Antelope Audio Zen Quadro Synergy Core 14 x 10 Dual USB Powered Audio Interface
Antelope Audio Zen Quadro Synergy Core 14 x 10 Dual USB Powered Audio Interface
Scan code: LN148216 Manufacturer code: Zen Quadro Synergy Core
£499.00Item overdue since 30 January 2025
Pre order
  • Thumbnail 1 : Antelope Audio Zen Quadro Synergy Core 14 x 10 Dual USB Powered Audio Interface
  • Thumbnail 2 : Antelope Audio Zen Quadro Synergy Core 14 x 10 Dual USB Powered Audio Interface
  • Thumbnail 3 : Antelope Audio Zen Quadro Synergy Core 14 x 10 Dual USB Powered Audio Interface
  • Thumbnail 4 : Antelope Audio Zen Quadro Synergy Core 14 x 10 Dual USB Powered Audio Interface

Antelope Audio Zen Quadro Synergy Core 14 x 10 Dual USB Powered Audio Interface

Antelope Audio - Zen Quadro Synergy Core 14 x 10 Dual USB Powered Audio Interface

Scan code: LN148216 Manufacturer code: Zen Quadro Synergy Core
£499.00
FREE DELIVERY ON YOUR ENTIRE BASKET
Item overdue since 30 January 2025
Pre order

Email me when the availability or price changes

  • By DPD Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window | Free Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout
  • Collect instore Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE) | Free
  • UPS and DPD Pickup Pickup from local convenience store | £4.99 Collect your parcel from your newsagents, petrol stations and convenience stores
  • From £17.48 / month (APR 16.9%) or 0% for 4 months
    Monthly Payment: £41.59
    Instalment Rate: 0% p.a. (fixed)
    Cost of purchase: £499.00
    Total inc. interest: £499.00
    Monthly Payment: £20.80
    Instalment Rate: 0% p.a. (fixed)
    Cost of purchase: £499.00
    Total inc. interest: £499.00
    Monthly Payment: £17.48
    Instalment Rate: 16.9% p.a. (fixed)
    Cost of purchase: £499.00
    Total inc. interest: £629.03
    Example
    Minimum Spend: £99
    Instalment Rate: N/A
    Cost of purchase: £99
    Total inc. interest: £99
    If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 23.9% and may be even lower.

    Representative Example:

    Purchase Rate: 23.9% p.a. (variable)

    Representative: 23.9% APR (variable)

    Assumed Credit Limit: £1,200

    Subject to status. Terms and Conditions apply.
  • With a 10% deposit from just £13.26 / month (APR 19.9%)
  • paypal short logo blue 0% UP TO   MONTHS Spend £99 or more and choose PayPal at checkout. More info
  • SCANPROTECT Protect against installation damage for 28 days. More info

14 x 10 Dual USB Powered Audio Interface
Antelope - Zen Quadro Synergy Core

Antelope Zen Quadro Synergy Core 14 x 10 Dual USB Powered Audio Interface

Bring it. Together. From input to output, the Zen Q is designed to help you grow to a bigger setup without losing the desktop size format. The ultra-linear preamps and pristine AD/DA conversion give you professional quality in the studio or on the go – all in a compact package.

Add to that its generous connectivity and real-time onboard effects, and you’ll be up to almost any task – whether you want to record, mix, master, stream, or just play.

All I/O,
all the time
With its pairs of headphone outputs, preamps, and instrument inputs, the Zen Q interface was built with collaboration in mind. Flexible routing and switchable inputs unlock a wealth of possible setups. Four simultaneous Hi-Z instruments and two pairs of monitors? No problem. Four balanced analog outboard inserts? You got it.

If you need even more inputs, hook up any ADAT-compatible preamp with up to eight additional channels, and you’re ready to record a full band live. The stereo input and output over S/PDIF can be used to add an outboard effect, record a digital hardware synth, or send a high-quality clocking signal to the rest of your studio.

at a glance • Ideal for Producers/Musicians/Podcasters/Streamers
• 4 Mic/Line and 2 Hi-Z Inputs, 75 dB Gain
• 2 Headphone Outs, 4 Line Outs
• 24-Bit / 192 kHz AD/DA Conversion
• Virtual Loopback, Standalone Operation
• ADAT Input (8 Channels), 2 S/PDIF I/O

Everything You Could Need

Antelope Zen Quadro Synergy Core 14 x 10 Dual USB Powered Audio Interface

Extensive
connectivity
It all starts with the bus-powered connectivity – you only need a USB or Thunderbolt cable and a computer to start the show. The multipurpose inputs and the digital ports allow you to change things on the fly and expand your setup easily.

Antelope Zen Quadro Synergy Core 14 x 10 Dual USB Powered Audio Interface

Console-grade
preamps
For our discrete preamps we use a combination of transistors that results in maximum noise reduction and, most importantly, precise sound capture.

Antelope Zen Quadro Synergy Core 14 x 10 Dual USB Powered Audio Interface

Signature clocking
& conversion
The 64-bit AFC clocking and AD/DA converters give the stereo image more detail and a sense of spaciousness. This gives your recordings stand-out sound quality and makes the Zen Q ideal for mastering.

Discrete Console-Grade Preamps

Antelope Zen Quadro Synergy Core 14 x 10 Dual USB Powered Audio Interface

SOUND QUALITYThe Zen Q audio interface packs two professional-grade microphone preamps with 65db of gain and individual phantom power. Their ultra-linear, discrete circuit topology is on par with the preamps found in legendary consoles at the world’s best studios.

The clock you can’t beatTaken from our award-winning master clocks, the AFC™ (Acoustically Focused Clocking) technology ensures professional, low-jitter AD/DA conversion up to 192 kHz / 24 bit. This makes listening, mixing, and even mastering with the Zen Q an absolute audiophile experience. From analog to digital and back, your sound meets nothing but the best signal path.

Real-Time Onboard FX

Antelope Zen Quadro Synergy Core 14 x 10 Dual USB Powered Audio Interface

SYNERGY CORE COLLECTIONPowered by the Synergy Core, the Zen Q comes with a selection of 37 analog-modeled effects, with many more available in our Software Store. This ultra-low latency processing is entirely run within the interface on a unique combo of FPGA and DSP chips, at no extra cost to your computer’s CPU or memory. This means you can record and monitor voice and instruments through real-time models of effects and guitar amps, from classic gear to rare gems.

Not ready to commit? No problem. You can still take advantage of the Synergy Core effects during mixing by using afx2daw. Analog workflow in the digital domain.

Session Recall, Easy Routing & More...

From studio
to studio
The portable design of the Zen Q means you can carry it in your backpack and take it on tour with you or any on-location recording session.

Work at the speed
of sound
Unleash the true power of the Zen Q by creating custom monitor and headphone mixes, combining device inputs and DAW outputs with real-time analog-modeled Synergy Core FX – all that from an intuitive control panel.

Handy
loopback
The built-in loopback feature lets you livestream a complete mix to Facebook, YouTube, Twitch and more.

Introducing The New Zen Quadro SC

The Tech Spec

Features Specification
Channels of I/O 14 Inputs / 10 Outputs
Built-In DSP Yes
Maximum Sampling Rate 192 kHz / 24-Bit
Number of Microphone Inputs 4
Analog Audio I/O 2x Combo XLR-1/4" TRS Mic/Line/Hi-Z Input
2x Combo XLR-1/4" TRS Mic/Line Input
2x 1/4" TRS Balanced Line Output (DC-Coupled)
2x 1/4" TRS Balanced Monitor Output (DC-Coupled)
2x 1/4" TRS Headphone Output
Phantom Power 48 V
Digital Audio I/O 1x Mini-TOSLINK / 3.5 mm Optical ADAT Input
1x RCA Coaxial S/PDIF Input
1x RCA Coaxial S/PDIF Output
Host Connection 1x USB-C (Class-Compliant)
1x USB-C (Class-/USB OTG-Compliant)
Power Requirements USB Bus Power
OS Compatibility macOS 10.14.6 or Later
Windows 10 or Later
Processor Requirement PC: Intel Core i5 or Better
RAM Requirements 4 GB, 8 GB Recommended
Storage Requirements 4 GB
Weight 0.9 kg
Dimensions 20.8 x 13.5 x 5.8 cm
Specifications
Computer Interface Type USB 2.0 Type-C
Connections (Input) 4 x XLR / Jack Combo
Mic Preamps (Max) 4
Instrument Inputs (Max) 4
Phantom Power Yes
Sample Rate (Max) 192 kHz
Bit Resolution 24
iPad Compatible No
Connections (Output)
Dimensions (mm) 210 x 58 x 136 WxHxD
DSP Processing No
Misc. Notes
Additional Information
Scan Code LN148216
Model Number Zen Quadro Synergy Core
GTIN 850041548081
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
24 months
Type:
Return to base
DOA Period:
28 days
RTB Period:
24 months
