Seasonic EVO 850W Full Modular Power Supply

850W Seasonic EVO, 80 PLUS Bronze, Full Modular, SLI/CrossFire, Single (1) Rail, 70A +12V, 1x120mm Fan, ATX PSU

Scan code: LN55450 Manufacturer code: SS-850AM2 Request call
£109.99Item overdue since 29 May 2017
Pre order
Spend over £225 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
High End
Delivery options £5.48 By DPD DPD Delivered to your specified address. Receive SMS with one-hour delivery window. £4.79 Collect from local shops UPS and DPD Pickup Collect your parcel from your newsagents, petrol stations and convenience stores. Free Collect Instore Q-Collect Place your order online and collect from our Bolton store with Q-Collect. Weekend, timed and European delivery options are available at checkout ScanProtect protection ScanProtect Protect against installation damage for 28 days.More
Product Overview DC to DC Converter Design
Provides superior dynamic response, greater system stability and maximizes the 12V DC rail output.

Highly reliable 105c Aluminium Electrolytic Capacitors
A build that integrates high level, Japan-sourced components and to extend product life.

Conductive Polymer Aluminium Solid Capacitors
A build with high level, Japan or Taiwan-sourced components, which ensure operation stability under extreme conditions.

Ample +12V Outputs
Enhanced +12V current capability broadens utilization possiblities.

Active Power Factor Correction[Up to 99%]
Reduces line loss and power distortion.

Smart & Silent fan control
Intelligent thermal control to ensure an optimal balance between silence and cooling.

120mm Ball Bearing Cooling Fan
Increases airflow and product lifetime while reducing noise and fan rotation. Features Multi-GPU technology Support
6-Pin and 8-Pin PCI-E connectors to support all GPU platforms.

Fully Modular Cables
Flexible cable solution to reduce clutter and optimize cable management.

Size ATX
Edition EVO
Wattage 850 W
80 PLUS Certification 80 PLUS Bronze
Max. Efficiency 85 %
Cooling Fan
Fans 1 x 120mm
Internal +12V Rails Single Rail
Rail 1 +12V 70 A
Rail 2 +12V N/A
Rail 3 +12V N/A
Rail 4 +12V N/A
Rail 5 +12V N/A
Rail 6 +12V N/A
Max. Combined Output +12V 70 A
Modular Yes
Modularity Full Modular
SLI/CrossFire Yes
EPS 12V Yes
Motherboard Connector 20+4-pin
  • 1 x 4+4-pin CPU +12V (EPS)
  • 5 x 4-pin Molex
  • 6 x 6+2-pin PCIe
  • 1 x 8-pin CPU +12V (EPS)
  • 1 x FDD Power
  • 10 x SATA
Dimensions 150 x 86 x 170 (WxHxD)
Package Type Retail

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

60 months
Return to base
DOA Period:
7 days
RTB Period:
60 months
Manufacturer Contact Details
Seasonic / Scan
0871 472 4747
Customers also bought
850W Seasonic EVO, 80 PLUS Bronze, Full Modular, SLI/CrossFire, Single (1) Rail, 70A +12V, 1x120mm Fan, ATX PSU is rated 5.0 out of 5 by 1.
Rated 5 out of 5 by from Amazing! This was a great purchase it does everything it says and everything you'd expect, however my only complaint is that the seasonic logo ended up upside down due to the design of my case and it you care about your product being visually appealing then you might want to check the design of your case and this PSU other then that amazing product plenty of spare cables, would heartly recommend it
