Asus RS720A-E11 3rd Gen EPYC CPU 2U 24 Bay Barebone Server

Asus RS720A-E11-RS24U/10G Barebone AMD EPYC™ 7003 Dual Processor Server, 2U Rackmount, 24x NVMe/SAS/SATA Hot-Swap Bays

Thumbnail 1 : Asus RS720A-E11 3rd Gen EPYC CPU 2U 24 Bay Barebone Server Thumbnail 2 : Asus RS720A-E11 3rd Gen EPYC CPU 2U 24 Bay Barebone Server Thumbnail 3 : Asus RS720A-E11 3rd Gen EPYC CPU 2U 24 Bay Barebone Server Thumbnail 4 : Asus RS720A-E11 3rd Gen EPYC CPU 2U 24 Bay Barebone Server
Scan code: LN117905 Manufacturer code: 90SF01G3-M00620
Delivery Options
  • By DPD to your specified address. | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

Services
  • 48HR REPLACEMENT If you need to return this item, your replacement will be dispatched within 2 working days of your product arriving back at Scan. More info
Product Overview

AMD EPYC 7003 Series Processors

The latest AMD EPYC™ 7003 series processors are the new standard for modern data centers. AMD was first with X86 multi-chip-module server CPUs and continues to innovate with the 3rd Gen EPYC processors, including up to 32MB of L3 cache per core and synchronized fabric and memory-clock speeds designed for improved performance.


PCIe 4.0 Ready

PCI Express® (PCIe®) 4.0 delivers 16 GT/s bandwidth, which is double the speed of PCIe 3.0, offering lower power consumption, better lane scalability and backwards compatibility. ASUS RS720A-E11 servers are PCIe 4.0 ready to support a diverse array of graphics, storage and networking – enabling flexible scalability for demanding or increasing workloads.


Four Dual-Slot GPUs Support

ASUS RS720A-E11 servers feature a powerful GPU architecture that supports up to four dual-slot GPUs such as NVIDIA A100 in one 2U system to enable easy scale-up in order to meet the demands of AI and high-performance computing (HPC), and to securely run workloads in virtualized environments.

ASUS AMD EPYC 7003-based series are Xilinx Alveo-qualified servers to provide optimized acceleration for workloads across cloud and on-premises data centers, and for hybrid cloud environments in financial computing, machine learning, computational storage, and data search and analytics.


CPU-Balanced Architecture

The new AMD EPYC 7003 processors excel at providing full features and functionality for both dual-socket and single-socket platforms, but our new servers ASUS is introducing an CPU-balanced architecture to enable secure and optimal CPU-performance efficiency.

This architecture extends the full bandwidth to either dual- or single-CPU configurations, enabling more computing capability and much-improved overall power efficiency for compute-intensive workloads. This architecture allows customers to take full advantage of bandwidth capabilities of the dual-CPU architecture with a single CPU, while offering the flexibility to upgrade later with the addition of a second CPU.


Modular Design

ASUS RS720A-E11 servers offer a flexible, modular design to enable easy scale-up of configurations to meet increasing data-center workloads.


Scalable Storage Solution

ASUS RS720A-E11 servers feature scalable storage solutions to support maximum performance for data center flexibility, and enable industry-standard SAS/SATA/NVMe interfacing through Broadcom Tri-Mode RAID adapters for increased connectivity and security. Up to 24 all-flash NVMe drives on front panel enable extensive storage and high-throughput performance.


Cooling Solutions

Data centers typically demand high-performance processors, GPUs or memory in dense configurations to run HPC or AI workloads. ASUS RS720A-E11 servers feature either air or liquid-cooled solutions, with Asetek’s Direct-to-Chip (D2C) liquid-cooling technology achieving lower power-usage effectiveness (PUE) and optimized TCO for data centers.


Enhanced Security

ASUS RS720A-E11 servers integrate PFR FPGA as the platform Root-of-Trust solution for firmware resiliency to prevent from hackers from gaining access to infrastructure. ASUS security solutions are fully compliant with the 2018 National Institute of Standards and Technology (NIST) SP 800 193 specification.

In addition, all RS720A-E11 servers also include support Trusted Platform Module 2.0 (TPM 2.0) to secure hardware through integrated cryptographic keys and offer regular firmware update for vulnerabilities.


OCP 3.0

ASUS RS720A-E11 servers feature the latest OCP NIC 3.0 card with PCIe 4.0 bandwidth for a faster time-to-market network solution, delivering the speeds of up to 200 Gbps for high bandwidth and low latency. It also features a tool-less, hot-swappable design to simplify installation and serviceability.


ASUS ASMB10-iKVM

ASUS ASMB10-iKVM is the latest server-management solution from ASUS, built upon the ASPEED 2600 chipset running on the latest AMI MegaRAC SP-X. The module provides various interfaces to enable out-of-band server management through WebGUI, Intelligent Platform Management Interface (IPMI) and Redfish® API.


ASUS Control Center

ASUS Control Center (ACC) is a centralized and integrated IT-management platform for monitoring and controlling ASUS servers, workstations and mini PCs. ACC enables remote BIOS updates, monitoring of multiple systems via mobile devices, and one-click software updates and dispatching, allowing easier server management for any IT infrastructure.

Features


• GPU-optimized design allows four dual-slot or eight single-slot GPUs for AI workloads
• Up to 24 all-flash NVMe drives on front panel to enable extensive storage and high-throughput performance
• Up to nine PCIe® 4.0 slots to enable higher bandwidth and improved data-transfer rates
• Flexible onboard LAN-module design to enable four 1 Gb LAN or two 10 Gb LAN options
• Flexible air and liquid cooling solution to achieve lower power-usage effectiveness (PUE) and optimized TCO for data centers
• Onboard ASUS ASMB10-iKVM for out-of-band management with ASPEED AST2600 controller
• Integrated PFR FPGA as the platform Root-of-Trust solution for firmware resiliency
• High power efficiency with redundant 2400W 80 Plus Titanium power supplies

Specifications
Edition RS720A-E11-RS24U
Form Factor 2U Rackmount
CPU Included No
CPU Type AMD EPYC™ 7003 Series
CPU Model
Architecture Infinity / Zen 3
Manufacturing Process 7 nm
Unlocked CPU No
Core
No. of Threads N/A
Clock Speed N/A
Burst Frequency N/A
CPU Cache
CPU Cooler
Max. TDP 280 W
CPU Socket SP3
Chipset N/A
Motherboard Form Factor Proprietary
Motherboard Model
Memory Type DDR4 RDIMM/LRDIMM
Memory Included No
Memory Capacity Included N/A
Memory Edition
Memory Channels Octa (8)
Memory Type (ECC) ECC/Non-ECC
Memory Type (R/U) RDIMM / LRDIMM / LRDIMM 3DS
Memory Speed (Mhz) DDR4 - 3200
Max. Memory Capacity 4096GB (32x128GB)
On-board/Integrated Graphics Yes
Processor/Motherboard Graphics Chip Aspeed® AST2600
Discrete GPU No
Discrete GPU Chipset
GPU Architecture
GPU Manufacturing Process
GPU Cores/Streams/Execution Units
GPU Tensor Cores N/A
Base GPU Speed N/A
Max. GPU Speed N/A
GPU Memory Size
GPU Memory Type
GPU Memory Clock
GPU Memory Bus
Discrete GPU Cooler
Multi-GPU Configuration No
Max. GPU Resolution
Graphics Interface PCIe 4.0 (x16) [PCIe 3.0 Backwards Compatible]
Expansion Slots
  • 2 x M.2, 22-42/60/80/110, PCIe Gen4x4
  • 2 x M.2, 22-42/60/80/110, PCIe/SATA
  • 9 x PCIe 4.0 x8
SATA SATA3 / M.2
HDD Storage Included No
HDD Storage Type
HDD Storage Capacity N/A
Optical Drive None
Drive Bays 24 x 2.5" NVMe/SATA/SAS Hot-Swap
Backplane I/O
RAID Support Requires RAID Card
Internal I/O N/A
Network Interface Type
Network Chip/Modules
  • 4 x Gigabit LAN
  • 1 x Mgmt LAN
Front Panel
  • 1 x HDD Activity LED
  • 1 x Location Switch with LED
  • 1 x Message LED
  • 1 x Power Switch with LED
  • 1 x Reset Switch
  • 2 x USB 3.2 Gen1 Type-A
Back Panel
  • 2 x 10/100/1000 (LAN)
  • 1 x D-Sub (VGA)
  • 1 x Location Switch with LED
  • 1 x Message LED
  • 1 x Power Switch with LED
  • 1 x Q-Code/Port 80 LED
  • 1 x RJ-45 Mgmt LAN
  • 2 x USB 3.1 Gen2 Type-A
Cooling Fans
Keyboard / Mouse Included No
Remote Control Included No
VESA Mountable N/A
PSU Wattage 2400 W
PSU Efficiency Rating 80 PLUS Titanium
PSU Redundancy 1+1
Operating System Included No
Operating System N/A
Colour
Dimensions 840mm x 88.1mm x 449mm (mm WxHxD)
Weight 21.64 kg
Includes
Notes
Storage Drives
SSD Storage Included No
SSD Storage Type
SSD Storage Capacity
Additional Information
Scan Code LN117905
Model Number 90SF01G3-M00620
GTIN 4711081368502
