Scan code: LN98290 Manufacturer code: T1500G-8T(TL-SG2008)

TP-LINK 8 Port Managed Smart Switch

8 Port TP-LINK T1500G-8T JetStream Gigabit Smart Switch, 8x 10/100/1000M Rj45

Thumbnail 1 : TP-LINK 8 Port Managed Smart Switch Thumbnail 2 : TP-LINK 8 Port Managed Smart Switch Thumbnail 3 : TP-LINK 8 Port Managed Smart Switch Thumbnail 4 : TP-LINK 8 Port Managed Smart Switch
Scan code: LN98290 Manufacturer code: T1500G-8T(TL-SG2008)
£52.75
spend over £225 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
Delivery Options
  • By DPD On 25th Nov 2019 to your specified address. | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • UPS and DPD Pickup Pickup from local convenience store | £4.79

    Collect your parcel from your newsagents, petrol stations and convenience stores

Services
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

Product Overview What This Product Does
TP-Link JetStream Gigabit Smart Switch T1500G-8T is equipped with 8 gigabit RJ45 ports and the port 8 can receive power from PoE Power Sourcing Equipment (PSE). The switch provides high performance, enterprise-level QoS, useful security strategies and rich layer 2 management features.

TP-Link’s JetStream Gigabit Smart Switch T1500G-8T is especially designed for the small and medium business networks that require efficient network management. T1500G-8T comes with a comprehensive set of features, such as Link Aggregation Group, 802.1Q VLAN, Access Control Lists (ACL), Quality of Service (QoS L2 to L4), Storm Control and IGMP Snooping to provide a small or medium-sized business with a network that is geared for growth while ensuring performance and reliability. What’s more, its easy-to-use web management interface means faster setup and configuration with less downtime, providing the ideal solution for your business network.

IEEE 802.3at/af-compliant Power over Ethernet
T1500G-8T supports IEEE 802.3af/at standard for Power over Ethernet (PoE). It can obtain its power from either a PoE source or from an external AC power adapter. This gives an SMB flexibility when installing the switch in places where a power outlet is not present.

Advanced QoS features
To integrate voice, data and video service on one network, the switch applies rich QoS policies. Administrator can designate the priority of the traffic based on a variety of means including Port Priority, 802.1P Priority and DSCP Priority, to ensure that voice and video are always clear, smooth and jitter free. In conjunction with the Voice VLAN the switch supports, the voice applications will operate with much smoother performance.

Abundant Layer 2 features
For more application of layer 2 switches, T1500G-8T supports a complete lineup of layer 2 features, including 802.1Q tag VLAN, Port Isolation, Port Mirroring, STP/RSTP/MSTP, Link Aggregation Group and 802.3x Flow Control function. Any more, the switches provide advanced features for network maintenance such as Loop Back Detection, Cable Diagnostics and IGMP Snooping. IGMP snooping ensures the switch intelligently forward the multicast stream only to the appropriate subscribers while IGMP throttling & filtering restrict each subscriber on a port level to prevent unauthorized multicast access.

Enterprise Level Management Features
T1500G-8T is easy to use and manage. It supports various user-friendly standard management features, such as intuitive web-based Graphical User Interface (GUI) or SNMP (v1/2/3) and RMON support enables the switch to be polled for valuable status information and send traps on abnormal events. Features • 802.3af compliant PoE Port8 allows receiving power from a PoE source
• Gigabit Ethernet connections on all ports provide full speed of data transferring
• Advanced security features include IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm Control, DHCP Snooping, 802.1X, and Radius Authentication
• L2/L3/L4 QoS and IGMP snooping optimize voice and video applications
• WEB/CLI managed modes, SNMP, RMON bring abundant management features
• Dual Firmware Image improves reliability and up-time of your network
Specifications
Edition JetStream
Form Factor Desktop
Total Network Ports 8 x 10/100/1000 (Gigabit) RJ-45
PoE Support Type
No. of Ports Providing PoE 1 x 10/100/1000 (Gigabit) RJ-45
Other Non-Network Ports
Switching Capacity
Non-Blocking Throughput
Forwarding Rate 11.9Mpps
MAC Address Table Size 8K Entries
Network Capacity
Built-in Flash Memory
RAM Memory
Network Protocols
  • IEEE 802.1d
  • IEEE 802.1p
  • IEEE 802.1Q
  • IEEE 802.1s
  • IEEE 802.1w
  • IEEE 802.1x
  • IEEE 802.3ab
  • IEEE 802.3ad
  • IEEE 802.3af
  • IEEE 802.3i
  • IEEE 802.3x
  • IEEE 802.3z
Acoustic Noise
Max. Power Consumption 5.75W W
Max. PoE Wattage per Port
Mean Time Between Failures (MTBF)
Power Supply External Power Supply (Included)
Material
Includes
Dimensions (WxHxD) 209 x 26 x 126 mm
Weight
Additional Information
Scan Code LN98290
Model Number T1500G-8T(TL-SG2008)
GTIN 6935364083045
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
36 months
Type:
Direct
DOA Period:
28 days
RTB Period:
12 months
Manufacturer Contact Details
Manufacturer:
TP-LINK
Telephone:
0845 147 0017 (UK) or 0818 229 000 (Ireland)
