Scan code: LN145441 Manufacturer code: ACFRE00133A

Arctic Freezer 4U-M AMD/Intel 4U Single Tower CPU Server Cooler

Arctic Freezer 4U-M Tower 4U CPU Cooler, 2x 120mm PWM Fans, AMD SP6/SP3/sTR5/TR4/sTRX4/SWRX8, Intel LGA4189/LGA4677

Thumbnail 1 : Arctic Freezer 4U-M AMD/Intel 4U Single Tower CPU Server Cooler Thumbnail 2 : Arctic Freezer 4U-M AMD/Intel 4U Single Tower CPU Server Cooler Thumbnail 3 : Arctic Freezer 4U-M AMD/Intel 4U Single Tower CPU Server Cooler Thumbnail 4 : Arctic Freezer 4U-M AMD/Intel 4U Single Tower CPU Server Cooler
Scan code: LN145441 Manufacturer code: ACFRE00133A
£49.99Item currently awaiting an ETA
Pre order
spend over £280 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
Delivery Options
  • By DPD to your specified address. | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • UPS and DPD Pickup Pickup from local convenience store | £4.79

    Collect your parcel from your newsagents, petrol stations and convenience stores

Services
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

Product Overview

Versatile Multi-Compatible Server Cooler

The Freezer 4U-M stands as a multi-compatible server cooler, boasting an expansive contact surface and an enhanced mounting mechanism. It now offers compatibility with a wide range of Intel and AMD server processors, including Intel's LGA 4189 and LGA 4677, as well as AMD's SP6, sTR5, SP3, TR4, sTRX4, and sWRX8 sockets. Remarkably, despite its impressive cooling capabilities, the Freezer 4U consumes a mere 2.88 watts, ensuring exceptional efficiency in cooling even the most powerful processors with up to 96 cores and a TDP of up to 350 watts.


RAM Compatibility and Clearance

The Freezer 4U offers a spacious 53 mm of RAM clearance, allowing for the use of memory sticks with moderate heatsinks. This clearance allows efficient airflow and enables compatibility with different RAM variants.


Compact Design and Dual Socket Compatibility

With an optimised installation height of only 145 mm, it fits into both classic 4U server racks and most consumer 4U cases available on the market. The Freezer 4U features a compact design with dimensions of just 156 x 124 mm. This also makes it suitable for dual-socket motherboards. To adjust the airflow direction if required, the fans can be easily swapped over.


Powerful Fans in Push-Pull Configuration

The installed PWM fans benefit from all the advantages of the award-winning P series. Designed for static pressure, the fans are ideal for the Freezer 4U-M's high fin density and provide efficient heat dissipation in push-pull mode, even in power-hungry applications. Especially office workstations benefit from the quiet fans. The dual configuration also allows for inherent redundancy and protects the system from total shutdown caused by heat.


Designed for Continuous Operation

Both fans of the Freezer 4U-M are equipped with dual ball bearings, which allows for 24/7 continuous operation without the slightest compromise in performance. This type of bearing is much more resistant to contamination and wear caused by high temperatures than conventional sleeve bearings or Fluid-Dynamic bearings and is therefore the perfect choice if you want to ensure fault-free continuous operation.


Premium Thermal Paste Included

The Freezer 4U-M comes with MX-6 thermal paste. ARCTIC's Ultimate Performance thermal paste reduces the heat build-up between the heat spreader of the CPU and the cooler. The thermal paste is neither conductive nor capacitive and therefore absolutely safe to use.

Features


• Compatibillity: AMD: SP6, SP3, sTR5, TR4, sTRX4, SWRX8, Intel: LGA4189, LGA4677.
• Heat Pipe: Direct Touch 6 mm x 8.
• Number of Fins: 57.
• Fin Material: Aluminium.
• Fan Speed: 400 - 2300 rpm PWM Controlled.
• Connector: 4-Pin Plug.
• Cable Length: 200 mm.
• Bearing: Double Ball Bearing.
• Noise Level: 40 dBA.

Specifications
Cooler Specifications
Edition Freezer 4U-M
Cooler Form Factor 4U Single Tower Server
Heatpipes 8
Cooler Features
Socket Compatibility
  • 4189
  • 4677
  • SP3
  • SP6
  • TR4
  • TR5
  • TRX4
Max. TDP
Fan Specifications
Included Fan Configuration 2 x 120mm
Fan Edition
PWM Fan Yes
Fan Bearing Type Dual Ball Bearing
Fan Colour Black
LED Lighting
Fan/Pump Connectors 2 x 4-pin PWM
Max. Fan Speed 2300 rpm
Max. Fan Airflow
Max. Air Pressure
Max. Sound Level 40 dBA
Materials
Cooler Materials Aluminium
Included TIM (Thermal Interface Material) Included
Dimensions & Weight
Heatsink/Radiator Dimensions
Total Dimensions 160 x 141 x 211 mm (WxHxD)
Weight 1548 g
Additional Information
Scan Code LN145441
Model Number ACFRE00133A
GTIN 4895213704113
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
72 months
Type:
Return to base
DOA Period:
28 days
RTB Period:
12 months
Manufacturer Contact Details
Manufacturer:
ARCTIC GmbH
