Product Overview

Enable Flexibility with Tri-Mode Connectivity

The 9600W-16e Tri-Mode, PCIe Gen 4.0 enhanced HBA (eHBA) is ideal for increased connectivity and maximum performance for enterprise data center flexibility.

With increased bandwidth and IOPS performance compared to previous generations, the 9600W-16e eHBA delivers the performance and scalability needed by critical applications.

Features

• Low profile, half-length x16 PCIe Gen 4.0 adapter
• Connect up to 240 SAS/SATA devices or 32 NVMe devices
• Hardware Secure Boot and SPDM Attestation support
• SMART monitoring
• Drive temperature monitoring
• SafeStore key management for attached SEDs
• Universal Bay Management (UBM) Ready

Full technical specifications for: eHBA 9600W-16e

Specifications
Ports Total 16 Port
Ports Internal 16 Int Ports
Ports External
Connectors
Interface PCIe 4.0 x16
JBOD No
RAID Support N/A
Low Profile Compatible Yes
Cables Inc.
Cache Memory
Notes
Additional Information
Scan Code LN135725
Model Number 05-50108-00
GTIN 830343007745
