Scan code: LN112122 Manufacturer code: TL-SF1005LP

TP-LINK 5-Port Fast Ethernet Desktop Switch w/ PoE

5-Port TP-LINK TL-SF1005LP Fast Ethernet Desktop Switch w/ 4-Port PoE, 5x 10/100Mbps, Plug & Play, Fanless, Black

Thumbnail 1 : TP-LINK 5-Port Fast Ethernet Desktop Switch w/ PoE Thumbnail 2 : TP-LINK 5-Port Fast Ethernet Desktop Switch w/ PoE Thumbnail 3 : TP-LINK 5-Port Fast Ethernet Desktop Switch w/ PoE
Scan code: LN112122 Manufacturer code: TL-SF1005LP
£27.98
Order now and get it tomorrow (upgrade to Sunday delivery at checkout)
spend over £280 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
Delivery Options
  • By DPD On 26th Jul to your specified address. | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • UPS and DPD Pickup Pickup from local convenience store | £4.79

    Collect your parcel from your newsagents, petrol stations and convenience stores

Services
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

Product Overview

Dedicated 4-Port PoE Switch (41 W Budget) for Numerous Applications

Compliance with the 802.3af PoE standard supports up to 15.4 W on each PoE port. The total 41 W PoE power budget* for the 4× PoE ports opens up a wide range of applications, such as surveillance for offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, and more.

• 4 PoE Ports.
• Up to 15.4W on Each Port.
• Total 41W Power Budget.


Plug and Play, No Configuration Required

1. Plug in.
2. Connect devices such as IP phones, IP cameras, access points, etc.
3. Enoy!


Ideal for IP Surveillance - Up-to 250m Transmissions

With extend mode, the PoE transmission distance reaches up to 250 m* - perfect for IP Camera deployment in large areas.

*The speed of the ports in extend mode will downgrade to 10 Mbps. The actual transmission distance may vary due to power consumption of PoE-powered devices or the cable quality and type.


Priority Video Quality Guaranteed

Quality of sensitive applications like video monitoring in critical business areas is guaranteed by offering higher priority options for ports 1–2 when one-touch Priority Mode is on.


Intelligent Power Management

When total power consumption exceeds 41W, the intelligent power management will cut the lower priority port power. This ensures the high priority port’s power supply and protects the device from power overload. It also automatically detects and provides the required power for your PoE devices while protecting your PoE and non-PoE equipment from being damaged.


Durable Metal Casing

The interior components of TL-SF1005LP are protected by high-quality metal casing to ensure a long product life. Having passed an array of stringent reliability tests, TL-SF1005LP delivers switching performance you can depend on.

• Compact desktop design.
• Wall-mounting capable.
• Fanless design.

Features

• 5× 10/100 Mbps RJ45 ports.
• 4× PoE ports transfer data and power on individual cables.
• Works with IEEE 802.3af compliant PDs.
• Up to 250 m data and power transmitting range under Extend Mode.
• Priority Mode ensures high priority of ports 1–2 to guarantee the quality of sensitive application.
• Supports PoE Power up to 41 W for all PoE ports.
• Plug and play with no configuration required.

Specifications
Edition Unmanaged Switch
Form Factor Desktop/Wall Mount
Total Network Ports 5 x 10/100 (Fast Ethernet) RJ-45
PoE Support Type PoE
No. of Ports Providing PoE 4 x 10/100 (Fast Ethernet) RJ-45
Other Non-Network Ports
Switching Capacity 1 Gbps
Non-Blocking Throughput
Forwarding Rate 0.744 Mpps
MAC Address Table Size 2K Entries
Network Capacity
Built-in Flash Memory
RAM Memory
Network Protocols
  • IEEE 802.3af
  • IEEE 802.3at
Acoustic Noise 0 dB
Max. Power Consumption 47 W
Max. PoE Wattage per Port 15.4 W
Mean Time Between Failures (MTBF)
Power Supply External Power Supply (Included)
Material Metal
Includes
Dimensions (WxHxD) 100 x 25 x 98 mm
Weight
Additional Information
Scan Code LN112122
Model Number TL-SF1005LP
GTIN 6935364052799
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
36 months
Type:
Direct
DOA Period:
28 days
RTB Period:
12 months
