Scan code: LN109601 Manufacturer code: TL-SF1009P

TP-LINK 9-Port Desktop Switch with 8-Port PoE+

9-Port TP-LINK TL-SF1009P Desktop Switch, 9x 10/100Mbps, 8× PoE+ Ports, IEEE 802.3af/at, 65 W PoE Budget

Thumbnail 1 : TP-LINK 9-Port Desktop Switch with 8-Port PoE+ Thumbnail 2 : TP-LINK 9-Port Desktop Switch with 8-Port PoE+ Thumbnail 3 : TP-LINK 9-Port Desktop Switch with 8-Port PoE+ Thumbnail 4 : TP-LINK 9-Port Desktop Switch with 8-Port PoE+
Scan code: LN109601 Manufacturer code: TL-SF1009P
£39.98
Order now and receive it by Monday, 21st September
Delivery Options
  • By DPD On 21st Sep to your specified address. | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • UPS and DPD Pickup Pickup from local convenience store | £4.79

    Collect your parcel from your newsagents, petrol stations and convenience stores

Services
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

Product Overview

Professional 9-Port Switch with 8-Port PoE+ (65 W Budget)

Compliance with the 802.3af/at PoE+ standard supports up to 30 W on each PoE port. The total 65 W PoE power budget for the 8× PoE+ ports opens up a wide range of applications, such as surveillance for offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, and more.


Ideal for IP Surveillance Up to 250m Transmissions

With extend mode, the PoE transmission distance reaches up to 250m perfect for IP Camera deployment in large areas.


Ideal for IP Surveillance Higher Performance and Security

Priority Mode and Isolation Mode make surveillance smoother and safer.


Priority Video Quality Guaranteed

Quality of sensitive applications like video monitoring in critical business areas is guaranteed by offering higher priority options for ports 1–2 when one-touch Priority Mode is on.


One-Click Traffic Separation for Ports 1-8

With one click, Isolation Mode easily divides traffic for ports 1–8 to avoid snooping and tampering. This enables the switch to isolate broadcast storm, improving LAN security and data transmission.


Intelligent Power Management

When total power consumption exceeds 65 W, the intelligent power management will cut the lower priority port power. This ensures the high priority port’s power supply and protects the device from power overload. It also automatically detects and provides the required power for your PoE devices while protecting your PoE and non-PoE equipment from being damaged.


Durable Metal Casing

The interior components of TL-SF1009P are protected by high-quality metal casing to ensure a long product life. Having passed an array of stringent reliability tests, TL-SF1009P delivers switching performance you can depend on.


Features

• 9× 10/100 Mbps RJ45 ports.
• 8× PoE+ ports transfer data and power on individual cables.
• Works with IEEE 802.3af/at compliant PDs.
• Supports PoE Power up to 30 W for each PoE port.
• Supports PoE Power up to 65 W for 8 PoE ports.
• Up to 250 m data and power transmitting range under Extend Mode.
• Priority Mode ensures high priority of ports 1–2 to guarantee the quality of sensitive application.
• Isolation Mode allows one-click client traffic separation for higher security and performance.
• Plug and play with no configuration required.
Specifications
Edition
Form Factor Desktop
Total Network Ports 9 x 10/100 (Fast Ethernet) RJ-45
PoE Support Type PoE / PoE+
No. of Ports Providing PoE 8 x 10/100 (Fast Ethernet) RJ-45
Other Non-Network Ports
Switching Capacity 1.8 Gbps
Non-Blocking Throughput
Forwarding Rate 1.3392 Mpps
MAC Address Table Size 2K Entries
Network Capacity
Built-in Flash Memory
RAM Memory
Network Protocols
Acoustic Noise
Max. Power Consumption 77.08 W
Max. PoE Wattage per Port 30 W
Mean Time Between Failures (MTBF)
Power Supply External Power Supply (Included)
Material Metal
Includes
Dimensions (WxHxD) 171 x 27 x 98 mm
Weight
Additional Information
Scan Code LN109601
Model Number TL-SF1009P
GTIN 6935364052973
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
60 months
Type:
Direct
DOA Period:
28 days
Manufacturer Contact Details
Manufacturer:
TP-LINK
Telephone:
0845 147 0017 (UK) or 0818 229 000 (Ireland)
