73-key Virtual Analogue Synthesizer
ASM - Hydrasynth Deluxe

ASM - Hydrasynth Deluxe

double the power!ASM’s impressive Hydrasynth Deluxe is the proud new flagship of Hydrasynth range. Offering a sublime dual-engine setup with a total of 16 voices plus an all-new 73-note keybed featuring ASM's much sought after PolyTouch® polyphonic aftertouch functionality, this is clearly in a class of its own. With what is essentially two Hydrasynths in one instrument, KeySplit and Dual voice mode patches with 8 independent voices each are possible.

You also have separate balanced stereo audio outputs for each of the two parts. The easily accessible 4 octave ribbon controller adds for truly expressive playing. The Hydrasynth Deluxe of course offers CV/GATE I/O for interfacing to modular and other voltage-controlled synths. There's a ton of potential for sound creation, using ASM's WaveScan oscillators together with the Mutator wave shaping section and user configurable filters.

A plethora of LFO's and Envelope's plus Insert and Master Effects makes this a dream sound creation tool and quite possibly the ultimate synthesizer and controller combo for your rig.

1024Presets

73Number of Keys

5LFO

at a glance • 16-voice polyphonic digital wave morphing synthesizer
• POLYTOUCH™ Polyphonic Aftertouch, Note on/off velocity keyboard with 73 full-size keys
• Multi function ribbon controller (Modulation, Pitch bend, Theremin mode)
• 640 Multi program locations with 1280 embedded program locations
• MPE (MIDI Polyphonic Expression) compatibility
• Single/Multi Dual/Keysplit voicing options
• Dual stereo audio outputs

Explore 'PolyTouch'!

ASM - Hydrasynth Deluxe

ribbon controllerNo matter if you’re performing or tracking in the studio, ASM’s Hydraysnth Deluxe hands over a rich and hugely expressive playing experience, even more so once you explore the PolyTouch capabilities! PolyTouch is a new means of polyphonic aftertouch sensing. Handing you full control over aftertouch curves, offsets and release times, delivering massive creative potential.

There’s an integrated ribbon controller to take your performance options even further! Control pitch bend or modulation amount, and there’s even a cool Theremin mode to enable you to play melodies on the ribbon controller against what you’re playing on the keyboard!

Huge Modulation Potential!

ASM - Hydrasynth Deluxe

32-SLOT MODULATION MATRIXFeaturing a 32-slot modulation matrix, ASM’s Hydrasynth Deluxe gives you the power to curate amazingly detailed and expressive sounds. Both novice and experienced musicians are sure to be blown away with the envelope generators (5 per voice), each of which offer delay and hold alongside ADSR stages. Each individual stage is able to sweep through exponential and logarithmic curves, offering vast creative potential for huge modulations.

Like the majority of function within the Hydrasynth Deluxe, envelopes are able to be locked to bpm to allow for tempo-synched modulations. Alongside the loop function, it’s possible to use the envelopes as LFOs for cool waveshapes! As a side note, Hydrasynth Deluxe offers up to 5 LFOs for each voice with a total of 11 waveshapes.

Real-Time Control!

ASM - Hydrasynth Deluxe

EIGHT MACRO CONTROLSOne of the coolest things about software synths is the potential to take control over numerous parameters simultaneously via macro controls. Hydrasynth Deluxe hands you this incredible control and power through hardware form. Customise up to 8 macro controls to tweak up to 8 destinations simultaneously. With a huge 170 modulation destinations to get stuck into, it’s a breeze to use these powerful macro controls to warp across sound variations!

Take a Tour of the ASM Hydrasynth!

Glen Darcey takes you on a tour of the features of the new Hydrasynth Keyboard and Hydrasynth Desktop synthesizers.

This talking tour covers the main features and functions of the synthesizers.

The Tech Spec

Features Specification
Type Keyboard Synthesizer
Sound Engine Dual Wave Morphing Synthesis Engines (wavetable, linear FM, wave PWM, subtractive)
Analogue/Digital Digital
Number of Keys 73
Type of Keys Semi-weighted
Aftertouch Polyphonic Aftertouch
Velocity Sensitive Yes
Other Controllers Pitchbend, Mod wheel, 4-octave Ribbon Controller
Polyphony 16 Notes
Number of Presets 1024 Factory Patches, 640 Factory Multi-mode Patches
Oscillators 3 x WaveScan Oscillators, 1 x Noise Generator
Waveforms 219 x Waveforms, 4 x Wave Mutators
LFO 5 x LFO (sine, triangle, saw up/down, square, pulse 27%, pulse 13%, S&H, noise, random, step)
Filter Multimode Filter, 2-mode Filter (lowpass/bandpass/highpass, lowpass/notch/highpass)
Envelope Generator 5 x ADSR ; Delay, Hold, Looping
Effects Types 4 x Reverb, 6 x Delay, 5 x Modulation, Distortion, EQ, Compressor, Lo-Fi
Arpeggiator 8 x Modes with Direction, Octave, Chord, Phrase
Audio Outputs 2 x 1/4" Main/Upper (L/mono, R), 2 x 1/4" Lower (L, R)
Headphones 1 x 1/4", 1 x 1/8"
USB 1 x Type B
MIDI I/O In/Out/Thru/USB
Pedal Inputs 1 x 1/4" (expression), 1 x 1/4" (sustain)
Other I/O 2 x Mod In, 2 x Mod Out, Pitch Out, Gate Out, Clock Out
Features 32-slot Modulation Matrix
Power Source 12V DC power supply (included)
Height 4.7"
Width 44.5"
Depth 14.1"
Weight 29.8 lbs.
