D-Link DGS-1100-05V2/B 5 Port Gigabit Smart Managed Switch
D-Link DGS-1100-05V2/B 5 Port Gigabit Smart Managed Switch
Scan code: LN116973 Manufacturer code: DGS-1100-05V2/B
£29.48Item currently awaiting an ETA
Pre Order
Pre order
  • Thumbnail 1 : D-Link DGS-1100-05V2/B 5 Port Gigabit Smart Managed Switch
  • Thumbnail 2 : D-Link DGS-1100-05V2/B 5 Port Gigabit Smart Managed Switch
  • Thumbnail 3 : D-Link DGS-1100-05V2/B 5 Port Gigabit Smart Managed Switch

D-Link DGS-1100-05V2/B 5 Port Gigabit Smart Managed Switch

5 Port D-Link DGS-1100-05V2/B Gigabit Smart Managed Switch, 5 x 10/100/1000 Ports, Web UI, Green Technology, Fanless
MORE INFO
MORE INFO

Scan code: LN116973 Manufacturer code: DGS-1100-05V2/B
£29.48
£5.48 NEXT DAY DELIVERY
Item currently awaiting an ETA
Pre Order
Pre order
  • By DPD Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout
  • Collect instore Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE) | Free
  • UPS and DPD Pickup Pickup from local convenience store | £4.79 Collect your parcel from your newsagents, petrol stations and convenience stores
  • Spend over £280 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
  • SCANPROTECT Protect against installation damage for 28 days. More info
Product Overview

Simple. Easy. Smart.

DGS-1100 Smart Switch Series provides an affordable solution for environments that require simple network management.


Advanced Security Features

The DGS-1100's web user interface is an easy way to manage Layer 2 features, such as VLANs, Spanning Tree Protocol (STP), link aggregation (static). With powerful security features like IGMP snooping, Static MAC, and Storm Control, the DGS-1100 Smart family is a versatile solution for environments that require easy to deploy and easy to configure solutions without added complexities.


Simplify Network Management

D-Link’s free Network Assistant (DNA) displays all connected devices and speeds up the first time configuration. The free D-View 7 Network Management System comes with a license for 25 nodes and 2 probes and full access to the management tools. Optional upgrade licenses allow you to broaden your network and analysis.


Easy Troubleshooting

The DGS-1100 Series features Loopback Detection and Cable Diagnostics to help network administrators find and solve network problems quickly and easily.

Loopback Detection is used to detect loops created by a specific port and automatically shut down the affected port. The Cable Diagnostics feature is designed for network administrators to quickly examine the quality of the copper cables, recognise the cable type, and detect cable errors.


Green Technology

D-Link Green technology enables the DGS-1100 Smart series to save power without sacrifices. The majority of the family utilises a fanless design, for silent and energy efficient operation. All are IEEE 802.3az compliant and feature Link Status detection.

Features


• 5 x 10/100/1000BASE-T ports
• Compact design for convenient placement
• Fanless design for silent operation
• Innovative D-Link Green energy saving features
• Complete web interface for comprehensive switch management

Specifications
Edition Smart Managed Switch
Form Factor Desktop
Total Network Ports 5 x 10/100/1000 (Gigabit) RJ-45
PoE Support Type
No. of Ports Providing PoE
Other Non-Network Ports
Switching Capacity 10 Gbps
Non-Blocking Throughput
Forwarding Rate 7.4 Mpps
MAC Address Table Size 2k Entries
Network Capacity
Built-in Flash Memory
RAM Memory
Network Protocols
  • IEEE 802.3
  • IEEE 802.3ab
  • IEEE 802.3u
  • IEEE 802.3x
  • IEEE 802.3z
Acoustic Noise 0 dB
Max. Power Consumption 3.42 W
Max. PoE Wattage per Port
Mean Time Between Failures (MTBF) 1,562,055 hours
Power Supply External Power Supply (Included)
Material
Includes
Dimensions (WxHxD) 100.5 x 28 x 82 mm
Weight 0.23 kg
Additional Information
Scan Code LN116973
Model Number DGS-1100-05V2/B
GTIN 790069453281
