Scan code: LN109283 Manufacturer code: TL-SG1005LP

TP-LINK 5 Port Gigabit Desktop Switch with 4-Port PoE

5-Port TP-LINK TL-SG1005LP Gigabit Desktop Switch, 10/100/1000, 4-Port PoE

Thumbnail 1 : TP-LINK 5 Port Gigabit Desktop Switch with 4-Port PoE Thumbnail 2 : TP-LINK 5 Port Gigabit Desktop Switch with 4-Port PoE Thumbnail 3 : TP-LINK 5 Port Gigabit Desktop Switch with 4-Port PoE
Scan code: LN109283 Manufacturer code: TL-SG1005LP
£34.99Item due on 24 September 2020
Due 24th Sep
Delivery Options
  • By DPD to your specified address. | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • UPS and DPD Pickup Pickup from local convenience store | £4.79

    Collect your parcel from your newsagents, petrol stations and convenience stores

Services
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

Product Overview

Dedicated 4-Port PoE+ Switch for Numerous Applications

Compliance with the 802.3af/at PoE+ standard supports up to 30 W on each PoE port. The total 40 W PoE power budget* for the 4× PoE ports opens up a wide range of applications, such as surveillance for offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, and more.


Intelligent Power Management

When total power consumption exceeds 40 W, the intelligent power management will cut the lower priority port power. This ensures the high priority port’s power supply and protects the device from power overload. It also automatically detects and provides the required power for your PoE devices while protecting your PoE and non-PoE equipment from being damaged.


Qos For Fluent Online Experience

Administrators can designate the priority of traffic based on QoS, for example, to ensure that voice and video applications remain clear and lag-free.


Traffic Optimization for IPTV

IGMP Snooping optimizes multimedia traffic delivery, to ensure a better network experience especially for applications like IPTV.


Durable Metal Casing

The interior components of TL-SG1005LP are protected by high-quality metal casing to ensure a long product life. Having passed an array of stringent reliability tests, TL-SG1005LP delivers switching performance you can depend on.



Features

• 5× 10/100/1000 Mbps RJ45 ports
• With four PoE+ ports, transfers data and power on one single cable
• Works with IEEE 802.3af/at compliant PDs
• 802.1p/DSCP QoS enable smooth latency-sensitive traffic
• Supports PoE Power up to 30 W for each PoE port
• Supports PoE Power up to 40 W for all PoE ports*
• Plug and play, no configuration and installation required
Specifications
Edition Unmanaged Switch
Form Factor
Total Network Ports 5 x 10/100/1000 (Gigabit) RJ-45
PoE Support Type PoE
No. of Ports Providing PoE 4 x 10/100/1000 (Gigabit) RJ-45
Other Non-Network Ports
Switching Capacity 10 Gbps
Non-Blocking Throughput
Forwarding Rate 7.44 Mpps
MAC Address Table Size 2k Entries
Network Capacity
Built-in Flash Memory
RAM Memory
Network Protocols
  • IEEE 802.1p
  • IEEE 802.3af
  • IEEE 802.3at
  • IEEE 802.3x
Acoustic Noise
Max. Power Consumption 47.5 W W
Max. PoE Wattage per Port
Mean Time Between Failures (MTBF)
Power Supply External Power Supply (Included)
Material ABS / SPCC
Includes
Dimensions (WxHxD) 99.8 x 25 x 98 mm
Weight
Additional Information
Scan Code LN109283
Model Number TL-SG1005LP
GTIN 6935364052737
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Warranty information has not yet been updated for this product. For further information please call 0871 472 4747 or 01204 474747.
