CAD E60 Equitek Cardioid Condenser Microphone
CAD E60 Equitek Small Diaphragm Cardioid Condenser Microphone, 16mm Gold Sputtered Capsule, Discrete Linear Power Supply
Scan code:
LN96037
Manufacturer code:
E60
FREE DELIVERY ON YOUR ENTIRE BASKET
Order now and receive it
by Tuesday, 21st September
From
£14.50
/ month (APR 0%)
spend over £280 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
Delivery Options
- By DPD On 21st Sep to your specified address. | Free Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout
- Collect instore Collect from our Bolton store, BL6 6PE | Free
- UPS and DPD Pickup Pickup from local convenience store | £4.79
- SCANPROTECT Protect against installation damage for 28 days. More info
Product Overview
The e60 is designed specifically for use as an instrument microphone. It is great for virtually all acoustic, wind, and amplified instruments. One of the most popular uses for the e60 is in miking drum kits, ideally in an overhead type configuration.
Features
• 16mm, 24k Gold sputtered externally biased condenser capsule.
• 10dB non-capacitive pad
• 4 position hi-pass filter - flat, 40Hz, 85Hz, and 122Hz
• CAD's proprietary discrete linear power supply for efficient low noise and linear power
• Four position roll-off switch which allows for extended “tuning” of the frequency response depending on the intended application.
• The e60 is also equipped with a -10dB pad switch.
• Standard 5/8x27 threaded swivel adaptor included.
Technical Specifications
• Type: Front Address, Externally Biased Condenser.
• Frequency Response: 30-20 kHz
• Polar Pattern: Cardioid
• Impedance: 300 ohms
• Sensitivity: -41 dBV (8.9mV) @ 1Pa
• Equivalent Noise Level: 22 dB Equivalent SPL, A weighted.
• Maximum SPL: 140 dB SPL (with pad on), 1% THD, 1KHz
• Powering: P24, P48, 6mA
• Connector: Three pin male XLR type.
• Finish: Durable black “leather feel” urethane.
• Net Weight: 11.5oz. (326 grams).
*In our constant efforts to maintain excellence, CAD Professional Microphones reserves the right to change these specifications at any time and without prior notice
• 10dB non-capacitive pad
• 4 position hi-pass filter - flat, 40Hz, 85Hz, and 122Hz
• CAD's proprietary discrete linear power supply for efficient low noise and linear power
• Four position roll-off switch which allows for extended “tuning” of the frequency response depending on the intended application.
• The e60 is also equipped with a -10dB pad switch.
• Standard 5/8x27 threaded swivel adaptor included.
Technical Specifications
• Type: Front Address, Externally Biased Condenser.
• Frequency Response: 30-20 kHz
• Polar Pattern: Cardioid
• Impedance: 300 ohms
• Sensitivity: -41 dBV (8.9mV) @ 1Pa
• Equivalent Noise Level: 22 dB Equivalent SPL, A weighted.
• Maximum SPL: 140 dB SPL (with pad on), 1% THD, 1KHz
• Powering: P24, P48, 6mA
• Connector: Three pin male XLR type.
• Finish: Durable black “leather feel” urethane.
• Net Weight: 11.5oz. (326 grams).
*In our constant efforts to maintain excellence, CAD Professional Microphones reserves the right to change these specifications at any time and without prior notice
