Allen & Heath GX4816 stage box
Scan code: LN102802
Manufacturer code: GX4816/240X
£3,599.00
Allen & Heath GX4816 stage box
Allen & Heath - GX4816 - 48 in /16 Out Stagebox For SQ And dLive
Scan code:
LN102802
Manufacturer code:
GX4816/240X
FREE DELIVERY ON YOUR ENTIRE BASKET
Order in the next 14 mins and get it tomorrow
(upgrade to Saturday delivery at checkout)
Allen & Heath - GX4816 Expander for SQ and dLive
48 XLR Input / 16 XLR Output Portable GX Expander with DX Sockets The GX4816 is the new flagship audio expander from Allen & Heath, providing high-input-count remote expansion for SQ, Avantis and dLive mixing desks. The GX8416 comes loaded with 48 dLive mic preamps, each preamp with its own individual Phantom Power LED indicator, 16 XLR line outs. An additional 2 DX ports are provided for connecting to a maximum of 4 DX expanders for further I/O expansion. It’s possible to connect to a ME personal mixer via the DX2 socket. Connection between the GX4816 couldn’t be simpler, simply connect via one CAT5e cable to an Slink socket on an SQ or Avantis desk, or, to an gigaACE audio netword card on a dLive system.
Detailed Information
Specification | Description |
---|---|
Type | Stagebox Interface |
Compatibility | GLD, Qu, Avantis and SQ mixers |
Channels | 48 x 16 |
Inputs - Mic Preamps | 48 x XLR (mic/line) |
Outputs - Main | 16 x XLR |
Data I/O: | 1 x Ethernet (dSnake), 1 x Ethernet (ME personal mixers), 1 x Ethernet (additional racks) |
Rackmountable | Yes, 5U |
Power Source | Standard IEC AC cable |
