Gigabyte AMD Radeon RX VEGA 56 8GB HBM2 Graphics Card

8GB Gigabyte Radeon RX Vega 56, 14nm, 3584 Streams, 1156MHz, 1471MHz Boost, 800MHz HBM2, DP/HDMI

Gigabyte
Scan code: LN84150 Manufacturer code: GV-RXVEGA56-8GD-B Request call
£515.99
In stock
Pay on Scan Finance with a 10% deposit from just £12.89 / month (APR 15.9%)
Mid Range
Delivery options £11.50 By DPD On 21st Sep 2017 DPD Delivered to your specified address. Receive SMS with one-hour delivery window. Free Collect Instore Q-Collect Place your order online and collect from our Bolton store with Q-Collect. Weekend, timed and European delivery options are available at checkout ScanProtect protection ScanProtect Protect against installation damage for 28 days.More
Product Overview Vega has arrived. Probably the most anticipated graphics cards architecture for years, the Radeon RX Vega56 graphics cards come hot on the heels of the hugely popular flagship Vega64 cards, and the great news is you can now purchase yours from Scan. For the time being available in a stealthy all-black design, combining style, value & performance; Team Red has built your perfect upgrade.

All Vega56 graphics cards from Scan feature a huge 3584 stream processors, fed by 8 Gigabytes of the latest HBM2 Memory, whilst this particular Gigabyte Radeon RX Vega56 card incorporates a blower-style cooler with black backplate & shroud, for optimum gaming performance with stealth.

Next Gen Compute Units
These revamped nCUs (1 nCU = 64 stream processors) are designed to operate at incredible clock speeds and deliver extreme gaming experiences with the newest high resolution and high refresh rate monitors.

Revolutionary Memory Engine
State of the art memory system shatters the limitations of traditional GPU memory, to tackle the growing high res texture packs in today’s games.

Optimized Pixel Engine
Optimized rasterizer technology enhances rendering efficiency and leaves more headroom to crank up quality settings while maintaining smooth 3D rendering.

Enhanced Geometry Engine
The enhanced geometry engine can efficiently process millions of polygons that make up your game, helping boost FPS. Features • Powered by AMD Radeon™ RX VEGA 56.
• Air Cooling System.
• 8GB 2048-bit High Bandwidth Memory (HBM2).
• Radeon™ VR Ready Premium.
• 3rd Gen FinFET 14.
• Features HDMIx1/ DisplayPortx3.
Specifications
Chipset Radeon RX Vega56
Edition
Manufacturing Process 14 nm
Microarchitecture Vega
Streams 3584
Core Clock 1156 MHz
Boost Clock 1471 MHz
Memory Size 8GB
Memory Type HBM2
Memory Clock 800 MHz
Memory Speed (Effective with DDR)
Memory Data Rate 1.6 Gb/s
Memory Bus 2048 Bit
Memory Bandwidth 410 GB/s
Peak Half Precision Compute Performance 21 TFLOPS
Peak Single Precision Compute Performance 10.5 TFLOPS
Cooling Solution Single Fan (1)
Cooler Design AMD Reference Design Blower Fan (Black)
Fitted/Included Backplate Yes
Interface PCIe 3.0 (x16)
Connectivity
  • 3 x DisplayPort 1.4
  • 1 x HDMI 2.0b
Maximum Digital Resolution 5120x2880 @ 60Hz
Maximum Analog (VGA) Resolution N/A
Max. Concurrent Displays 4 Displays
AMD CrossFire Support 4-Way CrossFire
AMD Freesync Support Yes
AMD FreeSync Version FreeSync™ 2
Microsoft DirectX Support 12 API
HDR Support Yes
Width Dual Slot
Low Profile Support N/A
Graphics Card TDP/Power 210 W
Graphics Card Power Connectors 2 x 8-pin PCIe
Minimum Recommended PSU 650 W
Maximum GPU Temperature 85 C
Dimensions 127 x 40 x 280 mm
Package Type Retail
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
36 months
Type:
Return to base
DOA Period:
28 days
RTB Period:
36 months
