QNAP TS-i410X-8G 4 bay Industrial Grade Tower NAS Enclosure

QNAP TS-i410X-8G 4-bay Desktop NAS

With a fanless design and rock-solid chassis, the TS-i410X industrial grade NAS is designed for harsh environments. The TS-i410X can operate in temperatures of -40 ~ 70 Celsius (-40°F ~ 158°F) while its 9V ~ 36V DC wide-range power supply is ideal for factories, warehouses, transportation, and other rugged operating environments.

Quad Cores up to 3.0 GHz with AES-NI Accelerated Encryption

The TS-i410X is powered by Intel® Atom® x6425E quad-core processor (burst up to 3.0 GHz) and equipped with 8 GB dual-channel memory. With hardware-accelerated AES-NI encryption, the TS-i410X also provides unmatched encryption performance while ensuring the safety of sensitive business data stored in the NAS. The TS-i410X has four 2.5-inch SATA 6Gb/s SSD slots for allocating SSDs (industrial SSDs are recommended) to greatly boost IOPS to meet the performance requirements of demanding applications.

Industrial-Grade Hardened Hardware Design with 9V ~ 36V DC Wide-Range Power Supply

With a fanless design and rock-solid chassis and compliant with the military-grade MIL-STD-810H the TS-i410X can operate in -40 ~ 70 Celsius (-40°F ~ 158°F) environments. It can be used as a set-top box, or used with the optional VESA 75 wall-mount to provide installation flexibility. With the 9V ~ 36V DC wide-range power supply, the TS-i410X is suitable for industrial and transportation applications with a variety of input voltage requirements.

Use with Industrial Wide Temperature SSDs

When using industrial wide temperature SSDs, adjust the disk warning setting to 85°C (185°F) in the Storage & Snapshots to match the upper limit of SSD operating temperature. (The default temperature is 70°C for SSDs)

Build a High-Speed 10GbE Network Environment

The TS-i410X provides two 10GBASE-T (10G/5G/2.5G/1G) ports. With QNAP's comprehensive, budget-friendly storage and networking solutions you can easily and flexibly upgrade workplace or home networks to handle bandwidth-hungry applications.

Multiple USB Ports for UPS, and More

With four USB 3.2 Gen 2 (10Gbps) ports, you can quickly backup and transfer large files to/from the TS-i410X. A wide range of USB devices, such as external hard drive or uninterruptible power supply (UPS), are also supported to provide greater functionality and application potential.

Direct 4K HDMI™ Output for Multimedia and Virtual Machines

The TS-i410X features Intel® UHD Graphics that supports hardware decoding and real-time transcoding. The HDMI™ output supports up to 4K @30Hz, providing great benefits for applications like video production/editing or industrial design that demands high resolution as well as intensive media storage, transfer and display. By connecting the TS-i410X to an HDMI™ display, you can operate virtual machines from Virtualization Station or Linux Station, or directly watch multimedia content saved on the NAS.

Smart Surveillance Solution for 24/7 Security

QVR Elite is QNAP's subscription-based smart surveillance solution, allowing you to easily build a surveillance system with lower TCO and higher scalability. Recordings are saved as MP4 files, allowing playback on nearly every device. QVR Elite also integrates QNAP AI-based solutions to build smart facial recognition for retail and door access systems with QNAP NAS. You can arrange a dedicated, independent storage space for surveillance data on the TS-i410X and enjoy simplified camera management, storage space allocation, camera live viewing and playback.

QTS 5, Fast, Smooth, and Easy-to-use!

The TS-i410X comes with the QTS 5 operating system as standard, providing a next-generation usage experience with an updated system kernel, optimized user interface, and advanced security features.

Comprehensive Backup and Disaster Recovery Solution

The TS-i410X supports various apps that cover all your backup needs. Practice safe IT habits by regularly backing up files and device content, allowing them to be easily restored when needed.

Multi-Version Snapshots Mitigate Ransomware Threats

The TS-i410X supports block-based snapshots that record the state of the system at any time. It helps protect data, which can be restored back to a specific point of time, greatly helping in mitigating the threat of ransomware.

The Best File Storage and Collaboration Center

The TS-i410X integrates rich apps for storing, managing, synchronizing, searching, and archiving files. It supports SMB/CIFS, AFP, and NFS protocols for streamlined file sharing across Windows®, Mac®, and Linux®/UNIX®, and provides the smartest NAS solution for professionally managing your files.

Comprehensive Security and Privilege Settings

The TS-i410X is loaded with flexible privilege settings and security measures. Besides IP blocking, QNAP Authenticator, HTTPS connection, there are more apps that help ensure optimal NAS protection against threats like malware and hackers.

All-in-one Solution for Hosting Virtual Machines and Containers

By running multiple virtual machines and containers on the TS-i410X, you can deploy multi-tenant environments and applications to increase management efficiency and save hardware costs. Coupled with the Network & Virtual Switch app that boosts interoperability between virtual machines, containers, QNAP NAS, and other physical devices on the network, you can flexibly allocate physical and virtual network resources to simplify network deployment.

More Productivity-Boosting Applications

The TS-i410X provides an App Center that includes feature-rich apps to expand your NAS potential!

Extend Hardware Warranty up to 5 Years

The TS-i410X is backed by a 3-year warranty at no additional cost. You can also purchase a warranty extension that extends your warranty coverage up to 5 years.

10GbE connectivity: Two 10GBASE-T/NBASE-T RJ45 ports accelerate virtualization tasks, high speed backup/recovery, file sharing, and video transmission.
4K HDMI™ output: Supports 4K playback and real-time transcoding.
Optimized SSD performance and lifespan: Install SATA 6Gb/s SSDs and activate SSD caching for increased IOPS performance.
Virtualization applications: Host multiple virtual machines and containers to run a wide range of applications and microservices.
Data backup and recovery: Protect PC/Macs, virtual machines, software containers, and cloud data.
Hybrid cloud applications: Cloud storage gateways realize hybrid cloud applications by working with the cache space reserved on NAS.
