise Performance: Maintaining lower operating temperatures throughout the Rackmount helps to prolong the lifespan of your server components and reduce the risk of downtime.
• Backplane: 12GB Mini-SAS (SFF8643) with SGPIO & temperature control chipset.
